Programming remote transmitters:
To program replacement remotes please follow the procedures below. The
unit will hold a maximum of 2 remote codes and when programming all
other older remote codes will be deleted.
Method 1: Turn On and Off the ignition 8 times and leave it ON and wait 2
seconds. The LED will glow solid. Press button 1 of the new remote control
to set the code. The LED will flash twice and the siren will chirp twice. Press
button 1 on the second remote and the LED will flash 4 times and the siren
will chirp 4 times. Turn Off the ignition to set the codes.
Method 2: With the ignition ON, press firmly and hold in the programming
button on the back of the main unit. The LED will glow solid. Press button 1
of the new remote control to set the code. The LED will flash twice and the
siren will chirp twice. Press button 1 on the second remote and the LED will
flash 4 times and the siren will chirp 4 times. Turn Off the ignition to set the
codes.
Battery Replacement:
The M1 remotes use a "AAA" Battery and will last approximately 4 months
depending on use.
For Customer service please email:
customerservice@encoreautomotivesystems.com
For Dealer Tech Support please call 855-463-6267: Ext 3
Encore Automotive Systems
27240 Turnberry Lane Suite 200, Valencia CA 91355
www.encoreautomotivesystems.com
E
M1: Two-Way
Motorcycle & ATV Alarm
Professional installation only
Installation and User's Manual
The Encore M1 is a state of the art Two-way
motorcycle alarm that utilizes advanced
detection techniques to fully secure and
protect your Motorcycle. It offers both Radar
and impact sensing and incorporates advanced
Starter or Ignition shutoff. Please read and
understand this manual before you begin your
installation.
ncore
Powered By:
E
ncore
Advertisement
Related Manuals for Encore M1
Summary of Contents for Encore M1
- Page 1 4 times and the siren will chirp 4 times. Turn Off the ignition to set the codes. Battery Replacement: The M1 remotes use a “AAA” Battery and will last approximately 4 months Professional installation only depending on use. Installation and User’s Manual...
-
Page 2: Wire Diagram
Blue/Wht: Horn Input White: Lt. Parking Light Once determined turn the key to the OFF position and insure the trigger is M1 Two Way Black: System Ground Motorcycle Alarm correct. This wire is attached to the common post of a horn relay and will be open when the horn is not used. -
Page 3: Operation
installed under the seat or in any open area. The unit will trigger warn away Display: as well as full trigger depending on the amount of time the disturbance takes place. If the radar sensor sees movement within its range for 3 seconds, it will trigger the warn-away of the alarm with a few siren and horn beeps. - Page 4 Though the M1 Motorcycle alarm system has range of up to one mile, this triggered the system. If full trigger is initiated, the unit will add a melody can vary with different environmental conditions.
- Page 5 Impact Sensor: Ignition Trigger: The impact sensor is located in the main unit and adjustments can be made When the system is armed and the ignition directly from the remote control. switch is turned ON the unit will trigger a full event.
