The message "Measuring" on the display means that the instrument is
measuring. During this phase never disconnect test leads.
7. During measurements, at the end of each test, the partial values are displayed for 5
seconds, then the instrument passes to the following test
8.
At the end of the Ra
resistance value is lower than 50V/I
the instrument displays for 5 seconds a
screen like this, then it passes to the
following measurement.
paragraph 4.11 for further details or
information regarding
outcome of the test or anomalous
situations
9. At the end of the test, if the detected
tripping time is lower than the maximum
admittable limit, the instrument displays
for 5 seconds a screen like this, then it
passes to the following screen. For
further details or information regarding
the negative outcome of the test or
anomalous situations refer to paragraph
4.10
10.
At the end of the MΩ test, if the
detected resistance value is higher than
0.5MΩ, the instrument displays for 5
seconds a screen like this, then it
passes to the following screen. For
further details or information regarding
the negative outcome of the test or
anomalous situations refer to paragraph
4.9
11. At the end of the AUTO test, if all tests
have a positive outcome, the instrument
emits a double sound to signal the
positive outcome and displays a screen
like this. To display partial results press
FUNC HOLD. The single test results
are dislayed cyclically by any new
pressure on this key
CAUTION
test, if the earth
∆n
Refer to
the negative
EN - 38
MULTITEST M72 - M73 - M74 - M75
Measured value of
global earth
resistance
Measured value of
tripping time
Value of test current
Measured value of
resistance
Value of test voltage
