  • Page 1

    NCL-DS Series NCL-DS NCL-DS NCL-DS NCL-DS NCL-DS NCL-D NCL-D NCL-D NCL-D NCL-D NCL-DR1 NCL-DR1 NCL-DR1 NCL-DR1 NCL-DR1...

  • Page 2

    Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Welcome! ... 1-1 Package contents ... 1-1 Special features ... 1-2 1.3.1 Product highlights ... 1-2 1.3.2 Innovative ASUS features ... 1-4 Chapter 2: Hardware information Chapter 2: Hardware information Chapter 2: Hardware information Chapter 2: Hardware information Chapter 2: Hardware information Before you proceed ...

  • Page 4

    Managing and updating your BIOS ... 4-1 4.1.1 Creating a bootable floppy disk ... 4-1 4.1.2 AFUDOS utility ... 4-2 4.1.3 ASUS CrashFree BIOS 2 utility ... 4-5 4.1.4 ASUS Update utility ... 4-7 BIOS setup program ... 4-10 4.2.1 BIOS menu screen ... 4-11 4.2.2...

  • Page 5

    Contents Power menu ... 4-27 4.5.3 Hardware Monitor ... 4-30 4.6.1 Boot Device Priority ... 4-32 Boot menu ... 4-32 4.6.2 Boot Settings Configuration ... 4-33 4.6.3 Security ... 4-35 Exit menu ... 4-38 Appendix: Block diagrams Appendix: Block diagrams Appendix: Block diagrams Appendix: Block diagrams Appendix: Block diagrams...

  • Page 6: Notices

    Notices Federal Communications Commission Statement Federal Communications Commission Statement Federal Communications Commission Statement Federal Communications Commission Statement Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and •...

  • Page 7: Safety Information

    Safety information Electrical safety Electrical safety Electrical safety Electrical safety Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 8: About This Guide

    A S U S w e b s i t e s A S U S w e b s i t e s The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information.

  • Page 9: Typography

    Conventions used in this guide Conventions used in this guide Conventions used in this guide Conventions used in this guide Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. D A N G E R / W A R N I N G : D A N G E R / W A R N I N G : D A N G E R / W A R N I N G :...

  • Page 10: Ncl-ds Series Specifications Summary

    Supports PCI Express 1.0a interface Intel ® ICH5R South Bridge supports: - 4 USB 2.0/1.1 ports ASUS Q-Fan2 ASUS CrashFree BIOS 2 ASUS MyLogo2 AMI BIOS, 8 MB Flash ROM, Green, PnP, DMI2.0a, SMBIOS 2.3, WfM2.0 (continued on the next page) ®...

  • Page 11

    ASUS Live Update Utility c o n t e n t s c o n t e n t s Anti-virus software *Specifications are subject to change without notice.

  • Page 12

    x i i x i i x i i x i i x i i...

  • Page 13

    This chapter describes the motherboard features and the new technologies it supports. Product introduction...

  • Page 14: Chapter Summary

    Chapter summary Welcome! ... 1-1 Package contents ... 1-1 Special features ... 1-2 ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series...

  • Page 15: Welcome

    N C L - D R 1 The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards! Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

  • Page 16: Special Features

    Special features 1.3.1 1.3.1 1.3.1 Product highlights Product highlights Product highlights 1.3.1 1.3.1 Product highlights Product highlights Latest processor technology Latest processor technology Latest processor technology Latest processor technology Latest processor technology The motherboard comes with dual 604-pin surface mount ZIF sockets designed for the Intel (FSB) and 1 MB L2 cache.

  • Page 17

    Gigabit LAN solution Gigabit LAN solution Gigabit LAN solution Gigabit LAN solution Gigabit LAN solution The motherboard comes with dual Gigabit LAN controllers to provide a total solution for your networking needs. The onboard Broadcom BCM5721 Gigabit LAN controllers use the PCI Express interface and have network throughput close to Gigabit bandwidth.

  • Page 18: Innovative Asus Features

    ASUS Smart Fan technology ASUS Smart Fan technology ASUS Smart Fan technology The ASUS Smart Fan technology smartly adjusts the fan speeds according to the system loading to ensure quiet, cool, and efficient operation. See page 4-31 for details. ASUS MyLogo2™...

