Pace Setter G02743 Operating Instructions Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

ELECTRIC GROUT REMOVER

Español p. 21

ATTACH YOUR RECEIPT HERE

Serial Number

Questions, problems, missing parts? Before returning to

your retailer, call our customer service department at

1-877-876-7562, 8 a.m. - 5 p.m., CST, Monday - Friday.

Purchase Date

# G02743

3156805

CONFORMS TO US STD.

60745-1

CERTIFIED TO CSA STD.

C22.2 No. 68-09

Table of Contents

Summary of Contents for Pace Setter G02743

Page 1 # G02743 ELECTRIC GROUT REMOVER Español p. 21 3156805 CONFORMS TO US STD. 60745-1 CERTIFIED TO CSA STD. C22.2 No. 68-09 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at...
Page 2: Table Of Contents
Operating Instructions ............13 Care and Maintenance ............17 Troubleshooting ..............18 Warranty ................20 TECHNICAL SPECIFICATIONS DESCRIPTION SPECIFICATIONS Model G02743 Input 120 V ~ 60 Hz, AC only Amps Maximum stroke 7,200 min Net weight 12 oz. S2: 30 min.: Cool the tool completely after operating at rated load...
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY On/Off switch Stroke adjustment dial Power cord Output shaft Setscrew Chisel tip Point tip Hex wrench...
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING • DO NOT allow familiarity with products to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury.
Page 5: Electrical Safety
SAFETY INFORMATION • Keep bystanders, children and visitors away while operating a power tool. Distractions can cause you to lose control. Electrical Safety • Double insulated tools are equipped with a polarized plug (one blade is wider than the other.) This plug will fit in a polarized outlet only one way.
Page 6: Personal Safety
SAFETY INFORMATION Personal Safety • Stay alert, watch what you are doing and use common sense when operating a power tool. DO NOT use tool while tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Page 7 SAFETY INFORMATION • Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the tool. Such preventive safety measures reduce the risk of the tool starting accidentally. • Store idle tools out of reach of children and other untrained persons.
Page 8 SAFETY INFORMATION Specific Safety Rules • Hold tool by its insulated grip surface when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts of the cutting tool “live” and shock the operator. •...
Page 9 SAFETY INFORMATION • Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. A wire gauge size (A.W.G.) of at least 16 is recommended for an extension cord 50 ft. or less in length.
Page 10: Electrical
SAFETY INFORMATION • DO NOT alter or misuse tool. Any alteration or modification is a misuse and may result in serious personal injury. • Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If you loan someone this tool, loan them these instructions also.
Page 11: Electrical Connection
ELECTRICAL Electrical Connection The product has a precision-built electric motor. It should be connected to a power supply that is 120 volts, 60 Hz, AC only (normal household current). DO NOT operate this tool on direct current (DC). A substantial voltage drop will cause a loss of power and motor will overheat.
Page 12: Explanation Of Symbols
ELECTRICAL WARNING • Keep the extension cord clear of the working area. Position the cord so that it will not get caught on lumber, tools or other obstructions while you are working with a power tool. Failure to do so can result in serious personal injury. •...
Page 13: Operating Instructions
OPERATING INSTRUCTIONS Applications This tool is used for removing the old, moldy, mildewed and dirty darkened grout with the pointed and chisel tips provided. It is designed to remove non-sanded or unsanded grout and used on most grout joints that are 1/8 in. or less. Function Description WARNING •...
Page 14 OPERATING INSTRUCTIONS Installing the Tips 1. Unplug power cord (C). Insert hex wrench (H) into setscrew (E) and turn counterclockwise. 2. Choose the tip for the job. Use the pointed tip (G) on cement-based grout joints where grout width is 1/8 in. or less. Use the chisel tip (F) for varying widths of grout, such as those around kitchen sinks and soap...
Page 15 OPERATING INSTRUCTIONS Stroke (SPEED) Adjustment The stroke adjustment dial (B) on the side of the removal tool housing controls the stroke length. 1. To adjust stroke length, turn dial to desired speed. • Low speed (1) is for fine detail and the narrowest of grout widths.
Page 16 OPERATING INSTRUCTIONS 2. Press the On/Off switch (A) to the ON (I) position. Note: DO NOT start removing grout at the joint (the intersection of four tile corners). This may cause tile damage, cracking, or the tile popping out. 3. Initially, run the tool at low speed, applying minimal pressure to remove grout.
Page 17: Care And Maintenance
CARE AND MAINTENANCE WARNING • When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. • To avoid accidents, always disconnect the tool from the power supply before cleaning or performing any maintenance. 1.
Page 18: Troubleshooting
TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-877-876-7562, 8 a.m. - 5 p.m., CST, Monday - Friday. WARNING • Unplug the tool from the power supply before performing troubleshooting procedures. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Grout 1.
Page 19 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Poor 1. Extension cord 1. Use extension cord working too long or heavy enough to carry performance. undersized. the current. 2. Tool stopped 2. Release excessive working. pressure by moving the tool and accessory. 3.
Page 20: Warranty
ONE-YEAR WARRANTY The manufacturer warrants this item against defects in materials and workmanship for one (1) year from the date of purchase. If within this period the product is found to be defective in material or workmanship, the manufacturer will, at its option, repair, replace or refund the original purchase price to the consumer.
