1.2.1 General Technical Specifications

• Loops - from 1 to 4 loops
• Up to 250 devices (detectors and modules, regardless of the type) per Loop
• Zones - 96 displayed zones
• Monitored relay outputs - 4 (Sounder, Fire, Fault and Fire Protection)
• Non monitored relay outputs - 4 programmable, 230V/ 10A
• Display - 320x240 CSTN graphic display (118.8 x 89.38 mm) with a touch panel
• Real time clock
• Up to 128 programmable Inputs/Outputs per panel
• Comprehensive day/night mode facility
• 2 Steps of alarm levels (T1 and T2)
• Based on Windows graphical configuration utility via Ethernet or USB
• Simple Http monitoring utility
• Loop less panel option (repeater)
• Thermal printer (optional)
• Flush mounting enclosure
• Multi- language support
• Easy software update
• Certified according EN54-2/4

1.2.2 Possible Hardware Configuration

Maximum configuration:
- Main Board
- Power Supply Source
- LED-indication
- Input/Output Module
- 4 Relay Module
- 4 Loop Controllers
- Heat Printer (optional)

1.2.3 Working Environment

- Working Temperature: .......................-10˚C up to +50˚C
- Relative Humidity: ............................up to 95% (without condense)
- Storage Temperature: .......................-10˚C up to +60˚C
- Weight (without the battery): ............6kg.

1.2.4 Electrical Specifications

Earth connection
The earth connection has to be realized in accordance with the rules for the electrical safety with the total resistance in
the circuit lower than 10Ω. It is mandatory to connect the main power supply cable to the middle input of the fire panel
terminal - see item 2.2.7 Power Source.
Main power supply
In normal operating conditions the fire panel is powered from the mains voltage line. In case of mains voltage line loss
the fire panel is equipped with one rechargeable battery. The characteristics of the main power supply are as follows:
- Main Power Supply: .........................~230V +10%/ -15%
- Frequency: .......................................50/ 60Hz
- Electrical output: ...............................7.5A
Consumption
From the main power supply in standby mode:
- For 1 loop configuration: 65 mA AC
- For 2 loops configuration: 75 mA AC
- For 3 loops configuration: 85 mA AC
- For 4 loops configuration: 95 mA AC
From the backup power supply in FAULT mode and generated message 'AC loss':
- For 1 loop configuration: 285 mA DC
- For 2 loops configuration: 360 mA DC
- For 3 loops configuration: 435 mA DC
- For 4 loops configuration: 510 mA DC
ATTENTION: Do not instal the fire panel near power electromagnetic fields (radio equipment, elec-
tric motors, etc.)!
Addressable Fire Panel MAGPRO96 - Installation and Programming Manual
Minimum configuration:
- Main Board
- Power Supply
5