  • Page 19

    This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the jumpers and connectors on the motherboard. Hardware information...

  • Page 20

    Before you proceed ... 2-1 Motherboard overview ... 2-2 Central Processing Unit (CPU) ... 2-11 System memory ... 2-15 Expansion slots ... 2-18 Jumpers ... 2-21 Connectors ... 2-26 ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series...

  • Page 21: Before You Proceed

    Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Use a grounded wrist strap or touch a safely grounded object or to a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.

  • Page 22: Motherboard Overview

    Motherboard overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the chassis power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

  • Page 23: Cek Spring Support For Motherboard

    2.2.3 2.2.3 CEK spring support for motherboard CEK spring support for motherboard 2.2.3 2.2.3 2.2.3 CEK spring support for motherboard CEK spring support for motherboard CEK spring support for motherboard For additional protection from motherboard breakage due to the weight of the CPU heatsinks, your motherboard package comes with two CEK springs.

  • Page 24

    Press the lower spring clips inward, then insert to the lower CPU heatsink holes until they snap in place. If you installed a second CPU, repeat steps 2 to 4 to install the CEK spring to the CPU2 heatsink holes. The CEK springs appear as shown when installed.

  • Page 25

    Install the motherboard with the external I/O ports toward the chassis rear panel. The CPU sockets should be right on top of their respective standoffs. Make sure that the standoffs perfectly match the CEK spring screw holes; otherwise, you can not install the CPU heatsinks properly. Secure the motherboard with 9 screws.

  • Page 26: Motherboard Layouts

    2.2.4 2.2.4 Motherboard layouts Motherboard layouts 2.2.4 2.2.4 2.2.4 Motherboard layouts Motherboard layouts Motherboard layouts NCL-DS model NCL-DS model NCL-DS model NCL-DS model NCL-DS model ATXPWR1 PS/2 T: Mouse B: Keyboard REAR_FAN2 DDR DIMM_B4 (64/72 bit, 240-pin module) USB1 KBPWR1 USB2 DDR DIMM_A4 (64/72 bit, 240-pin module) DDR DIMM_B3 (64/72 bit, 240-pin module)

  • Page 27

    NCL-D model NCL-D model NCL-D model NCL-D model NCL-D model ATXPWR1 PS/2 T: Mouse B: Keyboard REAR_FAN2 DDR DIMM_B4 (64/72 bit, 240-pin module) USB1 KBPWR1 USB2 DDR DIMM_A4 (64/72 bit, 240-pin module) DDR DIMM_B3 (64/72 bit, 240-pin module) USBPW12 COM1 DDR DIMM_A3 (64/72 bit, 240-pin module) DDR DIMM_B2 (64/72 bit, 240-pin module) DDR DIMM_A2 (64/72 bit, 240-pin module)

  • Page 28

    NCL-DR1 model NCL-DR1 model NCL-DR1 model NCL-DR1 model NCL-DR1 model ATXPWR1 PS/2 T: Mouse B: Keyboard REAR_FAN2 DDR DIMM_B4 (64/72 bit, 240-pin module) USB1 KBPWR1 USB2 DDR DIMM_A4 (64/72 bit, 240-pin module) DDR DIMM_B3 (64/72 bit, 240-pin module) USBPW12 DDR DIMM_A3 (64/72 bit, 240-pin module) DDR DIMM_B2 (64/72 bit, 240-pin module) DDR DIMM_A2 (64/72 bit, 240-pin module) DDR DIMM_B1 (64/72 bit, 240-pin module)

  • Page 29: Layout Contents

    2.2.5 2.2.5 Layout contents Layout contents 2.2.5 2.2.5 2.2.5 Layout contents Layout contents Layout contents S l o t s / S o c k e t s S l o t s / S o c k e t s S l o t s / S o c k e t s S l o t s / S o c k e t s S l o t s / S o c k e t s...

