2.6 Onboard Headers and Connectors

2.6 Onboard Headers and Connectors 2.6 Onboard Headers and Connectors
2.6 Onboard Headers and Connectors 2.6 Onboard Headers and Connectors
Onboard headers and connectors are NOT jumpers. Do NOT place jumper
caps over these headers and connectors. Placing jumper caps over the
headers and connectors will cause permanent damage of the
motherboard!
Primary IDE Connector
(43-pin IDE1, see p.10/11 No. 5)
Serial ATAII Connectors
(SATAII_1: see p.9/10, No. 8)
(SATAII_2: see p.9/10, No. 7)
(SATAII_3: see p.9/10, No. 9)
(SATAII_4: see p.9/10, No. 6)
Serial ATA (SATA)
Data Cable
(Optional)
USB 2.0 Headers
(9-pin USB6_7)
(see p.9/10 No. 12)
(9-pin USB4_5)
(see p.9/10 No. 13)
System Panel Header
(9-pin PANEL1)
(see p.9/10 No. 11)
IDE1
PIN1
These Serial ATAII (SATEII)
connectors support SATAII
or SATA hard disk for internal
storage devices. The current
SATAII interface allows up to
3.0 Gb/s data transfer rate.
Either end of the SATA data cable
can be connected to the SATA /
SATAII hard disk or the SATAII
connector on the motherboard.
Besides two default USB 2.0
USB_PWR
P-7
ports on the I/O panel, there are
P+7
GND
DUMMY
two USB 2.0 headers on this
motherboard. Each USB 2.0
1
GND
header can support two USB
P+6
P-6
USB_PWR 2.0 ports.
USB_PWR
P-5
P+5
GND
DUMMY
1
GND
P+4
P-4
USB_PWR
PLED+
This header accommodates
PLED-
PWRBTN#
several system front panel
GND
functions.
1
DUMMY
RESET#
GND
HDLED-
HDLED+
