Lennox comfortsense 7500 User Manual

Color touchscreen
Hide thumbs Also See for comfortsense 7500:

Advertisement

Quick Links

User Guide

Color Touchscreen
Programmable Thermostat
®
ComfortSense
7500 (13H14)

Advertisement

loading

Related Manuals for Lennox comfortsense 7500

Summary of Contents for Lennox comfortsense 7500

  • Page 1: User Guide

    User Guide Color Touchscreen Programmable Thermostat ® ComfortSense 7500 (13H14)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Dew point adjustment control. Ergonomic design. Features ........Smooth Setback Recovery starts system Temperature Dial Indicator .

  • Page 3: Temperature Dial Indicator

    Temperature Dial Indicator 2:31 am Ⓐ Ⓒ Ⓑ Ⓕ heat−to inside Ⓓ 72° waiting cool−to Ⓔ 78° outside heat/cool 89° away Figure 1. Temperature Dial Feature...
  • Page 4 A. This is the heat set point position indicator D. When there is an active call for heating, this on the dial. This object will be red in color. area of the dial will fade back and forth from white to red. B.

  • Page 5: Home Screen

    Home Screen 2:31 am Ⓓ Ⓒ Ⓙ Ⓔ Ⓕ Schedule hold until 8:22 am Ⓖ heat−to Ⓚ inside Ⓔ 72° waiting Ⓘ cool−to Ⓕ 78° Ⓑ outside schedule 1 Ⓗ Ⓐ 89° away Figure 2. home screen...
  • Page 6 Press the screen anywhere - the first press turns D. Menu - This will allow access to notifications, on the backlight. performance report, schedules and set­ tings. A. OPERATING MODE - press to access the E. This allows you to set the heat-to (if enabled) screen that will list available modes.
  • Page 7 I. Displays the current indoor temperature. cated (i.e., 11:57 pm). To exit schedule hold, press Ⓧ. J. Indicates the schedule is on hold until the next time period or permanent. 5. For the permanent setting the screen will in­ dicate schedule hold permanent. To exit 1.
  • Page 8 Table 1. System Status Icons Screen Icon Description Humidifying icon is displayed when humidifying is occurring. Pressing on the icon will display humidifying next to the icon. Dehumidifying icon is displayed when dehumidifying is occurring. Pressing on the icon will display dehumidifying next to the icon. Red flames indicates the system is heating.
  • Page 9 Screen Icon Description Red flame with a plus indicates the system is running in emergency heat mode. Transitioning to next schedule temperature setting. This icon will only appear if smooth setback recovery is enabled under the installer setup. When enabled, it will begin recovery up to two hours before the programmed time so that the pro­...

  • Page 10: Selection Mode

    Selection Mode Press anywhere in the area indicated below to select how the system will operate. 2:31 am heat−to inside 72° cool−to 78° outside schedule 1 69° away Figure 3. Home Screen (Accessing Mode Screen)

  • Page 11: Operating Modes

    OPERATING MODES In the CIRCULATE mode, the user can cycle the fan for a programmed period time of active time per 1. HEAT/COOL allows the thermostat to switch hour during periods of equipment inactivity (i.e., between heating and cooling automatically. heating or cooling equipment not running).

  • Page 12: Menu Screen

    Menu menu notifications heat−to performance report 72° cool−to edit schedules 78° settings Figure 4. User Menu Screen...

  • Page 13: Dealer Info

    NOTIFICATIONS ture reminder. When a system error or reminder occurs, a pop-up Any active history for notifications (critical errors or screen will appear indicating the condition. reminders will be listed under settings > notifica­ Error code notification pop-up can be dismiss tion.
  • Page 14 When reminders occur, they will also be displayed under notifications as illustrated in figure 6. Press the clear or remind later to redisplay active reminder for 1 day, 1 week, 1 month, 3 months or a custom date. < notifications reminders critical media filter...
  • Page 15 PERFORMANCE REPORT NOTE: See Selection Mode on page 10 to run a This will display the total number of hours each specific schedule. month that the system has been running. Example From the HOME screen press the MENU and would be for mar (March) 23H or 23 hours. To re­ press edit schedules option.
  • Page 16 select days individual days week/weekend edit schedules schedule x all 7 days (rename) select mode schedule 1 schedule 2 select days schedule 3 select mode heat/cool heat only cool only monday * A maximum of four time periods can be used. If tuesday any time periods are deleted, an option to add a wednesday...
  • Page 17 SETTINGS (USER) Table 3. User Settings (Fan) user settings Setting < Function Description Selection See table 2 for on, auto and > detail descrip­ circulate tion. > heat/cool humidity > reminders > general > display > Figure 9. User Setting Options...
  • Page 18 Table 4. User Settings (Heat/Cool, Cool Only and Reminders) Setting Selection Function Description Heats home to desired tempera­ normal ture setting. Options are on or off. If system is two-stage heating or comfort cooling, then 2 stage is lock in unit demand is satisfied.
  • Page 19 Table 5. User Settings (Humidity) Table 6. User Settings (Reminders) Setting Setting Function Description Function Description Selection Selection media filter Options for (air filter) each reminder Options are humidity - is disabled ON and OFF. humidity pad Allows section (default), Allows humidi­...
  • Page 20 Table 7. User Settings (General) Setting Selection Function Description Displays information concerning thermostat about model number, serial number, hardware and software revisions. Setting options are unlocked, partially, and locked. To set partially lock, create a three digit code. Partially lock restricts access to accessing the menu.
  • Page 21 Table 8. User Settings (Display) Setting Selection Function Description Outdoor temperature display None or sensor Options are enable and disable. Default is enabled. When enable only the time, inside temperature and outside temperature (if outdoor sensor is installed and enabled) is screen saver displayed on the screen.
  • Page 22 INDEX Display Settings, 21 Edit Schedules, 15 About, 20 Emergency heat, 18 Away, 6 Fan Operation, 11 Fan User Settings, 17 Backlight, 21 Features, 2 Clean Screen, 21 General Settings, 20 Comfort Setting, 18 Selection Mode, Select Mode, 10 Heat-To, 6 Cool-To, 6 Home Screen, 5 Critical Notifications, 13...
  • Page 23 reminders custom reminders, 19 Master Unlock Code, 20 humidity pad, 19 Menu, 6, 12 media filter (air filter), 19 PureAir, 19 Normal Setting, 18 routine system check up, 19 Notifications, 13 uv lamp, 19 Operating Modes, 6, 11 Schedule Hold, 7 Schedules, 11 Outdoor Air Temperature, 6 Screen Brightness, 21...
  • Page 24 Settings - User, display, 20 Temperature Dial Indicator, 3 Temperature Override Setting, 7 Temperature Scale, 21 Unlock Code (master), 20 UV lamp, 19 ® U.S. Registered Trademark Model: 13H14 507503-01 ©2015 Lennox Industries Inc. Dallas, Texas, USA 7/2015 Supersedes 4/2015...