  • Page 30

    I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s Floppy disk drive connector (34-1 pin FLOPPY1)

  • Page 31: Central Processing Unit (cpu)

    Central Processing Unit (CPU) The motherboard comes with surface mount 604-pin Zero Insertion Force (ZIF) sockets. The sockets are designed for the Intel the 604-pin package with 1 MB L2 cache. The new generation Xeon™ processor supports 800 MHz system bus and Extended Memory 64-bit Technology (EM64T).

  • Page 32

    Position the CPU above the socket as shown. Carefully insert the CPU into the socket until it fits in place. The CPU fits only in one correct orientation. DO NOT force the CPU into the socket to prevent bending the pins and damaging the CPU! Carefully push down the socket lever to secure the CPU.

  • Page 33: Installing The Cpu Heatsink And Fan

    2.3.2 2.3.2 Installing the CPU heatsink and fan Installing the CPU heatsink and fan 2.3.2 2.3.2 2.3.2 Installing the CPU heatsink and fan Installing the CPU heatsink and fan Installing the CPU heatsink and fan The Intel ® Xeon™ processors require an Intel certified heatsink and fan assembly to ensure optimum thermal condition and performance.

  • Page 34

    Use a Phillips screwdriver to tighten the four heatsink screws in a diagonal sequence. Connect the fan cable to the 4-pin connector labeled CPU_FAN1. Do not forget to connect the CPU fan connector! Hardware monitoring errors may occur if you fail to plug this connector. Repeat steps 1 to 3 to install the other heatsink if you have installed a second CPU, then...

  • Page 35: System Memory

    Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor. Refer to the DDR2 Qualified Vendors List at the ASUS web site. • Due to chipset resource allocation, the system may detect less than 16 GB system memory when you installed eight 2 GB DDR2 memory modules.

  • Page 36

    Single rank population Single rank population Single rank population Single rank population Single rank population M C H M C H M C H M C H M C H Single and dual rank mixing Single and dual rank mixing Single and dual rank mixing Single and dual rank mixing Single and dual rank mixing...

  • Page 37: Installing A Dimm

    2.4.3 2.4.3 Installing a DIMM Installing a DIMM 2.4.3 2.4.3 2.4.3 Installing a DIMM Installing a DIMM Installing a DIMM Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components.

  • Page 38: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Make sure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 39: Interrupt Assignments

    2.5.3 2.5.3 Interrupt assignments Interrupt assignments 2.5.3 2.5.3 2.5.3 Interrupt assignments Interrupt assignments Interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments I R Q I R Q P r i o r i t y P r i o r i t y I R Q I R Q...

  • Page 40: Pci/pci-x Slots

    2.5.4 2.5.4 PCI/PCI-X slots PCI/PCI-X slots 2.5.4 2.5.4 2.5.4 PCI/PCI-X slots PCI/PCI-X slots PCI/PCI-X slots The PCI/PCI-X slots support cards such as a LAN card, SCSI card, USB card, and other cards that comply with PCI 2.3 and PCI-X 1.0 specifications.

  • Page 41: Jumpers

    Jumpers The grayed out components in the illustrations may not be present in certain models. 1 . 1 . C l e a r R T C R A M ( C L R T C 1 ) C l e a r R T C R A M ( C L R T C 1 ) C l e a r R T C R A M ( C L R T C 1 ) C l e a r R T C R A M ( C L R T C 1 ) C l e a r R T C R A M ( C L R T C 1 )

  • Page 42

    2 . 2 . C P U f a n p i n s e l e c t i o n ( 3 - p i n F M _ C P U 1 , F M _ C P U 2 ) C P U f a n p i n s e l e c t i o n ( 3 - p i n F M _ C P U 1 , F M _ C P U 2 ) C P U f a n p i n s e l e c t i o n ( 3 - p i n F M _ C P U 1 , F M _ C P U 2 ) C P U f a n p i n s e l e c t i o n ( 3 - p i n F M _ C P U 1 , F M _ C P U 2 )

  • Page 43

    4 . 4 . K e y b o a r d p o w e r ( 3 - p i n K B P W R 1 ) K e y b o a r d p o w e r ( 3 - p i n K B P W R 1 ) K e y b o a r d p o w e r ( 3 - p i n K B P W R 1 ) K e y b o a r d p o w e r ( 3 - p i n K B P W R 1 ) K e y b o a r d p o w e r ( 3 - p i n K B P W R 1 )

