Movie - DRONE
TM
RADIO CONTROLLED
QUAD-COPTER WITH CAMERA
FEATURING:
1. Four-Rotor design allows great speed and maneuverability for both Indoor and Outdoor use.
2. Built-in 6-axis Gyro ensures excellent stability.
3. Modular design for increased ease of maintenance.
4. 360-degree 3-dimensional stunt and tumbling function
5. With Photo/Video
The materials and specifications stated in this instruction manual are for reference only.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Movie-Drone and is the answer not in the manual?

Questions and answers

Related Manuals for Protocol Movie-Drone

Summary of Contents for Protocol Movie-Drone

  • Page 1 Movie - DRONE RADIO CONTROLLED QUAD-COPTER WITH CAMERA FEATURING: 1. Four-Rotor design allows great speed and maneuverability for both Indoor and Outdoor use. 2. Built-in 6-axis Gyro ensures excellent stability. 3. Modular design for increased ease of maintenance. 4. 360-degree 3-dimensional stunt and tumbling function 5.
  • Page 2 RC Q OPTER WITH AMERA Thank you for your purchase of Protocol’s Movie-Drone. You are about to experience the best of what remote control flight has to offer. We strongly recommend that you take the time to read this manual thoroughly. It contains many tips and instructions on how to get the most out of this aircraft and maintain it for a long life.

  • Page 3: Remote Control

    REMOTE CONTROL KEYPAD AND LCD MANUAL Antenna Lights (Flashing or Steady) Single Flip Photo/Video Speed (Low, High Flip) Forward/Backward Trim Throttle – Left/Right Turn Directional Control Stick (Forward/Reverse, Left/Right Banking) Left/Right Turn Trim Left/Right Banking Trim Remote Control 1. Install batteries carefully. 2.

  • Page 4: Flying The Quadcopter

    1 and 2 of the process. Turn the remote off and unplug the cable from the Movie-Drone. Then, turn on the remote first and then plug the cable back into the Movie-Drone to turn it on. Follow with Step 3.

  • Page 5: Charging The Quad-Copter Battery

    CHARGING THE QUAD-COPTER BATTERY 1. Disconnect the wires on the quad-copter. 2. Plug the A/C adapter to a power outlet and connect the other end into the battery. The orange indicator light on the box will turn on. The green indicator will turn on once the battery is fully charged.

  • Page 6: Operation (Mode 1)

    3V. Check monthly and recharge as needed. 5. Do not disassemble battery. LOW, HIGH, AND FLIP SPEED MODES The Movie-Drone features 3 speed modes. Low, High, and Continuous Flip*. Choose the speed based on flight experience and level of Low, High, Flip comfort.

  • Page 7: Troubleshooting

    Potential Solution 1. To synchronize, turn on controller, then 1. Communication between controller and turn on aircraft and place it on level Movie-Drone aircraft was not synchronized during set up ground. Move throttle stick all the way does not forward, then all the way back.
  • Page 8 TIPS ON 3D STUNT & TUMBLING OPERATION Once you are familiar with the basics of quad-copter flight, you can try some advanced maneuvers! At a height of at least 10 feet, press the Single Flip button [on controller’s right side] then move the right stick in whichever direction desired to perform a 360-degree flip in that direction.

  • Page 9: Shooting Photo/Video

    Shooting Photo/Video Thank you for your purchase of Protocol’s Movie-Drone. We know that accidents can sometimes happen and that is why we offer spare parts kits on our website: ProtocolNY.com.
