- Page 1 TND 760 Fleet Edition User Manual For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281...
- Page 2 However, if you have questions that are not addressed here, we invite you to contact us. Call us: 1-800-641-RAND (7263) E-mail us: fleetsupport@randmcnally.com Write to us: Rand McNally Attn: TND 760 Fleet Edition Customer Support ™ 106 Hi-Lane...
-
Page 3: Fcc Compliance Statement
Les changements ou modifications à l’équipement, que ce soient intentionnelles ou non, non expressément approuvés par Rand McNally pourraient annuler l’autorisation de l’utilisateur à utiliser cet équipement. -
Page 4: Table Of Contents
Contents Welcome to Your Rand McNally tND 760 Fleet Edition ......2 ™ Truck Info ...................19 General, Route and Map Preferences ........... 19-20 Device overview..................3 Warnings ...................20 Getting Started ..................4 Route to Destination ..............21-22 System Registration ................4 POIs ....................23... -
Page 5: Welcome To Your Rand Mcnally Tnd 760 Fleet Edition
Welcome to Your Rand McNally tND 760 Fleet Edition Easy. Convenient. Accurate. Flexible. Responsive. the Rand McNally tND 760 Fleet Edition is ™ designed to improve your work life. 1. Easy. The format, the applications and the processes are easy to understand and easy to use. -
Page 6: Device Overview
Device overview Front of Display Power Button Mounting Bracket Support Plate Use the USB to connect (with (3) 10-32 x 3/8” screws) (with (4) 10-24 x 1”screws a keyboard or mouse to your and (4) 10-24 nuts) 760. Home Button Press to return to Home Menu screen. -
Page 7: Getting Started
Getting Started System Registration 760 Fleet Edition System Registration ™ The first time you power up your TND ™ 760, Register TND 760 Fleet Edition. Once system is installed ™ you will need to register your unit. and powered on, the Registration screen should display. Enter your truck number in the truck # field and tap Register. -
Page 8: Power On
Getting Started Exhibit 1. Power on 760 Power Button ™ Press the Power button on the top right of the TND 760 display. ™ Log on The start-up screen for the TND 760 displays a log on pop-up [Exhibit 2, (a)] and the on-screen keyboard [Exhibit 2, (b)]. •... -
Page 9: Warning Screen
Getting Started Exhibit 3. Warning Screen Warning Screen The Warning Screen [Exhibit 3] reminds you that using your TND 760 while driving can be distracting. Be cautious and wise. • Tap Continue [Exhibit 3] to complete the logon. Communication Status You must have a cell or Wi-Fi connection to log on for the first time. -
Page 10: On-Screen Keyboard
Getting Started Exhibit 4. on-screen Keyboard On-screen Keyboard The TND 760 on-screen keyboard is quick to access and easy to use. ™ • All controls are on the screen. • Large button faces fit your fingers. To use the keyboard: •... -
Page 11: Status Bar
Getting Started Exhibit 5. Status Bar Status Bar The status bar remains visible at the bottom of every screen and gives you access to current information about the TND 760. ™ Any status or alert icons are found on the status bar [Exhibit 5, (a)]. Icons and their definitions are shown in the table to the left. -
Page 12: Screen Calibration
Getting Started Exhibit 6. Screen Calibration Calibrate Screen As soon as the TND 760 is running, calibrate your screen. ™ Recalibrate from time to time, especially if the screen “slips” when you touch it. To calibrate your screen: • Press and hold the Home button for 10 seconds. -
Page 13: Tnd ™ 760 Home Menu
760 Home Menu Exhibit 7. Home Menu Home Menu Screen The Home Menu [Exhibit 7] is the home screen of the TND ™ 760. The applications available to you on the TND ™ 760 are identified by icons. The icons on the Home Menu are explained in the table to the left. •... -
Page 14: Home Menu Safe-Driving Screen
760 Home Menu Exhibit 8. Home Menu Safe-driving Screen Home Menu Safe-driving Screen Menu options are limited while you are driving. When your truck is moving, the home menu safe-driving screen displays. Note: Functionality within the Mail, HOS and SysInfo applications is simplified while you are driving. -
Page 15: Tnd 760 Mail
760 Mail Exhibit 9. Mail Mail Icon on Home Menu Select the Mail icon on the Home Menu [Exhibit 9] to access messages and send e-mails. Mail opens to the Inbox tab. The tabs in Mail are explained in the table to the left. Function Inbox Holds incoming messages. -
Page 16: Inbox