  • Page 44

    6 . 6 . G i g a b i t L A N c o n t r o l l e r s e t t i n g ( 3 - p i n L A N 1 _ E N 1 ) G i g a b i t L A N c o n t r o l l e r s e t t i n g ( 3 - p i n L A N 1 _ E N 1 ) G i g a b i t L A N c o n t r o l l e r s e t t i n g ( 3 - p i n L A N 1 _ E N 1 ) G i g a b i t L A N c o n t r o l l e r s e t t i n g ( 3 - p i n L A N 1 _ E N 1 )

  • Page 45

    8 . 8 . S C S I c o n t r o l l e r s e t t i n g ( 3 - p i n S C S I _ E N 1 ) S C S I c o n t r o l l e r s e t t i n g ( 3 - p i n S C S I _ E N 1 ) S C S I c o n t r o l l e r s e t t i n g ( 3 - p i n S C S I _ E N 1 ) S C S I c o n t r o l l e r s e t t i n g ( 3 - p i n S C S I _ E N 1 )

  • Page 46: Connectors

    Connectors 2.7.1 2.7.1 2.7.1 Rear panel connectors Rear panel connectors Rear panel connectors 2.7.1 2.7.1 Rear panel connectors Rear panel connectors 1 . 1 . P S / 2 m o u s e p o r t ( g r e e n ) . This port is for a PS/2 mouse. P S / 2 m o u s e p o r t ( g r e e n ) .

  • Page 47: Internal Connectors

    2.7.2 2.7.2 Internal connectors Internal connectors 2.7.2 2.7.2 2.7.2 Internal connectors Internal connectors Internal connectors 1 . 1 . F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y 1 ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y 1 ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y 1 ) F l o p p y d i s k d r i v e c o n n e c t o r ( 3 4 - 1 p i n F L O P P Y 1 )

  • Page 48

    3 . 3 . S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 ) S e r i a l A T A c o n n e c t o r s ( 7 - p i n S A T A 1 , S A T A 2 )

  • Page 49

    4 . 4 . U l t r a 3 2 0 S C S I c o n n e c t o r s ( t w o 6 8 - p i n S C S I A 1 , S C S I B 1 ) U l t r a 3 2 0 S C S I c o n n e c t o r s ( t w o 6 8 - p i n S C S I A 1 , S C S I B 1 ) U l t r a 3 2 0 S C S I c o n n e c t o r s ( t w o 6 8 - p i n S C S I A 1 , S C S I B 1 ) U l t r a 3 2 0 S C S I c o n n e c t o r s ( t w o 6 8 - p i n S C S I A 1 , S C S I B 1 )

  • Page 50

    5 . 5 . H a r d d i s k a c t i v i t y L E D c o n n e c t o r ( 4 - p i n H D L E D 1 ) H a r d d i s k a c t i v i t y L E D c o n n e c t o r ( 4 - p i n H D L E D 1 ) H a r d d i s k a c t i v i t y L E D c o n n e c t o r ( 4 - p i n H D L E D 1 ) H a r d d i s k a c t i v i t y L E D c o n n e c t o r ( 4 - p i n H D L E D 1 )

  • Page 51

    7 . 7 . C P U a n d s y s t e m f a n c o n n e c t o r s ( 3 - p i n C P U _ F A N 1 / 2 , C P U a n d s y s t e m f a n c o n n e c t o r s ( 3 - p i n C P U _ F A N 1 / 2 , C P U a n d s y s t e m f a n c o n n e c t o r s ( 3 - p i n C P U _ F A N 1 / 2 , C P U a n d s y s t e m f a n c o n n e c t o r s ( 3 - p i n C P U _ F A N 1 / 2 ,...

