Summary of Contents for Geemarc AMPLICALL10
- Page 2 Volume control Alarm mode switch Tone control Speaker Table mounting FRONT battery compartment (4 X AA) Wall mounting screw holes REAR Bed Shaker jack Modular Modular jack PTT line or Adaptor jack jack PTT line for a second Amplicall10 (option) connection...
-
Page 3: Installation
INSTALLATION Important Safety Instructions When using your device equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. - Page 4 INSTALLATION Installation (See drawing) 120V AC adaptor (option) Phone line Option: Bed Shaker RJ11 phone jack 1) Insert 4 AA batteries into the battery compartment, for battery backup feature. Test batteries every year. 2) Connect the Phone cable to the line jack found at the rear of the Amplicall 10.
-
Page 5: Alarm Operation
INSTALLATION Alarm Operation 1 - SETTING THE ALARM MODE Choose which alarm mode you want by moving the alarm mode switch to one of the following positions: : no alarm :both strobe flasher and sound alarm activated : both strobe flasher and shaker (if connected) activated : both sound alarm and shaker (if connected) activated... -
Page 6: Wall Mounting
INSTALLATION Wall Mounting 1. Drill two holes horizontally, 96mm apart, and leave the screws protruding from the wall by 5mm. 2. Hang the base on to the two screws and pull the base down to lock it into place. Table Mounting If you want to mount the unit on a table, simply place it in the base cradle, and place the base cradle on the table. -
Page 7: Troubleshooting
INSTALLATION Trouble shooting Symptom Solution No incoming call yet the 1) Check the batteries are Amplicall10 rings inserted correctly. automatically or rings 2) Check the power continuously; the adaptor is connected shaker vibrates correctly. automatically or 3) Turn off the power continuously;... - Page 8 INSTALLATION When there is an 1) Check it is connected to incoming call but the the shaker correctly. shaker doesn’t vibrate. 2) Check the shaker socket to see if it has been damaged. 3) Check the alarm mode selection switch position is correct.
-
Page 9: Regulatory Compliance
REGULATORY COMPLIANCE - This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the bottom of this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. - Page 10 REGULATORY COMPLIANCE But if advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your rights to file a complaint with the FCC if you believe it is necessary. - The telephone company may make changes in its facilities, equipment, operation or procedures that could affect the operation of the equipment.
- Page 11 REGULATORY COMPLIANCE or VCR will often reduce or eliminate the interference. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
- Page 12 REGULATORY COMPLIANCE - Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation for information. - If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this telephone equipment does not disable your alarm equipment.
- Page 13 GUARANTEE Sonic Alert warrants the phone against any defect in materials or workmanship for the period of one year from the date of purchase. Should you experience a problem, contact our customer service department. Be sure to save your sales receipt as proof of purchase date should you need warranty service.
- Page 14 GUARANTEE Simply send the Amplicall10(postpaid) and a copy of your sales slip as proof of purchase to: Sonic Alert Warranty Center 1081 West Innovation Dr. Kearney, MO 64060 IMPORTANT : YOUR RECEIPT IS PART OF YOUR WARRANTY MUST RETAINED PRODUCED IN THE EVENT OF A WARRANTY CLAIM Sonic Alert Warranty Center 1081 West Innovation Dr.