760 Mail Exhibit 10. Inbox Inbox Tab All incoming messages appear in your Inbox [Exhibit 10]. Special features of the Inbox tell you details about your messages. Status information is clustered together [Exhibit 10, (a), (b) and (c)]. • (a). A blank space in this column means the message has been opened. -
Page 17: Open Message
760 Mail Exhibit 11. open Message Open Message Screen Select a message to open it [Exhibit 11]. Four action buttons are available once a message is open. • (a). Back returns you to the Inbox. • (b). Play lets you listen to the message. •... -
Page 18: Outbox
760 Mail Exhibit 12. outbox Outbox Tab All outgoing messages appear in your Outbox [Exhibit 12]. Special features of the Outbox tell you details about your messages. Your Outbox holds 50 messages. When you have sent more than that, the oldest messages in your Outbox are automatically deleted. •... -
Page 19: Send
760 Mail Exhibit 13. Send Messages Send Tab You can send messages from the Send tab [Exhibit 13]. The on-screen keyboard [Exhibit 13, (a)] appears automatically when you select the Send tab. Drop-down boxes [Exhibit 13, (b)] make it easy for you to complete the to and Subject fields. -
Page 20: Options
760 Mail Exhibit 14. options Options Tab The Options tab has two buttons [Exhibit 14]. • Manage Contacts [Exhibit 14, (a)]. This button lets you add contacts (for the list that displays in the to drop-down box on your Send message screen), request your contact list when you enter a new truck and make changes to your contact list. -
Page 21: Tnd 760 Intelliroute
760 IntelliRoute ® Exhibit 16. IntelliRoute ® IntelliRoute Icon on Home Menu ® Select the IntelliRoute icon on the Home Menu [Exhibit 16] to ® access the truck-specific routing application. IntelliRoute will route ® you around low bridges, truck-restricted roads and help you find driver-specific points of interest. -
Page 22: Truck Info
760 IntelliRoute ® Exhibit 18. Enter truck Information Truck Info Screen 1. Tap truck tools > truck Info [Exhibit 18]. 2. Tap to view all options. 3. Tap to select the options to be changed. 4. Enter new truck information settings. 5. -
Page 23: Warnings
760 IntelliRoute ® Exhibit 20. Exhibit 21. 6. Tap the Route tab [Exhibit 20]. Route Preferences Tab Map Preferences Tab 7. Tap to view route options. 8. Tap the option button to be changed. 9. Enter the new settings for the option. 10. -
Page 24: Route To Destination
Destination address. Exhibit 24. b. Begin route to destination. Destination Screen c. Cross reference to printed Rand McNally Motor Carriers’ Road Atlas. d. Return to previous window. e. View the map. f. Change the starting address for a route to the location displayed on the map screen. -
Page 25: Route Map Screen
760 IntelliRoute ® Exhibit 25. Route to Saved Destination Address Book Tab Tap Choose Destination > History or Address Book [Exhibit 25]. 2. Tap on the desired destination in the displayed list. 3. Tap Begin New Route. Route Map Screen a. -
Page 26: Pois
760 IntelliRoute ® Exhibit 27. Find a Point of Interest (PoI) Point of Interest Screen 1. Tap Choose Destination > Points of Interest [Exhibit 27]. 2. Select a search type (My truck, City, My Route, End of Day, Destination, Custom PoI, or Quick Stops). 3. -
Page 27: Trails
760 IntelliRoute ® Exhibit 28. trails Trails Screen The Trails feature allows you to record and later view or follow route information on the map. This capability is particularly useful when driving off-road or through private facilities such as a terminal or distribution center where road data is not available. - Page 28 760 IntelliRoute ® Exhibit 30. View Saved trails Trail Route Screen 1. Tap truck tools > trails. 2. Tap on the trail you want to run. 3. Tap on Show on Map. 4. Tap on the Trail icon. 5. Tap: - trail only to show only the trail.
-
Page 29: Tnd 760 Hours Of Service
760 Hours of Service Exhibit 31. Hours of Service HOS Icon on Home Menu With the TND 760, your HOS information is well-organized ™ and user-friendly. What You Do Mark the beginning of your day by submitting an On Duty status and Trip Info entry. -
Page 30: Summary
760 Hours of Service Exhibit 32. Summary HOS Main Screen-Summary Tab This tab gives you critical HOS information at-a-glance. • The top of the Summary tab shows the name and HOS status of the driver logged on to the TND 760 [Exhibit 32, (a)]. - Page 31 760 Hours of Service Exhibit 32. Summary (continued) HOS Main Screen - Summary Tab • The Summary tab also reports Hours gained back from 70hr total after midnight [Exhibit 32, (e)]. Buttons at the bottom let you change your HOS status or add specific trip information to the log [Exhibit 32, (f)].