  • Page 52

    9 . 9 . B a c k p l a n e S M B u s c o n n e c t o r ( 6 - 1 p i n B P S M B 1 ) B a c k p l a n e S M B u s c o n n e c t o r ( 6 - 1 p i n B P S M B 1 ) B a c k p l a n e S M B u s c o n n e c t o r ( 6 - 1 p i n B P S M B 1 ) B a c k p l a n e S M B u s c o n n e c t o r ( 6 - 1 p i n B P S M B 1 )

  • Page 53

    B M C c o n n e c t o r ( 1 6 - p i n B M C C O N N 1 ) This connector is for the ASUS server management card, if available. NCL-DS Series BMC connector...

  • Page 54

    1 3 . 1 3 . S y s t e m p a n e l c o n n e c t o r ( 2 0 - p i n P A N E L 1 ) S y s t e m p a n e l c o n n e c t o r ( 2 0 - p i n P A N E L 1 ) 1 3 .

  • Page 55

    1 4 . 1 4 . A u x i l i a r y p a n e l c o n n e c t o r ( 2 0 - p i n A U X _ P A N E L 1 ) A u x i l i a r y p a n e l c o n n e c t o r ( 2 0 - p i n A U X _ P A N E L 1 ) 1 4 .

  • Page 56

    2 - 3 6 2 - 3 6 2 - 3 6 2 - 3 6 2 - 3 6 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n...

  • Page 57

    This chapter describes the power up sequence, the vocal POST messages, and ways of shutting down the system. Powering up...

  • Page 58

    Chapter summary Starting up for the first time ... 3-1 Powering off the computer ... 3-2 ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series...

  • Page 59: Starting Up For The First Time

    Starting up for the first time After making all the connections, replace the system case cover. Be sure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector.

  • Page 60: Powering Off The Computer

    Powering off the computer 3.2.1 3.2.1 3.2.1 Using the OS shut down function Using the OS shut down function Using the OS shut down function 3.2.1 3.2.1 Using the OS shut down function Using the OS shut down function If you are using Windows Click the S t a r t S t a r t S t a r t...

  • Page 61: Chapter 4: Bios Setup

    This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. BIOS setup...

  • Page 62

    BIOS setup program ... 4-10 Main menu ... 4-13 Advanced menu ... 4-18 Power menu ... 4-27 Boot menu ... 4-32 Exit menu ... 4-38 ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series...

  • Page 63: Managing And Updating Your Bios

    Refer to the corresponding sections for details on these utilities. Save a copy of the original motherboard BIOS file to a bootable floppy disk in case you need to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update or AFUDOS utilities. 4.1.1 4.1.1 4.1.1...

  • Page 64: Afudos Utility

    Windows ® 2000 environment To create a set of boot disks for Windows a. Insert a formatted, high density 1.44 MB floppy disk into the drive. b. Insert the Windows S t a r t S t a r t c.

  • Page 65

    Updating the BIOS file To update the BIOS file using the AFUDOS utility: Visit the ASUS website (www.asus.com) and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable floppy disk. Write the BIOS filename on a piece of paper. You need to type the exact BIOS filename at the DOS prompt.

  • Page 66

    The utility verifies the file and starts updating the BIOS. A:\>afudos /iNCLDS.ROM /pbnc AMI Firmware Update Utility - Version 1.19(ASUS V2.07(03.11.24BB)) Copyright (C) 2002 American Megatrends, Inc. All rights reserved. WARNING!! Do not turn off power during flash BIOS Reading file ... done Reading flash ...

  • Page 67: Asus Crashfree Bios 2 Utility

    ASUS CrashFree BIOS 2 utility ASUS CrashFree BIOS 2 utility The ASUS CrashFree BIOS 2 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using the motherboard support CD or the floppy disk that contains the updated BIOS file.

  • Page 68

    Restart the system after the utility completes the updating process. The recovered BIOS may not be the latest BIOS version for this motherboard. Visit the ASUS website (www.asus.com) to download the latest BIOS file. 4 - 6...

  • Page 69: Asus Update Utility

    4.1.4 ASUS Update utility ASUS Update utility ASUS Update utility The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows allows you to: • Save the current BIOS file • Download the latest BIOS file from the Internet •...

  • Page 70

    Updating the BIOS through the Internet Updating the BIOS through the Internet To update the BIOS through the Internet: Launch the ASUS Update utility from the Windows S t a r t S t a r t P r o g r a m s...

