Team C TS2 Manual page 8

7
Turnbuckle
T02029
T02029 4.8mm Ball End-Long TG2024 3x68 Turnbuckle
............8
8
Front Suspension
T02093
Ball stud sponge
9
Front Suspension
T02082 M3x22
T02063
True-to -scale diagram
1:1
TG2024
T02029
T02093
Ball stud sponge
T02092
Ball stud sponge
T02092
Ball stud sponge
TG2005
T02082 M3x10
Assemble as many times as specified
x1
Projection.Note direction
approx.51mm
Projection.Note direction
approx.51mm
Projection.Note direction
approx.46mm
......4
T02082 M3x10 Screw T02082 M3x22 Screw
......4
4
Front Upper-Left
x1
Front Upper-Right
x1
Steering Tip
x2
T02093
Ball stud sponge
T02093
T02093
Ball stud sponge
Ball stud sponge
T02063 5mm Ball stud
...2 ........................2
1:1
1:1
1:1
