PRIMERGY PG-RD101 User Manual

Internal data cartridge drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
B7FY-2111-01
内蔵データカートリッジドライブユニット 取扱説明書
Internal Data Cartridge Drive Unit User's Guide
（PG-RD101）
J
E

Advertisement

Table of Contents
loading

Summary of Contents for PRIMERGY PG-RD101

  • Page 1 B7FY-2111-01 内蔵データカートリッジドライブユニット 取扱説明書 Internal Data Cartridge Drive Unit User’s Guide （PG-RD101）...
  • Page 2 はじめに PG-RD101 2007 安全にお使いいただくために 本製品のハイセイフティ用途での使用について...
  • Page 3 本書の表記 ■ 警告表示 警告 注意 ■ 本文中の記号 記号 意味 　　　　　...
  • Page 4 ■ 製品の呼び方 製品名称 本文中の表記 PG-RD101 ® ® Microsoft Windows Server 2003, Standard Edition ® ® Microsoft Windows Server 2003, Enterprise Edition ® ® Windows Server 2003 Microsoft Windows Server 2003 R2, Standard Edition ® ® Microsoft Windows Server 2003 R2, Enterprise Edition ®...
  • Page 5 安全上のご注意 ■ 本製品の取り扱いについて 警告 注意 　　　　　...
  • Page 6 注意 ■ リサイクルについて...
  • Page 7 （ *1） ・ SATA 電源ケーブル （ *1） ・ SATA データケーブル （ *2） ・ 保証書 ・ 取扱説明書（本書） PGBRD101 PG-RD101 SATA SATA Microsoft、Windows、Windows Server は、米国 Microsoft Corporation の米国およびその他の国におけ る登録商標または商標です。 Linux は、Linus Torvalds 氏の米国およびその他の国における登録商標あるいは商標です。 Red Hat および Red Hat をベースとしたすべての商標とロゴは、米国およびその他の国における Red Hat, Inc. の商標または登録商標です。...
  • Page 8 目次 ........
  • Page 9 本製品の特徴 この章では、本製品の特徴について説明します。 サーバ本体への搭載と導入方法 この章では、サーバ本体への搭載方法と導入方法について説明します。 設置環境の確認 サーバ本体への搭載・接続 PRIMERGY TX120 / TX120W 　　1　本製品の特徴　　...
  • Page 11 CD-ROM CD-ROM PUSH CD-ROM PUSH 　　2　サーバ本体への搭載と導入方法　　...
  • Page 13 SATA SATA SATA 　　2　サーバ本体への搭載と導入方法　　...
  • Page 14 SATA SATA ケーブルを挟み込まないように注意してください。 SATA...
  • Page 15 SATA 　　2　サーバ本体への搭載と導入方法　　...
  • Page 16 CD-ROM CD-ROM CD-ROM ケーブルは、必ず同じ場所に接続してください。...
  • Page 17 　　2　サーバ本体への搭載と導入方法　　...
  • Page 18 サーバ本体の BIOS 設定確認および OS の設定 BIOS 設定の確認 2.3.1 BIOS FDD ユニット（USB）を使用する場合や、データカートリッジを入れたまま運用す る場合は、必ず BIOS の確認／設定を行ってください。本設定を行わないと、FDD ユニット（USB）からの起動や、Windows の手動インストール、Windows の自動 システム回復機能（ASR）などで、フロッピーディスクへのアクセスができなくな ります。 POST <F2> BIOS Setup / <F12> BOOT Menu POST BIOS Main Native IDE TANDBERGRDX-(TS) Main Advanced Security Server Exit Item Specific Help System Time: [HH:MM:SS] System Date:...
  • Page 19 Boot Options Enter Boot Options Main Advanced Security Server Exit Boot Options Item Specific Help POST Errors: [Halt On All Errors] Keyboard Check: [Enabled] [Enabled] SM Error Halt: Fast Boot: [Disabled] Quiet Boot: [Disabled] Boot Menu: [Enabled] NumLock: [Auto] MultiBoot for HDs: [Enabled] Boot Sequence Change Values...