  • Page 71

    A S U S U p d a t e A S U S U p d a t e A S U S U p d a t e. The ASUS Update main window appears. A S U S U p d a t e...

  • Page 72: Bios Setup Program

    The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. 4 - 1 0 4 - 1 0...

  • Page 73: Bios Menu Screen

    C o n f i g u r a t i o n f i e l d s [11:10:19] [Fri 08/06/2004] [1.44M, 3.5 in] [ST320413A] [ASUS CD-S520/A] [Not Detected] [Not Detected] [Not Detected] [Not Detected] G e n e r a l h e l p...

  • Page 74: Menu Items

    [1.44M, 3.5 in] Use [+] or [-] to Primary IDE Master : [ST320413A] configure system time. Primary IDE Slave : [ASUS CD-S520/A Third IDE Master : [Not Detected] Third IDE Slave : [Not Detected] Fourth IDE Master : [Not Detected]...

  • Page 75: Main Menu

    M a i n M a i n M a i n menu screen appears, [11:10:19] [Fri 08/06/2004] [1.44M, 3.5 in] [ST320413A] [ASUS CD-S520/A] [Not Detected] [Not Detected] [Not Detected] [Not Detected] Use [ENTER], [TAB] or [SHIFT-TAB] to select a field.

  • Page 76: Primary, Third And Fourth Ide Master/slave

    4.3.4 4.3.4 Primary, Third and Fourth IDE Master/Slave Primary, Third and Fourth IDE Master/Slave 4.3.4 4.3.4 4.3.4 Primary, Third and Fourth IDE Master/Slave Primary, Third and Fourth IDE Master/Slave Primary, Third and Fourth IDE Master/Slave The BIOS automatically detects the connected IDE devices. There is a separate sub-menu for each IDE device.

  • Page 77

    PIO Mode [Auto] PIO Mode [Auto] PIO Mode [Auto] PIO Mode [Auto] PIO Mode [Auto] Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4] SMART Monitoring [Auto] SMART Monitoring [Auto] SMART Monitoring [Auto] SMART Monitoring [Auto] SMART Monitoring [Auto] Sets the Smart Monitoring, Analysis, and Reporting Technology.

  • Page 78: Ide Configuration

    4.3.5 4.3.5 IDE Configuration IDE Configuration 4.3.5 4.3.5 4.3.5 IDE Configuration IDE Configuration IDE Configuration The items in this menu allow you to set or change the configurations for the IDE devices installed in the system. Select an item then press <Enter> if you wish to configure the item.

  • Page 79: System Information

    4.3.6 4.3.6 System Information System Information 4.3.6 4.3.6 4.3.6 System Information System Information System Information This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. AMIBIOS Version : 08.00.10 Build Date : 07/23/04 Processor Type : Intel(R) Xeon(TM) CPU 2.80GHz...

  • Page 80: Usb Configuration

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. USB Configuration MPS Configuration Remote Access Configuration CPU Configuration...

  • Page 81

    USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports] Allows you to enable a specific number of USB ports, or disable the USB function. Configuration options: [Disabled] [2 USB Ports] [4 USB Ports] Legacy USB Support [Auto] Legacy USB Support [Auto] Legacy USB Support [Auto]...

  • Page 82: Mps Configuration

    Emulation Type [N/A] When set to Auto, USB devices less than 530MB will be emulated as floppy drive, and the remaining drives as hard drives. Forced FDD option can be used to force an HDD formatted drive to boot as FDD (for example, ZIP drive).

  • Page 83: Remote Access Configuration

    4.4.3 4.4.3 Remote Access Configuration Remote Access Configuration 4.4.3 4.4.3 4.4.3 Remote Access Configuration Remote Access Configuration Remote Access Configuration The items in this menu allows you to configure the Remote Access features. Select an item then press <Enter> to display the configuration options.

  • Page 84: Chipset

    Enhance L1 Control [Auto] Enhance L1 Control [Auto] Enhance L1 Control [Auto] Enhance L1 Control [Auto] Enhance L1 Control [Auto] Configuration options: [Auto] [Disabled] CPU Internal Thermal Control [Auto] CPU Internal Thermal Control [Auto] CPU Internal Thermal Control [Auto] CPU Internal Thermal Control [Auto] CPU Internal Thermal Control [Auto] Configuration options: [Auto] [Disabled] Intel(R) SpeedStep Tech [Automatic]...

