Configuring settings from smartphones and tablet PCs Configuring settings from smartphones and tablet PCs Configuring settings from smartphones and tablet PCs
Setting this product in router mode
This explanation uses an Android terminal.
■Operating environment:
• Android OS 2.3 to 5.0 • iOS 4.0 or later
• Windows XP (SP3 or later)/Vista (SP2 or later)/7 (SP1 or later)/8/8.1
• This product only supports Mac OS X 10.6 or later
(only devices that are equipped with an Intel CPU).
Establishing a connection using simple setup
Search for [SkyLink Manager] in the
"Google Play store," and then install this
application.
On your terminal's home screen, tap the
[SkyLink Manager] icon.
R e a d t h e e n d - u s e r
license agreement, and
then t ap "同意" if y ou
have no problems with
the agreement.
Tap "スカイ リ ンクセッ トアップ"
on the menu.
Tap "簡単設定."
Setup will start after the
prologue movie.
The application search-
es for the SSID for use
in configuring the set-
tings. Wait until the de-
tection is finished.
* It may take approxi-
m a t e l y 3 m i n u t e s t o
search for the SSID.
* If the SSID is not detected,
the screen on the right will
be displayed. Press the WPS
button for approximately 5
seconds. The application will
d e t e c t t h e r o u t e r a n d
retrieve the connection pro-
fi l e . T h e p r o fi l e w i l l b e
installed automatically after
it is retrieved.
After the profile instal-
lation is finished, tap
"次へ."
If the message "インターネッ トが検出され
ませんでした" is displayed, tap "手動設定"
to configure the settings.
* We recommend that you turn the Bluetooth
function off in order to prevent radio wave
interference.
* In order to install [SkyLink Manager], you
require an environment in which you can
connect to the Internet.
* Perform SkyLink setup within 10 minutes
of connecting the AC adapter.
"Simple Setup" is a method of configuring the settings that enables the user to do so by
following configuration movies. "Simple Setup" is easy to use even for first-time users.
* The movies will not be displayed on smartphones that are not receiving radio waves or if you have not yet
signed a contract with your smartphone's service provider.
Enter the user name
and password that you
have received from
y our pr o vider, and
then tap "次へ"
* If you are using a DHCP
connection, tap "次へ" with-
out entering the user name
and password.
Configure the main SSID
settings.Enter the SSID
name and password, and
then select the authenti-
cation method. After you
enter the settings, tap
" 次 へ ."
* Write these settings on the included
setup information sheet, and then
store this in a safe location.
By setting SSIDs by yourself,
you can prevent virus infections
a n d u n a u t h o r i z e d u s e i n
advance!
◆ The main SSID is the one for the
network normally used by your family!
◆ The guest SSID is the one for the
network used by your friends when
they come to visit!
◆ From the viewpoint of security, we
recommend that you select "WPA2" for
the authentication method!
* Set the authentication method to
"WEP" when you are using old models
of the Nintendo DS and the PlayStation
Portable.
If you clear the "2.4GHz/5GHzのSSIDを同じにする。 "
check box, you can set different SSID names, pass-
words, and authentication methods for 2.4 GHz
and 5 GHz.
Configure the guest
SSID settings.
Enter the SSID name
and password, select
t h e a u t h e n t i c a t i o n
method, and then tap
"次へ"
Configure the adminis-
trator account settings.
Enter the user name
and pass w or d, and
then tap "次へ"
Ensure that the administrator
sets the "ユーザー名(User name)"
and "パスワー ド(Password)" so
that it is not possible for an
unauthorized individual to
connect to your network and
change the settings!
* You can set the user name
and password to any values
that you wish.
If you are using the
website filters of Child
Net Timer 2, set the
filter function to "ON,"
a n d t h e n e n t e r t h e
license key. After you
enter the settings, tap
"次へ"
セッ トア ッ プガイ ド （英語版） 2015年8月5日
Q & A
WRC-1900GHBK-A, WRC-1467GHBK-A,
WRC-600GHBK-A support website
http://www.elecom.co.jp/rd/elesup/034.html
Check the registered details. If there are no
problems, tap "次へ"
When this screen is
displayed, the settings
have been saved. Tap
"次へ"
This screen provides details for the
support services. Tap "次へ"
This completes the
s e t u p p r o c e d u r e .
Tap "終了"
Select the name of a
device that has been
s e t , a n d t h e n t a p
"OK."
Open a web browser.
●If you can connect to the
Internet, the settings are
complete.