  • Page 20 TANDBERGRDX-(TS) TANDBERGRDX-(TS) Space 2. FDD Y-E DATA USB-FDD-(USB 1.1) TANDBERGRDX-(TS) Y-E DATA USB-FDD-(USB 1.1) TANDBERGRDX-(TS) 4. BIOS Main Advanced Security Server Exit Boot Sequence Item Specific Help Boot Sequence: CD-ROM Drive: +Diskette TANDBERGRDX-(TS) +Hard Drive Legacy LAN card Help Change Values Select Item Setup Defaults Exit...
  • Page 21 Main Advanced Security Server Exit Boot Sequence Item Specific Help Boot Sequence: CD-ROM Drive: +Diskette Y-E DATA USB-FDD-(USB 1.1) TANDBERGRDX-(TS) +Hard Drive Legacy LAN card Change Values Help Select Item Setup Defaults Exit Save and Exit Select Menu Enter Select Sub-Menu Windows での設定...
  • Page 22 TANDBERG RDX Serial ATA Controller Intel(R) 82801GB/GR/GH(ICH7 Family) Serial ATA Storage Controller TANDBERG RDX Serial ATA Controller TANDBERG RDX...
  • Page 23 Serial ATA Controller TANDBERG RDX Ultra DMA 　　2　サーバ本体への搭載と導入方法　　...
  • Page 24 Linux での設定 2.3.3 Linux Linux ■ デバイスの確認方法 Linux dmesg "/dev/sdb" ■ データカートリッジのフォーマット NTFS Linux mkfs mkfs ext3 mkfs fdisk fdisk fdisk Linux Windows Linux Windows...
  • Page 25 ■ 自動マウントの設定方法 /etc/fstab /etc/fstab /etc/fstab media/rdx mkdir /etc/fstab mount mount 　　2　サーバ本体への搭載と導入方法　　...
  • Page 26 各部の名称と働き この章では、本製品の各部の名称と働きについて説明しています。 フロントパネルおよびコネクタ 本製品前面 3.1.1...
  • Page 27 ■ イジェクトボタン／ユニットインジケータ ■ 緊急取り出し穴 本製品に電源が入っているときには、緊急取り出し穴を使用してデータカートリッ ジを排出しないでください。OS ／バックアップソフトウェアのエラーや、データ カートリッジ内のデータが破損することがあります。 ■ カートリッジインジケータ 　　3　各部の名称と働き　　...
  • Page 28 本製品背面 3.1.2 SATA ■ SATA コネクタ SATA SATA データカートリッジのセット／取り出し P.30 ■ セット方法 ［本製品］ カートリッジインジケータ ［データカートリッジ］...
  • Page 29 ■ 取り出し方法 - Windows Windows Server 2003 を使用する場合、Administrator 権限がないとカート リッジの排出やフォーマットを行えません。 Administrator 権限がないユーザで排出やフォーマットを行う場合は、 「・ セキュリティポリシーの変更について」 （→ P.32）を照参し、設定変更を 行ってください。 - Linux 2. unmount eject /dev/sdb1 * /dev/sdb1 * /media/rdx * /dev/sdb1 　　3　各部の名称と働き　　...
  • Page 30 データカートリッジについて この章では、本製品で使用できるデータカートリッジについて説明しています。 使用できるデータカートリッジ （*） 品名 商品番号 記憶容量 備考 0162110 40GB データカートリッジディスク RD 40GB NTFS フォーマット 0162120 80GB データカートリッジディスク RD 80GB NTFS フォーマット 0162130 120GB データカートリッジディスク RD 120GB NTFS フォーマット *：1GB=1000 × 1000 × 1000byte 換算。未フォーマット時の容量です。 実際にバックアップできる容量は、この値よりも少なくなります。 : 0120-505-279 9:00 17:30 データカートリッジは消耗品です。購入後...
  • Page 31 データの書き込み保護 　　4　データカートリッジについて　　...
  • Page 32 バックアップ運用上の注意 この章では、本製品のバックアップ運用上の注意事項について説明しています。 ■ 全般 Windows Backup Windows Backup Windows Windows Server 2003 Administrator Administrator...

