nest Learning Thermostat Installation Manual page 6

8. Attach the Nest base
Pull the wires through the center of the base,
then attach it to the wall with the screws.
10. Attach the display
Press the display onto the base until it clicks.
064-00011-ES_16_InstallGuideENGLISH.indd 8-9
9. Connect wires
After all the wires are securely connected,
push them down to make sure they're flush
with the base.
3/8 in
The exposed wire should be straight.
11. Switch the power back on
Breaker box Switch
12. Setup and Nest Account
The Nest Thermostat will turn on and walk
you through setup. Just turn the ring and
press to select. During setup, you can connect
the thermostat to Wi-Fi.
Go to nest.com/account or download the
Nest app to create a Nest Account.
The app will show you how to connect your
Nest Account and thermostat.
Remember, you can download the free Nest app from the iTunes App Store
Questions about adding a thermostat to your Nest Account? Visit
or Google Play .
™ ™
nest.com/pair