  • Page 85

    NorthBridge Configuration NorthBridge Configuration NorthBridge Configuration NorthBridge Configuration NorthBridge Configuration The NorthBridge Configuration menu allows you to change the Northbridge settings. NorthBridge Chipset Configuration DIMM Speed: DDR2 400 Memory Remap Feature Memory Mirroring/Sparing DIMM Speed DIMM Speed DIMM Speed DIMM Speed DIMM Speed Displays the installed DIMM type and speed.

  • Page 86: Onboard Devices Configuration

    4.4.6 4.4.6 Onboard Devices Configuration Onboard Devices Configuration 4.4.6 4.4.6 4.4.6 Onboard Devices Configuration Onboard Devices Configuration Onboard Devices Configuration Configure Win627EHF Super IO Chipset Serial Port1 Address Serial Port2 Address Serial Port2 Mode Parallel Port Address Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]...

  • Page 87: Pci Pnp

    4.4.7 4.4.7 PCI PnP PCI PnP 4.4.7 4.4.7 4.4.7 PCI PnP PCI PnP PCI PnP The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting the IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices.

  • Page 88

    PCI IDE BusMaster [Enabled] PCI IDE BusMaster [Enabled] PCI IDE BusMaster [Enabled] PCI IDE BusMaster [Enabled] PCI IDE BusMaster [Enabled] Allows BIOS to use PCI bus mastering when reading/writing to IDE devices. Configuration options: [Disabled] [Enabled] Offboard PCI/ISA IDE Card [Auto] Offboard PCI/ISA IDE Card [Auto] Offboard PCI/ISA IDE Card [Auto] Offboard PCI/ISA IDE Card [Auto]...

  • Page 89: Acpi Apic Support [enabled]

    Power menu The Power menu items allow you to change the settings for the ACPI and Advanced Power Management (APM) features. Select an item then press <Enter> to display the configuration options. ACPI APIC Support APM Configuration Hardware Monitor 4.5.1 4.5.1 ACPI APIC Support [Enabled] ACPI APIC Support [Enabled]...

  • Page 90

    Use the arrow down key to scroll down the menu. Power On Ring Power On LAN Power On By PME# Power On By RTC Alarm Power On By PS/2 Keyboard Power On By PS/2 Mouse Power Management [Enabled] Power Management [Enabled] Power Management [Enabled] Power Management [Enabled] Power Management [Enabled]...

  • Page 91

    Power On Ring Power On Ring [Disabled] Power On Ring [Disabled] [Disabled] [Disabled] Power On Ring Power On Ring [Disabled] When set to [Enabled], the system enables the RI to generate a wake event while the computer is in Soft-off mode. Configuration options: [Disabled] [Enabled] Power On LAN [Disabled] Power On LAN [Disabled]...

  • Page 92: Hardware Monitor

    4.5.3 4.5.3 Hardware Monitor Hardware Monitor 4.5.3 4.5.3 4.5.3 Hardware Monitor Hardware Monitor Hardware Monitor Hardware Monitor CPU1 Temperature CPU2 Temperature MB Temperature CPU1 Fan Speed CPU2 Fan Speed Front1 Fan Speed Front2 Fan Speed Rear1 Fan Speed Rear2 Fan Speed Smart Fan Control VCORE1 Voltage VCORE2 Voltage...

  • Page 93

    Smart Fan Control [Disabled] Smart Fan Control [Disabled] Smart Fan Control [Disabled] Allows you to enable or disable the ASUS Q-Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Disabled] [Enabled] The C P U 1 T e m p e r a t u r e...

  • Page 94: Boot Device Priority

    4 - 3 2 Enter Go to Sub-screen [1st FLOPPY DRIVE] [PM-ST330620A] [PS-ASUS CD-S360] [MBA v7.5.12 Slot 0] Enter Go to Sub-screen C h a p t e r 4 : B I O S s e t u p...

