Device Structure; Structure Components - Dahua F Series Quick Start Manual

Dahua HD IR Vandal Proof Network Dome Camera Quick Start Guide

1 Device Structure

1.1 Structure Components

Note:
The following figure is for reference only, which is used to know the components and cable port
function.
There are differences about structure components and cables between different models, please refer
to the actual object for more details.
You can refer to the following figure for component structure. See Figure 1-1.
Please refer to the following sheets for detailed information.
Component
Component 1
Component 2
Figure 1-1 Component structure
Component Name
Dome enclosure
Dome cover
Sheet 1-1
