P-K DURATION II™
D2DW-30(S/D) & D2DW-80(S/D)
(S-Simplex D-Duplex)
INSTANTANEOUS INDIRECT
DOMESTIC HOT WATER SYSTEM
Model #:_______
Start-Up Date:
_______________________
Harsco Industrial, Patterson-Kelley
155 Burson Street
East Stroudsburg, PA 18301
Telephone: 570.476.7261
Toll Free: 877.728.5351
Facsimile: 570.476.7247
www.harscopk.com
©2015 Harsco Industrial, Patterson-Kelley
Printed: 11/11/2015
Serial #______________________
P-K Duration II D2DW-30&D2DW-80
Rev. 1.00 (10/1/2015)
PN: 1004905970
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harsco Industrial P-K DURATION II D2DW-30(S/D)
Summary of Contents for Harsco Industrial P-K DURATION II D2DW-30(S/D)
-
Page 1: Domestic Hot Water System
(S-Simplex D-Duplex) INSTANTANEOUS INDIRECT DOMESTIC HOT WATER SYSTEM Model #:_______ Serial #______________________ Start-Up Date: _______________________ Harsco Industrial, Patterson-Kelley 155 Burson Street East Stroudsburg, PA 18301 Telephone: 570.476.7261 Toll Free: 877.728.5351 Facsimile: 570.476.7247 www.harscopk.com ©2015 Harsco Industrial, Patterson-Kelley PN: 1004905970 Printed: 11/11/2015... - Page 2 P-K DURATION II ™ Indirect Domestic Water Heating System...
-
Page 3: Table Of Contents
P-K DURATION II ™ Indirect Domestic Water Heating System ..INTRODUCTION ..............................4 ..SAFETY ................................4 2.1 General ............................. 4 2.2 Training ............................. 5 2.3 Safety Features ..........................5 2.4 Safety Labels ............................ 5 2.5 Safety Precautions ........................... 6 .. -
Page 4: Introduction
If you have any questions on the information contained within, or do not fully and completely understand the content, please contact Harsco Industrial, Patterson-Kelley Technical Service at 570.476.7261 or toll free at 877.728.5351. -
Page 5: Training
If any of the provisions of this manual are not fully and completely understood, contact Harsco Industrial, Patterson-Kelley Technical Service at 570.476.7261 or toll free at 877.728.5351. AFETY... -
Page 6: Safety Precautions
P-K DURATION II ™ Indirect Domestic Water Heating System AFETY RECAUTIONS Provide a suitable location for the P-K Duration II system, away from normal personnel traffic, with adequate working space, adequate clearances, proper ventilation and lighting, with a structure sufficiently strong and rigid to support the weight of the P-K Duration II system, all piping, and accessories. -
Page 7: Installation
P-K DURATION II ™ Indirect Domestic Water Heating System 2.5.4 Chemical Hazards • Chemical hazards from cleaning products. Use caution when cleaning the system. The use of professional assistance is recommended. Use safe procedures for the disposal of all cleaning solutions. General Warning 2.5.5 Pressure Hazards... -
Page 8: Compliance With Codes
P-K DURATION II ™ Indirect Domestic Water Heating System OMPLIANCE WITH ODES The brazed plate heat exchanger is constructed and stamped in accordance with ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 for 219 psig maximum operating pressure. However, certain components in the domestic piping have a maximum pressure rating of 150 psig. -
Page 9: Mechanical Connections
P-K DURATION II ™ Indirect Domestic Water Heating System ECHANICAL ONNECTIONS The P-K Duration II system is designed to provide substantial domestic hot water capacity in a 32” wide x 64” long footprint and requires four (4) piping connections to operate as seen below: A. - Page 10 P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.2 Boiler Piping (Simplified) The energy source for the P-K Duration II system is hot boiler water from the hydronic system and is regulated by an electronic control valve. By default, this control valve is setup to operate as a 3-way valve since this is the recommended and preferred operating method.
- Page 11 P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.3 Boiler Water Manifold Piping (Duplex Only) The Duration II Duplex unit is equipped with a Boiler Water Manifold to allow for easy installation. Below is an image which shows the manifold. The Boiler water is piped to each heat exchanger from one connection point, limiting the requirement for multiple connections, provided the same boiler water is required to feed both heat exchangers.
- Page 12 P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.4 Domestic Water Piping (Simplified) The P-K Duration II system features constant recirculation on the domestic hot water piping. This circulation pump offers 3-speed operation that can be selected by the operator. Constant circulation on the domestic hot water side offers several advantages: ...
- Page 13 P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.5 Example Domestic Hot Water Installation It is important to note that the P-K Duration II indirect domestic water heating system does not require a domestic water storage tank, if hot water is constantly available for the 3-way valve. If using in conjunction with a boiler, the initial call for heat takes time until the boiler operates at maximum power.