  • Page 95: Boot Settings Configuration

    Allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Set this item to [Enabled] to use the ASUS MyLogo2™ feature. Add On ROM Display Mode [Force BIOS] Add On ROM Display Mode [Force BIOS]...

  • Page 96

    Wait for ‘F1’ If Error [Enabled] Wait for ‘F1’ If Error [Enabled] Wait for ‘F1’ If Error [Enabled] Wait for ‘F1’ If Error [Enabled] Wait for ‘F1’ If Error [Enabled] When set to Enabled, the system waits for the F1 key to be pressed when error occurs.

  • Page 97: Security

    4.6.3 4.6.3 4.6.3 Security Security Security 4.6.3 4.6.3 Security Security The Security menu items allow you to change the system security settings. Select an item then press <Enter> to display the configuration options. Security Settings Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password...

  • Page 98

    After you have set a supervisor password, the other items appear to allow you to change other security settings. Security Settings Supervisor Password User Password Change Supervisor Password User Access Level Change User Password Clear User Password Password Check Boot Sector Virus Protection [Disabled] User Access Level [Full Access] User Access Level [Full Access] User Access Level [Full Access]...

  • Page 99

    Clear User Password Clear User Password Clear User Password Clear User Password Clear User Password Select this item to clear the user password. Password Check [Setup] Password Check [Setup] Password Check [Setup] Password Check [Setup] Password Check [Setup] When set to [Setup], BIOS checks for user password when accessing the Setup utility.

  • Page 100: Exit Menu

    Exit menu The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Exit Options Exit & Save Changes Exit & Discard Changes Discard Changes Load Setup Defaults If you made changes to any of the settings in the menus, pressing <Esc>...

  • Page 101

    Load Setup Defaults Load Setup Defaults Load Setup Defaults Load Setup Defaults Load Setup Defaults Select this option then press <Enter> to load the optimized settings for each of the Setup menu items. When a confirmation window appears, select [OK] then press <Enter> to load the default settings.

  • Page 102

    4 - 4 0 4 - 4 0 4 - 4 0 4 - 4 0 4 - 4 0 C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p...

  • Page 103: Reference Information

    This appendix includes additional information that you may refer to when configuring the motherboard. Reference information...

  • Page 104: Ncl-ds Block Diagram

    Appendix summary NCL-DS block diagram ... A-1 NCL-D block diagram ... A-2 NCL-DR1 block diagram ... A-3 ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series ASUS NCL-DS Series...

  • Page 105: A.1 Ncl-ds Block Diagram

    NCL-DS block diagram Intel Xeon Processor with 800MHz system bus System Bus 64-bit, 800 MHz Intel Memory DDRII 400 DIMM Controller Hub (Intel 7520) x8 PCI Express PCI Bridge Intel PXH x4 PCI Express PCI Bridge Intel PXH x4 PCI Express x1 PCI Express x1 PCI Express Hub Interface 1.5...

  • Page 106: A.2 Ncl-d Block Diagram

    NCL-D block diagram Intel Xeon Processor with 800MHz system bus System Bus 64bit, 800 MHz Intel Memory Controller Hub (E7520) X8 PCI Express X4 PCI Express X4 PCI Express X1 PCI Express X1 PCI Express Hub interface 1.5 Intel I/O Controller Hub 5 (ICH5R) SMBus...

  • Page 107: A.3 Ncl-dr1 Block Diagram

    NCL-DR1 block diagram Intel Xeon Processor with 800MHz system bus System Bus 64bit, 800 MHz DDRII 400 DIMM Intel Memory Controller Hub (E7520) X8 PCI Express PCI bridge Intel PXH X1 PCI Express X1 PCI Express Hub interface 1.5 Intel I/O Controller Hub 5 (ICH5R) SMBus...

  • Page 108

    A - 4 A - 4 A - 4 A - 4 A - 4 A p p e n d i x A : R e f e r e n c e i n f o r m a t i o n A p p e n d i x A : R e f e r e n c e i n f o r m a t i o n A p p e n d i x A : R e f e r e n c e i n f o r m a t i o n A p p e n d i x A : R e f e r e n c e i n f o r m a t i o n...
