Quick guide to creating a new installation

When creating a new DDX installation there are various configuration tasks that need to be completed
within DDX Matrix. This page provides a recommended 'to do list' of the stages that you need to perform.
Primary tasks
• Configure the networking details for the DDX switch
• Ensure that the EDID definitions are appropriate for your installation
If additional EDID definitions are required for your installation, you can clone new
definitions from connected video displays and add these to the list of available definitions
• Add the required consoles (either before or after they are connected)
By default the DDX switch provides 20 computer ports along its rear panel and
10 user ports along its front panel. If necessary, these standard arrangements can be
changed to suit your installation.
• Determine the access permissions for each console
• Add your computers (either before or after they are connected)
• Add the users and define their login details
Secondary tasks
• Optionally make changes to the OSD settings
• Add description and location details for the switch
See Configure > Central Switch > Network
See Configure > Central Switch > Manage EDIDs
See Add EDID
See Configure > Consoles
See Reallocating ports
See Access permissions
See Configure > Computers
See The Users Page
See Configure > Central Switch > OSD Settings
See Configure > Central Switch > General