  • Page 33: Windows Backup

    」 Administrators Administrators Power User Power Users Administrators Interactive Users ■ Windows Backup Windows Backup 11MB/s Windows Backup 　　5　バックアップ運用上の注意　　...
  • Page 34 トラブルシューティング 本製品が正常に動作しない場合の対処方法について説明します。 3.1.1 P.26 SATA SATA BIOS SATA SATA BIOS BIOS...
  • Page 35 Windows 2.3.2 Windows P.21 2.3.1 BIOS P.18 BIOS 　　6　トラブルシューティング　　...
  • Page 36 仕様 この章では、本製品の仕様と設置環境を示しています。 仕様 PG-RD101 （*1） 40GB / 80GB / 120GB （*2） 25MB/s SATA 41.3 408g 16.35kJ/h *1 1GB=1000 1000 1000byte *2 1MB=1000 1000byte...

  • Page 37: Before Reading This Manual

    Before Reading This Manual Thank you for purchasing the Fujitsu Internal Data Cartridge Drive Unit (PG-RD101). This manual explains the basic usage of the Internal Data Cartridge Drive Unit (hereafter referred to as "this product"). Before using this product, read this manual in order to ensure proper use.
  • Page 38 Remarks Warning Descriptions Various symbols are used throughout this manual. These are provided to emphasize important points for your safety and that of others. The symbols and their meanings are as follows. Make sure to fully understand these before reading this manual. Ignoring this symbol could be potentially lethal.
  • Page 39 Abbreviations The following expressions and abbreviations are used to describe the product names used in this manual. Product names Expressions and abbreviations Internal Data Cartridge Drive Unit (PG-RD101) This product ® ® Microsoft Windows Server 2003, Standard Edition ® ®...
  • Page 40 Safety For safe use of this product, it is vital that the following warnings are heeded. Handling this product WARNING • Keep the plastic bags used as packing, out of the reach of children. They could cause suffocation. • If a foreign object (water, pieces of metal, liquid) falls into this product, immediately turn off the power and unplug it from the power source.
  • Page 41 CAUTION • Do not disassemble, or take this product apart. • Do not operate or store this product in the following environments. - Areas of extremely low temperature - Areas of extremely high temperature or humidity - Areas that experience extreme temperature changes - Areas exposed to magnetic fields - Areas exposed to shocks or vibration - Dusty or dirty areas (cigarette smoke, emissions)
  • Page 42 Checking the Items Supplied Before using the product, check that no supplied or attached items are missing. If any items are missing, contact an office listed in "Appendix A Contact Information" ( pg.72). • Internal Data Cartridge Drive Unit (this product) •...

  • Page 43: Table Of Contents

    Contents 1 Feature ......... . . 2 How to Install and Introduce this Product to a Server .

  • Page 44: Feature

    Installing and Connecting this Product to the Server Turn off the server (PRIMERGY TX120/TX120W) and connected devices, and unplug all power cables from the outlet. Remove the cover of the server. 1. Remove the foot stands and lay the server with the rubber feet down.
  • Page 45 2. Slide the cover toward you (towards the front cover), while pushing the lock button on the upper side of the server (1), and then lift up the cover to remove it. Remove a reinforcing bar. After lifting up (1) and disconnecting, pull (2) towards the rear and remove. Reinforcing bar 2 How to Install and Introduce this Product to a Server...
  • Page 46 Remove the internal hard disk drive bay / internal CD-ROM drive bay. 1. Remove all cables connected to the internal hard disk drive bay / internal CD- ROM drive bay. SAS connector 1 SAS connector 2 Power cable SAS cable 2 SAS cable 1 Power cable IDE cable...
  • Page 47 Remove the cover of the optional bay. Insert your fingers into two holes of the cover and pull the cover towards you to remove it. The cover of the optional bay Remove the power cables connected to the baseboard 24 pin ATX power connector and 4 pin ATX power connector (1), and pull the power unit up slightly (2).
  • Page 48 Connect the SATA cable included with this product to the baseboard SATA connector. SATA connector USB connector Floppy disk connector Front Rear Return the power unit to its original position, and reconnect the power cables to the baseboard 24 pin ATX power connector and 4 pin ATX power connector.
  • Page 49 Partially insert this product into the server option bay (1), and connect the SATA data cable and SATA power cable to the rear of this product (2). [Rear of this product] Insert this product fully into the server bay. Be careful not to pinch or catch any cables. Connect the power cable for the server internal option to the SATA power cable connected to this product.
  • Page 50 1. Open the clips which bound the cables in the server. Clip 2. Connect a SATA cable which connected this product and an optional power cable of the server. SATA data cable SATA connector This product SATA power cable Power supply unit Power cable for internal options...
  • Page 51 Install the internal hard disk drive bay/internal CD-ROM drive bay. Put the projections on the bottom face of the internal hard disk drive bay / internal CD-ROM drive bay to the holes of the optional bay, and slide it to be fixed. Internal hard disk drive bay / internal CD-ROM drive bay [The bottom face] Projection...
  • Page 52 Remove the optional bay panel from the cover of the server. Take off the tab inside of the panel to remove it. Cover of the server Optional bay panel Attach the cover of the server.

