Configuring settings from smartphones and tablet PCs
Configuring settings from smartphones and tablet PCs
Setting this product in router mode
This explanation uses an Android terminal.
Operating environment:
・ Android OS 4.0 or later • iOS 8.0 or later
・ Windows XP (SP3 or later)/Vista (SP2 or later)/7 (SP1 or later)/8/8.1/10/RT
・ This product only supports Mac OS X 10.9 or later (only devices that are equipped with an Intel CPU).
Establishing a connection using simple setup
Search for [SkyLink Manager] in the
"Google Play store," and then install this
application.
On your terminal's home
screen, tap the [SkyLink
Manager] icon.
Read the end-user
license agreement, and
then tap "同意" if you
have no problems with
the agreement.
Tap "スカイ リンクセッ トアップ"
on the menu.
Tap "簡単設定."
Setup will start after the
prologue movie.
The application searches
for the SSID for use in
configuring the settings.
Wait until the detection is
finished.
*It may take approximately 3
minutes to search for the SSID.
*A model number differing from that
of this product may be displayed.
*If the SSID is not detected, the
screen on the right will be
displayed. Press the WPS button
for approximately 5 seconds. The
application will detect the router
and retrieve the connection
profile. The profile will be installed
automatically after it is retrieved.
After the profile
installation is finished,
tap "次へ."
If the message "インター
ネッ トが検出されませんでし
た" is displayed, tap "手
動設定" to configure the
settings.
Enter the user name and
password that you have
received from your provid-
er, and then tap "次へ"
* You can enter numbers, alphabet
characters, "-" (hyphen), and "_"
(underscore) for the user name and
password in the provider information.
* If you are using a DHCP connec-
tion, tap "次へ" without entering the
user name and password.
WRC-GHBK Series /WRC-FEBK-A Series Setup Guide November 16, 2015, Version 2 ©2015 ELECOM CO., LTD. ALL RIGHTS RESERVED.
* We recommend that you turn the Bluetooth function off in order to prevent radio wave interference.
* In order to install [SkyLink Manager], you require an environment in which you can connect to the Internet.
* Perform SkyLink setup within 10 minutes of connecting the AC adapter.
"Simple Setup" is a method of configuring the settings that enables the user to do so by
following configuration movies. "Simple Setup" is easy to use even for first-time users.
* The movies will not be displayed on smartphones that are not receiving radio waves or if you have not yet
signed a contract with your smartphone's service provider.
Check the simple SSID
information on the screen,
view the movie, and then tap
"次へ."
Check the wireless LAN
smooth navigation informa-
tion on the screen, view
the movie, and then
tap "次へ."
Set the main SSID. If you
will set wireless LAN
smooth navigation,
select the check box. To
set simple SSID,
tap      
.
When you tap this
button, the SSID, pass-
word, and authentication
method are created
automatically.
By setting SSIDs by yourself, you
can prevent virus infections and
unauthorized use in advance!
◆ The main SSID is the one for the
network normally used by your
family!
◆ The guest SSID is the one for the
network used by your friends when
they come to visit!
◆ From the viewpoint of security, we
recommend that you select "WPA2"
for the authentication method!
* Set the authentication method to "WEP"
when you are using old models of the
Nintendo DS and the PlayStation Portable.
* When manually entering the SSID and
password, you can enter numbers, alphabet
characters, "-" (hyphen), and "_"
(underscore).
Set the guest SSID. To use the
guest wireless LAN, select the "
ゲス ト無線LANを使う" check box,
and then configure the settings.
The same as for the main SSID,
if you will set wireless LAN
smooth navigation, select the
check box. If you do not require
a guest SSID, tap "ゲス ト不要は次へ"
or "次へ."
* Even if you enter the guest SSID and password, they
will be cleared if you tap "ゲス ト不要は次へ."
Configure the administra-
tor account settings.
Enter the user name
and password, and then
tap "次へ"
Ensure that the administrator
sets the ユーザー名(User name)
and "パスワー ド(Password)" so that
it is not possible for an
unauthorized individual to
connect to your network and
change the settings!
* You can set the user name and password to
elecom123(入力例)
any values that you wish.
123elecom(入力例)
* You can enter numbers, alphabet
characters, "-" (hyphen), and "_"
(underscore) for the administrator account's
user name and password.
If you are using the
website filters of Child
Net Timer 2, set the filter
function to "ON," and
then enter the license
key. After you enter the
settings, tap "次へ"
• After you finish configuring the
settings in router mode, see "
(12) Supplement: Using the
Child Net Timer 2 Function."
Check the registered details. If there
are no problems, tap "次へ"
ネットワークの設定情報が
ここに表示されます。
The router restarts in order to apply
the settings. After the settings are
saved on the router, tap "次へ."
This screen provides details for the
support services. Tap "次へ"
This completes the
setup procedure.
Tap "終了"
Select the name of a
device that has been
set, and then tap
xx:xx:xx:xx:xx:xx
"OK."
Open a web browser.
●If you can connect to the
Internet, the settings are
complete.