-
Page 32: Duty Status
760 Hours of Service Exhibit 33. Add a Duty Status Pop-up for Adding a Duty Status • Tap any duty-status button to view the [Exhibit 32, (f)) Adding record of duty status pop-up [Exhibit 33, (a)]. Most fields are grayed out, which means you do not need to do anything; the system records the required information automatically. - Page 33 760 Hours of Service Exhibit 35. Add a Remark to a Duty Status Pop-up for Adding a Duty Status - Remarks Field You may need to include a comment about your duty status. The cursor automatically appears in the Remarks field [Exhibit 35].
- Page 34 760 Hours of Service Exhibit 36. Add trip Information Pop-up for Adding Trip Information • Tap the trip Info button on the Summary tab to view the Adding trip information pop-up [Exhibit 36, (a)]. The on-screen keyboard automatically appears so you can enter Load, Co-driver (if appropriate), trailer numbers and Remarks.
- Page 35 760 Hours of Service Exhibit 37. today’s Log Today’s Log Main Screen - Graph Tab The Today’s log button can be accessed on the Summary tab [Exhibit 32, (g)]. Four tabs display across the top of the Today’s log screen [Exhibit 37, (a)]. Graph is the tab that opens when you select Today’s log.
- Page 36 760 Hours of Service Exhibit 38. Edit trip Information Pop-up for Editing Trip Information Before selecting the Edit button [Exhibit 37, (b)], you can tap the graph screen on the point where you would like to make an edit. The green line on the graph indicates a change in duty status. You can also tap the Prev and Next buttons to move the green line to the desired point on the graph.
- Page 37 760 Hours of Service Exhibit 39. Certify Logs Graph Tab - Day to be Certified • If you have outstanding uncertified log entries (those that do not have a check mark next to them), you should review and certify them as soon as possible. •...
- Page 38 760 Hours of Service Exhibit 39. Certify Logs (continued) Graph Tab - Day to be Certified -To add a status, tap Add Duty Status [Exhibit 39, (c)]. Fill in the time, change the duty status field (if required) and enter the location. Add Remarks if appropriate. Tap Submit. -To alter the trip information record, tap Add trip Info [Exhibit 39, (d)], fill in the form and tap Submit.
-
Page 39: Logs
760 Hours of Service Logs Exhibit 40. Logs Tab The Logs tab gives a summary of the totals for the last 8 days [Exhibit 40]. Past days that you want to review, edit, or certify are displayed. • The top of the tab lists your name and current HOS status [Exhibit 40, (a)]. -
Page 40: Dvir
760 Hours of Service Exhibit 41. DVIR DVIR Tab The DVIR (Daily Vehicle Inspection Report) tab contains information regarding all DVIR entries from the last 8 days. DVIR information is clustered together [Exhibit 41, (a), (b) and (c)]. • (a). A blank space in this column means the DVIR entry has not yet been certified. - Page 41 760 Hours of Service Exhibit 42. Add a DVIR Pop-up for Adding DVIR • Add DVIR. Use this button when you want to add a DVIR for the current day or for any day within the last 8 days [Exhibit 41, (g)]. - trailer(s).
- Page 42 760 Hours of Service Exhibit 44. Certify DVIR Entries and Repairs DVIR Record-Defects Tab To review the entered defects of previous DVIR entries, select any entry from the last 8 days on the DVIR tab [Exhibit 40]. -Defects tab [Exhibit 44]. Select this tab to view the description of each defect listed for the selected DVIR.
-
Page 43: Dvir
760 Hours of Service Exhibit 45. Certify DVIR Entries and Repairs (continued) DVIR Record - Certify Tab - Certify tab [Exhibit 45]. Select this tab to certify the DVIR entry. • Reported by: lists Driver ID and time and date of DVIR entry. •... - Page 44 760 Hours of Service Exhibit 46. the options tab allows you to: Options Tab • Request Logs. Use this button when you want to move your logs from a previous tractor or when you have previous logs that you cannot view. The button brings up a pop-up box that displays the following notice: “Those portions of your log that haven’t been received by the back-end may be deleted when your HOS logs are downloaded.”...
