Yealink TR-069 User Manual

This technote mainly provides a general introduction of TR-069 (Technical Report 069)
and the way of enabling the TR-069 on the Yealink IP phones. It also provides the
supported RPC methods and the information of TR-111. The information in this document
is restricted to the following Yealink IP phone models with firmware version 71 or later:
SIP-T2xP IP Phones

SIP-T3xG IP Phones

SIP-T4X IP Phones

VP530 IP Video Phones

W52P IP DECT Phones (with firmware version 30 or later)

The following takes the SIP-T28P IP phone as an example.
TR-069 is a technical specification, which is defined by the Broadband Forum. It defines
a mechanism that encompasses secure auto-configuration of a CPE (Customer-Premises
Equipment), and also incorporates other CPE management functions into a common
framework. TR-069 uses common transport mechanisms (HTTP and HTTPS) for
communication between CPE and ACS (Auto Configuration Servers). The HTTP(S)
messages contain XML-RPC methods defined in the standard for configuration and
management of the CPE. The protocol addresses different Internet access devices such
as modems, routers, gateways, set-top boxes, and VoIP-phones for the end-users.
TR-069 Schematic Design
Yealink TR-069 Technote
1
