- Page 1 Betriebsanleitung Schutzgas-Schweißgeräte MIG/MAG 170 - 230 Operating Instruction MIG Welding Machines 170 - 230 Amp Models Notice d´utilisation postes de soudure semiautomatiques MIG/MAG 170 - 230 Gebruiksaanwijzing Lasapparaat MIG/MAG 170/230 Achtung! Lesen Sie diese Anleitung vor der Installation und Inbetriebnahme aufmerksam durch. Attention! Carefully read through these instructions prior to installation and commissioning.
-
Page 2: Table Of Contents
We reserve the right to change specifications. Product Liability/Warranty These welding machines shall only be used as specified. Any other use requires the written consent of Metabo GmbH, Business Unit Elektra Beckum, P.O.Box 1352, D-49703 Meppen, Germany. This product carries 2 years (5 years on main transformer and choke) manufacturer warranty under the prevailing legal provisions, which may vary from country to country. -
Page 3: Regulations For The Prevention Of Accidents
Welding range Open-circuit voltage No-load voltage Input capacity Mains 50/60 Hz AC Frequency Welding steps Wire diameter Weldable material Duty cycle (25°c/ 40°C ) 100% (25°c/ 40°C ) Mains fuse Cooling Protection class Isulation class Welding gun assembly Dimensions l x w x h Weight StandardScope of delivery: regulator for shielding gas, earth clamp, wire brush and nozzle anti-clogging spray. -
Page 4: Welding Output
Welding Output Box 6 Welding process Symbol e.g.: Manual metal arc welding with covered electrodes Tungsten inert-gas welding Metal inert and active gas welding including the use of flux cored wire Selfshielded flux cored arc welding Submerged arc welding Symbol for plasma cutting Symbol for plasma gouging Box 7 Symbol for welding power sources which are suitable for supplying power to welding operations... - Page 5 b) Welding Output Box 6 Welding process Symbol e.g.: Box 7 Symbol for welding power sources which are suitable for supplying power to welding operations carried out in an environment with increased hazard of electric shock (if applicable). Box 8 Welding current symbol e.g.: Direct current Alternating current, and additionally the rated frequency in...
-
Page 6: Operation
current is 60 % or 100 %. Column b) need not be used if the duty cycle (duty factor) at the rated maximum welding current is 100 %. c) Energy input Box 14 Energy input symbol e.g.: Box 22 IP.. Degree of protection, e.g. -
Page 7: Installing The Wire Spool
230 V/ 400 V Combi Machines Combi models come with a CEE 3-phase 5 prong plug fitted to power cord as standard, and an adaptor with 1-phase plug. If a 3-phase plug matching your local standard outlet has to be installed, connection has to be made to 2 phases, neutral and earth. -
Page 8: Welding Stainless Steel And Aluminium
4.2 Wire Feed Set-up The feed roller is fitted with four pilot grooves for wire diameters 0.6/0.8/1.0/1.2 mm. To adapt the feed roller to the wire size used, first release the tension roller from the feed roller by pushing the lever back. For 1.0 or 1.2 mm wire the corresponding outer groove is required. -
Page 9: Welding Aluminium
Welding Aluminium To weld aluminium the following components have to be installed on welding gun and torch lead assembly: - polyamid liner c/w copper spiral liner - cylindrical gas shroud - contact tip "A" - support tube It is important to have the feed roller set to the correct electrode wire diameter, otherwise the wire will be deformed resulting in feed problems. -
Page 10: Practical Hints For Mig Welding
Practical Hints for MIG Welding This distance required between the torch and the workpiece is directly related to the welding current: ● small current ● high current Too little distance causes excessive wear of the contact tip and gas shroud. Too much distance will not provide enough gas protection of the welding seam, it becomes porous. -
Page 11: Trouble Shooting
Trouble Shooting Cause Fault Irregular wire feed Incorrect tension of tension roller Pilot groove of feed roller and intake nozzle not aligned Liner clogged or not correct size for wire Wire spooled irregularly, rusty or of inferior quality Wire spool carrier to tight Feed rollers dirty of worn, groove not matching wire size Brittle or porous welding... -
Page 12: Spare Parts List And Accessoires
Spare Parts List and Accessories Description Rectifier bank Rectifier bank Rectifier bank Rectifier bank Rotary fan Central coupling 6-step selector switch 6-step selector switch Switch on/off with pilot light Neon pilot Light 380 V yellow Neon pilot Light 380 V white Selector switch Capacitor bank 44.000 µF Capacitor bank 66.000 µF... - Page 13 MIG Welding Torch SB 14/3 For models: MIG/MAG 170/30 TL MIG/MAG 170/30 TL Combi Pos. Description Welding torch SB 14/2 cpl. with torch leads 3 m Swan neck cpl. Nozzle spring (5x) Head insulator Swan neck boot Handle red cpl. Trigger red 2-pol.
- Page 14 MIG Welding Torch SB 15/3; SB 15/4; SB 15/5 For models: MIG/MAG 180/35 ET Combi MIG/MAG 200/35 ET Pos. Description Welding torch SB 15/2 3 Welding torch SB 15/2 4 Welding torch SB 15/2 5 Swan neck Nozzle spring (5x) Head insulator Swan neck spacer Swan neck boot...
- Page 15 MIG Welding Torch SB 25/2 For models: MIG/MAG 230/40 ET Pos. Description Welding Torch SB 25/2 with torch leads 3 mtr with torch leads 4 mtr with torch leads 5 mtr Swan neck, complete Gas shroud spring Torch body, plastic Handle ass'y, red SB 25-SB 501 Lead support Lead support...
- Page 16 D DEUTSCH KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortlichkeit, daß dieses Produkt mit den folgenden Normen übereinstimmt* gemäß den Bestimmungen der Richtlinien**. F FRANÇAIS DECLARATION DE CONFORMITE Nous déclarons, sous notre seule responsabilité, que ce produit est en conformité avec les normes ou documents normatifs suivants* en vertu des dispositions des directives ** IT ITALIANO DICHIARAZIONE DI CONFORMITÀ...