  • Page 53: Checking The Bios And Os Settings Of The Server

    Checking the BIOS and OS Settings of the Server 2.3.1 Checking the BIOS Settings The following shows how to check the BIOS settings. Make sure to check and set the BIOS settings when using an FDD unit (USB) or operating with a data cartridge inserted. If these settings are not performed, floppy disk access will not be possible when booting from the FDD unit (USB), manually installing Windows, or performing Windows Automatic System Recovery (ASR) function.
  • Page 54 Select "Boot Options" and press the [Enter] key. The Boot Options sub menu is displayed. Main Advanced Security Server Exit Boot Options Item Specific Help POST Errors: [Halt On All Errors] Keyboard Check: [Enabled] SM Error Halt: [Enabled] Fast Boot: [Disabled] Quiet Boot: [Disabled]...
  • Page 55 Check that booting from this product is disabled, and the FDD unit (USB) is prioritized before this product (when an FDD unit (USB) is connected). 1. Check if "!" is displayed in front of "TANDBERGRDX-(TS)". If "!" is not displayed, perform the following operation to display it. 1.
  • Page 56 • When an FDD unit (USB) is connected: Main Advanced Security Server Exit Boot Sequence Item Specific Help Boot Sequence: CD-ROM Drive: +Diskette Y-E DATA USB-FDD-(USB 1.1) TANDBERGRDX-(TS) +Hard Drive Legacy LAN card Change Values Help Select Item Setup Defaults Exit Save and Exit Select Menu...
  • Page 57 Right click "TANDBERG RDX", and select Properties. The next diagram shows an example where the "TANDBERG RDX" is added under the Serial ATA Controller "Intel(R) 82801GB/GR/GH (ICH7 Family) Serial ATA Storage Controller". Intel(R) 82801GB/ GR/ GH (ICH7 Family) Serial ATA Storage Controller Secondary IDE Channel Primary IDE Channel TANDBERG RDX...
  • Page 58 Change "Transfer Mode" of "Device 1"(Located in the "Number 1" checked in Step 6) in the "Advanced Settings" tab from "PIO Only" to "DMA if available" and click [OK]. It is not necessary to restart after setting changes are complete. Right click the IDE channel where the "TANDBERG RDX"...
  • Page 59 2.3.3 Settings for Linux This product is recognized as a removable disk in Linux. The following shows how to check and set this product in Linux. How to check the device When this product is recognized in Linux, the following logging message is output at OS startup. Use the "dmesg"...
  • Page 60 • Setting example of "/etc/fstab" ../dev/sdb1 /media/rdx auto pamconsole,exec,noauto,managed 0 0 ..When not using the automount, mount manually using the "mount" command after inserting the data cartridge. The following shows an example of the "mount" command execution when mounting manually. # mount -t ext3 /dev/sdb1 /media/rdx...

  • Page 61: Component Names And Functions

    Component Names and Func- tions This chapter explains the component names and functions of this product. Front Panel and Connector 3.1.1 Front View The front view of this product is as follows. Forced ejection hole Eject button/Unit indicator * This is both the eject button and the unit indicator. [When a data cartridge is inserted in this product] Cartridge indicator 3 Component Names and Functions...
  • Page 62 Eject button/Unit Indicator Press this button when ejecting the data cartridge from this product. Normally, do not use this button, eject using the software. The unit indicator shows this product's status. Display Status Power is not supplied to this product. Solid Green Power is supplied, and this product can be used.