-
Page 45: Options
760 Hours of Service Exhibit 46. options (continued) Options Tab • Fax/E-mail Logs. Use this button to fax or e-mail your logs. Note: You cannot send your logs unless you have certified all logs from the last 8 days. You must wait 10 minutes before sending your log again. - Page 46 760 Hours of Service Exhibit 47. options (continued) Pop-up for Changing Mode • Change Mode. This button lets you govern the information displayed by the TND 760. ™ - Normal. This option is the default or standard working mode. - Roadside Audit. This option provides limited access to your logs when enforcement asks to see them.
-
Page 47: Company
760 Hours of Service Exhibit 48. Company Company Tab The Company tab [Exhibit 48] contains information required for your log. Your carrier must make the changes to this screen. If any of the information is incorrect, contact your manager for help. Carrier The upper half of the screen identifies your carrier [Exhibit 48, (a)]. -
Page 48: Hos Safe-Driving Screen
760 Hours of Service Exhibit 49. HoS Safe-driving Screen HOS Safe-driving Screen The time shown on the HOS safe-driving screen is the effective drive time available to you for the day [Exhibit 49]. The time indicates how long you can drive before going into any violation, so the time displayed may not be your actual available drive time if you are close to your 14 or 70-hour limit. -
Page 49: Tnd 760 Sysinfo
760 SysInfo Exhibit 50. SysInfo SysInfo Icon on Home Menu Select the SysInfo icon on the Home Menu [Exhibit 50] to control system settings and to view technical information about your TND 760. SysInfo opens to the Settings tab. The tabs in SysInfo are explained in the table to the left. -
Page 50: Settings
760 SysInfo Exhibit 51. Settings Settings Tab • Volume. Control the volume of your TND 760 by selecting ™ Mute or by tapping the Down and Up buttons [Exhibit 51, (a)]. Each tap changes the volume by 10 percent. You can also change the volume by pressing down and drawing your finger across the percentage box. -
Page 51: Diagnostics
760 SysInfo Exhibit 53. Diagnostics Diagnostics – Wi-Fi Sub-Tab • Status. Shows the current method of communication [Exhibit 53, (a)]. • Health Check. Confirms function of system hardware. • Cell. Provides status of cell connection. • Wi-Fi. Provides status of Wi-Fi connection [Exhibit 53, (a) and (b)]. -
Page 52: Sysinfo Safe-Driving Screen
760 SysInfo Exhibit 55. SysInfo Safe-driving Screen SysInfo Safe-driving Screen The SysInfo safe-driving screen allows you to adjust the 760’s volume and screen brightness [Exhibit 55]. ™ For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd. Wilmington, NC 28411 (800) 507-0482 / (910) 686-4281 760 Fleet Edition User Manual ™... -
Page 53: Tnd 760 Stats
760 Stats Exhibit 56. Stats Stats Icon on Home Menu Select the Stats icon on the Home Menu [Exhibit 56] to access information about driver performance and fault codes. Stats opens to the Driver Performance tab. The tabs in stats are explained in the table to the left. Function Driver Displays statistics based on idle time, RPM,... -
Page 54: Driver Performance
760 Stats Exhibit 57. Driver Performance Driver Performance Tab The Driver Performance tab displays these statistics: • Hard brakes— where vehicle speed is over 20MPH. • Miles / MPG. • Idling percentages for Short, Mid and Long Idles. • Over Idle %—where idle is over your fleet’s grace period. •... -
Page 55: Fault Codes
760 Stats Exhibit 58. Fault Codes Fault Codes Tab The Fault Codes tab [Exhibit 58, (a)] displays recorded fault codes for the vehicle. Two columns provide details about the fault [Exhibit 58, (b)]. • Source. Indentifies the location of the fault (e.g., engine, cab controller, etc.). -
Page 56: Troubleshooting
troubleshooting Problem Possible Solutions troubleshooting No power or Check power connection intermittent - Ensure that the cable is secured to Deutsch port and display. power loss: To assist you with troubleshooting, please refer to the list - Reestablish the cable connections by unplugging them, then plugging them back in. of possible solutions to the left. - Page 57 Rand McNally and IntelliRoute are registered trademarks and TND is a trademark of Rand McNally. The Trucker’s Friend and National Truck Stop Directory are registered trademarks of TR information Publishers, Truck Down is a registered trademark of TruckDown Info International, Inc.