- Page 14 P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.6 Relief Valve Discharge Piping The Pressure Only relief valve discharge pipe is routed towards the floor. Refer to your local code enforcement to ensure compliance with relief valve discharge piping. DO NOT connect any valves in the relief valve discharge piping.
-
Page 15: Electrical Connections
P-K DURATION II ™ Indirect Domestic Water Heating System 3.4.8 Filling the DHW System Before filling the system, ensure all the mechanical connections are complete. STEP 1 – Connect a hose to the drain valve on the domestic water outlet line. ... -
Page 16: Pre-Start Check List
P-K DURATION II ™ Indirect Domestic Water Heating System Connect BMS system to LOVE controller on terminals 9 (Data -) and 10 (Data +). For connecting the Protocol Convertor to the system, please refer to the ProtoNode Startup Guide. TART HECK Before attempting to start the P-K Duration II system, ensure the following items have been completed. -
Page 17: Operation
P-K DURATION II ™ Indirect Domestic Water Heating System 4 OPERATION LOVE C ONTROLLER Read instructions and understand operation before operating or making adjustments to the digital temperature controller. A digital temperature controller (right) positions the valve in response to outlet water temperature. A 4-20 milliamp signal drives the valve actuator. -
Page 18: Setup Of The Electric Valve
P-K DURATION II ™ Indirect Domestic Water Heating System ETUP OF THE LECTRIC ALVE The valve should open when the hot water demand increases and close when the hot water demand decreases. If power is removed, the valve should fail in the closed position. This must be verified prior to putting the unit in service. -
Page 19: Maintenance
P-K DURATION II ™ Indirect Domestic Water Heating System 5 MAINTENANCE AINTENANCE AND NSPECTION CHEDULE Proper lockout/ tag out procedure must be employed when servicing this unit. Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Determine the cause of any lockout or errors before resetting the boiler. - Page 20 P-K DURATION II ™ Indirect Domestic Water Heating System 5.2.2 Circulation Pump Cavitation Cavitation occurs when the water pressure at the suction side of the pump is below the pump’s required suction head pressure. Ensure that any isolation valves on the suction side of both circulation pumps are OPEN. Also, ensure that there is a sufficient static fill pressure of the system.
-
Page 21: Parts/Technical Support
(877) 728-5351. The fax number is (570) 476-7247. Refer to the parts list shown on the assembly drawing provided in this manual. Technical information is also available at the above number and at the Harsco Industrial, Patterson-Kelly website www.harscopk.com. RECCOMENDED SPARE PARTS ... -
Page 22: Wiring Diagram
P-K DURATION II ™ Indirect Domestic Water Heating System IRING IAGRAM... -
Page 23: Models
P-K DURATION II ™ Indirect Domestic Water Heating System ODELS 6.3.1 Boiler Piping CALLOUT TAG PART DESCRIPTION 3-WAY ELECTRONIC CONTROL VALVE 2” BALL VALVE WYE - STRAINER STRAINER BLOW DOWN VALVE... - Page 24 P-K DURATION II ™ Indirect Domestic Water Heating System 6.3.2 DHW Piping Tag Number Part Description Wye-Strainer - 2” Pressure Gauge XX-XX PSI Temperature Gauge XXF – XXF Automatic Air Vent Section VIII Pressure Only Relief Valve 2” Ball Valves Wye-Strainer Blow Down Valve Recirculation Pump Manual Reset High Limit...
- Page 25 P-K DURATION II ™ Indirect Domestic Water Heating System 6.3.3 Control Panel and Heat Exchanger PART NUMBER DESCRIPTION POWER LIGHT HIGH LIMIT LIGHT DISCONNECT SWITCH TEMPERATURE CONTROLLER FUSES HEAT EXCHANGER...
- Page 26 Buyer’s sole risk and cost. This warranty applies only if the original installer and Seller (Attention: Harsco Industrial, Patterson-Kelley, 155 Burson Street, East Stroudsburg, PA 18301) receive, within the Warranty Period, an immediate written notice, providing a detailed description of all claimed defects, upon discovery of such defects together with proof of purchase (invoice or Order Acknowledgment) and a copy of the start-up report for the affected product.
- Page 27 P-K DURATION II ™ Indirect Domestic Water Heating System (D) the suitability of any product for any particular application; (E) the design or operation of owner’s plant or equipment or of any facility or system of which any product may be made a part; (F) any damage to the product due to abrasion, erosion, corrosion, deterioration, abnormal temperatures or the influence of foreign matter or energy;...
- Page 28 P-K DURATION II ™ Indirect Domestic Water Heating System...