  • Page 63: Inserting/Ejecting The Data Cartridge

    3.1.2 Rear View The rear view of this product is as follows. SATA connector SATA connector Connect the SATA data cable and SATA power cable included with this product. Inserting/Ejecting the Data Cartridge To handle the data cartridge properly, refer to "4 About the Data Cartridge" ( pg.65). How to insert With this product on it’s side, insert the data cartridge slowly into this product with the cartridge indi- cator down and the label panel facing you.
  • Page 64 How to eject • When the power of this product is turned on Normally, do not use the eject button to eject, use the OS or backup software to eject. - Ejecting using Windows 1. Right click this product in Explorer. 2.

  • Page 65: About The Data Cartridge

    About the Data Cartridge This chapter explains the data cartridge used for this product. Data Cartridges That can be Used Use a data cartridge made for TANDBERG DATA's RDX QuikStor. The data cartridge is a replaceable part. Replace 5 years after purchase to ensure safety.

  • Page 66: Data Write Protection

    Data Write Protection To make the data cartridge write-protected, slide the write-protect switch to the left. Write-protect Write protect switch...

  • Page 67: Cautions Concerning Backup

    Cautions Concerning Backup This chapter explains the points to note about backup operations for this product. General • This product and the data cartridge is a device to backup a server's hard disk. If this device is used as a hard disk for a server, the data cartridge may fail or be damaged and data may be lost. •...
  • Page 68 5. Select the privileges setting from the [Local Security] tab drop-down list. The privileges setting can be selected from the following three types. Contents Description Administrators Only administrators can eject removable media. Administrators and Administrators and Power users can eject removable media. Power Users Administrators and All users can eject removable media.

  • Page 69: Troubleshooting

    Troubleshooting This chapter explains troubleshooting methods when this product is not operating correctly. If the problem is not resolved after using these methods, contact an office listed in "Appendix A Contact Information" ( pg.72). For information on the unit indicator and cartridge indicator status refer to "3.1.1 Front View" ( pg.61).
  • Page 70 Phenomenon Solution Data cartridge cannot be inserted. • Check if there is a foreign object blocking the car- tridge inserting. • Check if the data cartridge is damaged. Data transfer rate is very low. If using Windows refer to "2.3.2 Settings for Windows"...

  • Page 71: Specifications

    Specifications This chapter explains the specifications for this product. Item Functions and Specifications Product name Internal Data Cartridge Drive Unit Product ID PG-RD101 Data storage capacity 40GB/80GB/120GB Data transfer rate Maximum 25MB/s Interface SATA Width 102 × Height 41.3 × Depth 160...

  • Page 72: Appendix A Contact Information

    Contact Appendix A Information • Australia: Fujitsu Australia Limited Tel: +61-2-9776-4555 Fax: +61-2-9776-4556 Address: 2 Julius Avenue (Cnr Delhi Road) North Ryde, Australia N.S.W. 2113 • China: Fujitsu (China) Holdings Co., Ltd. Tel: +86-21-5292-9889 Fax: +86-21-5292-9566 Address: 18F, Citic Square, 1168 West Nanjing Road Shanghai, China 200041 •...
  • Page 73 Address: Unit 802-8th floor, Fortuna Tower Hanoi 6B Lang ha Street, Ba dinh District, Hanoi Socialist Republic of Vietnam • United States: Fujitsu Computer Systems Corporation Tel: +1-800-831-3183 Fax: +1-408-496-0575 Address: 1250 East Arques Avenue, Sunnyvale, CA USA 94088-3470 For the latest information, refer to the Fujitsu PRIMERGY website (http://primergy.fujitsu.com). Appendix A Contact Information...
  • Page 75 PRIMERGY 内蔵データカートリッジドライブユニット （PG-RD101） 取扱説明書 Internal Data Cartridge Drive Unit (PG-RD101) User’s Guide B7FY-2111-01-00 発 行 日 2007 年 7 月 富士通株式会社 発行責任 Issued on July, 2007 Issued by FUJITSU LIMITED Printed in Japan ● 本書の内容は、改善のため事前連絡なしに変更することがあります。 ● 本書に記載されたデータの使用に起因する、 第三者の特許権およびその他の 権利の侵害については、当社はその責を負いません。 ● 無断転載を禁じます。...
