- Page 1 PU-Q1C8H v1.3 1 to 8 CAT 6 to HDMI Distribution Amplifier OPERATION MANUAL...
-
Page 2: Table Of Contents
Table of Contents Introduction Package Contents System Requirements Features Operation Controls and Functions 5.1 Front Panel Diagram 5.2 Rear Panel Diagram Pin Definitions 6.1 IR Cable Pin Definition 6.2 RJ-45 Pin Definitions Connection Diagram 1 7.1 Connection Diagram 2 7.2 Connection Diagram 3 Specifications... -
Page 3: Introduction
1. Introduction When used with HDMI to CAT6 transmitters, the 1 by 8 CAT6 to HDMI 1.3 splitter allows the user to distribute an HDMI source through CAT6 cables over 40 meters. This solution provides a direct input of one CAT6 to a looped output of CAT6 and 7 HDMI outputs –... -
Page 4: Features
4. Features • 3D Ready. • HDMI 1.3, HDCP1.1 and DVI1.0 compliant Receiver. • One CAT6 source connection to one CAT6 output and seven HDMI outputs - allowing users to link up to eight displays simultaneously. • PC and HDTV resolutions from VGA to SXGA (1280 x 1024) and 480i to 1080p. -
Page 5: Operation Controls And Functions
POWER POWER OUTPUT PU-Q1C8H 1. HDMI/DVI indicators: When the input source is HDMI this LED is illuminated, when the input source is DVI, this LED will not be illuminated. 2. HDCP indicators: When the input source has HDCP protection the HDCP LED will illuminate. -
Page 6: Rear Panel Diagram
5.2 Rear Panel CAT6 IN CAT6 OUT HDMI OUT DC 5V VIDEO VIDEO 1 DDC 1 IR IN IR OUT 8 Bit 12 Bit EDID SYS. Reset 1 2 3 1. IR IN: Connect the included IR receiver cable and use the source(s) existing remote control(s). - Page 7 5.2 Rear Panel cont’d 4. System reset function: It is suggested that this function is switched OFF, except when doing system reset. By switching this ON the system will reset TV to HDMI Input within 8~10 minutes. Switching to OFF means CEC bypass.
-
Page 8: Pin Definitions
6. Pin Definitions 6.1 IR Cable Pin Definitions IR Blaster IR Receiver 1 Power 5V 1 Power 5V 2 NC 2 NC 3 IR Blaster Signal 3 IR Blaster Signal Note: The frequency on both IR Receiver & Blaster can support 20~60KHz. Video TX2+ DDC Bus Clock... -
Page 9: Connection Diagram
7. Connection Diagram Page 7... -
Page 10: Connection Diagram
7.1 Connection Diagram Page 8... -
Page 11: Connection Diagram
7.2 Connection Diagram Page 9... -
Page 12: Specifications
8. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Port 1 x CAT6 + 1 x DDC Output Ports 7 x HDMI, 1 x CAT6 + 1 x DDC Weight 2130g Power Supply 5V DC/6A (US/EU standards, CE/FCC/UL Certified) Dimensions 436(W) x 160(D) x 44(H) Chassis Colour Black Chassis Material... - Page 13 9. Notes Page 11...
