Summary of Contents for Makita 9556HP
- Page 1 INSTRUCTION MANUAL Angle Grinder 9556HP 9557HP 9558HP 006110 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
ENGLISH SPECIFICATIONS Model 9556HP 9557HP 9558HP Depressed center wheel diameter 100 mm 115 mm 125 mm Spindle thread Rated speed (n) / No load speed (n 11,000 min 11,000 min 11,000 min Overall length 273 mm 273 mm 273 mm Net weight 2.0 kg... -
Page 3: Specific Safety Rules
Personal safety 20. Store idle power tools out of the reach of 10. Stay alert, watch what you are doing and use children and do not allow persons unfamiliar common sense when operating a power tool. with the power tool or these instructions to Do not use a power tool while you are tired or operate the power tool. - Page 4 Do not use accessories which are not 10. Hold power tool insulated gripping specifically designed and recommended by surfaces only, when performing an operation the tool manufacturer. Just because the where the cutting accessory may contact accessory can be attached to your power tool, it hidden wiring or its own cord.
- Page 5 b) Never place your hand near the rotating body, the possible kickback may propel the accessory. Accessory may kickback over your spinning wheel and the power tool directly at you. hand. c) When wheel is binding or when interrupting a c) Do not position your body in the area where cut for any reason, switch off the power tool and hold the power tool motionless until the...
-
Page 6: Functional Description
SAVE THESE INSTRUCTIONS. 20. Before using the tool on an actual workpiece, let it run for a while. Watch for vibration or wobbling that could indicate poor installation FUNCTIONAL DESCRIPTION or a poorly balanced wheel. 21. Use the specified surface of the wheel to perform the grinding. - Page 7 For tool without lock button CAUTION: To prevent the switch lever from accidentally pulled, a The wheel guard must be fitted on the tool so that • lock-off lever is provided. To start the tool, pull the the closed side of the guard always points toward lock-off lever toward the operator and then pull the the operator.
-
Page 8: Operation
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Wheel guard (Wheel cover) • Inner flange • Depressed center wheels 006122 •... - Page 12 Makita Corporation 884848A6...
