- Page 1 3U10 Extractor Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model...
- Page 3 IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. Disposing of a household appliance separately avoids possible negative consequences for the environment and health.
-
Page 4: Using Your Extractor
• Steam cleaners must not be used when cleaning this appliance. • The performance of your extractor will vary depending on a number of factors, such as supply voltage and cleanliness of the filters. Note: For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. - Page 5 To switch the extractor on: • Touch the “Plus” key (D) to start the extractor running at the lowest speed. Setting the extractor speed when it is running: The extractor may run at a choice of 4 speeds, indicated by the “Speed indicator”...
-
Page 6: Care And Maintenance
You can clean your extractor effectively by simply using a dilute solution of water and mild detergent and drying to a shine with a clean cloth, for example the CDA E-Cloth. Cleaning the grease filters The grease filters should be kept clean to minimise the risk of fire. - Page 7 Please note: Cleaning the grease filters in the dishwasher may lead to discolouration. This is normal and does not constitute a fault with the appliance. Fig. 2 To remove the aluminium grease filters for cleaning • With the electricity supply still switched on, touch the “Plus” key once to lower the moving panel and start the motor at its lowest speed.
- Page 8 The LED Lamps The LED lamps are long-life items that are not designed to be replaced by the user. In the unlikely event of a lamp failure, contact CDA Customer Care for assistance.
-
Page 9: Mains Electricity Connection
Mains Electricity Connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A 3A FUSE. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. -
Page 10: Electrical Information
Note: Use a 3A Fuse. Assembly and electrical connection should be carried out by specialised personnel. When installing this product we recommend you seek the help of another individual. Do not mount the isolation switch behind the chimney section. It is a requirement that you must be able to isolate the extractor from the mains electrical supply after installation. -
Page 11: Installation
Installation When the extractor is to be installed above an electric hob, the minimum distance between the hob and extractor Gas: 650mm minimum must exceed 650mm. Electric: 650mm minimum When the extractor is to be installed above a gas hob, the minimum distance Fig. -
Page 12: Mounting Your Extractor
Mounting Your Extractor IMPORTANT: To mount this extractor correctly onto a wall, free access to both sides of the appliance is required. This extractor is therefore unsuitable for fitting in a location where it is butting up to a side wall, fitting or other obstruction. To mount the extractor onto a wall: 1. - Page 13 4. Attach the lower fixing brackets to the wall using large screws in the lower two holes drilled in the wall; note the correct orientation of these brackets is shown in fig. 6. Fig. 6 5. Only tighten the screws in these lower fixing brackets enough to hold the brackets to the wall but still allow them to...
- Page 14 1. Fit the mesh cover into the air outlet; this simply drops into position (Fig. 9). 2. Ensure that charcoal filters are Fig. 9 fitted, as described in the “Care and Maintenance” section above. These are available from CDA as an accessory.
- Page 15 For extracting installation: Fig. 10 When installing for extraction both of the optional external chimney sections are often used. 1. It is usually easiest to screw the top mounting bracket (“A” in Fig. 11) to the wall and/or ceiling, centrally above the extractor outlet before assembling any ducting.
- Page 16 Notes:...
- Page 17 Notes:...
- Page 18 Notes:...
- Page 19 Measured power consumption off mode Sound power level Grease Filter Efficiency 48.4 (F) Hood Lamp efficiency 34.8 (A) Hood E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 20 T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu Copyright © CDA 2015...
