JP27/JP28/JP29: IEEE 1394 header
This header will only exist when the mainboard incorporates the SiS962
Southbridge chipset. Use this header to connect to any IEEE 1394 interface.
JP27
Pin Signal Name
1 VCC_BUS
3 TPB-0
5 TPA -0
7 Shield
JP28
Pin Signal Name
1 VCC_BUS
3 TPB-1
5 TPA -1
7 Shield
JP29
Pin Signal Name
1 VCC_BUS
3 TPB-2
5 TPA -2
7 Shield
Pin Signal Name
2 GND
4 TPB+0
6 TPA+0
8 NC
Pin Signal Name
2 GND
4 TPB+1
6 TPA+1
8 NC
Pin Signal Name
2 GND
4 TPB+2
6 TPA+2
8 NC
