Elsa Lanmonitor - ELSA LANCOM Business LC-4X00 Manual

Examples
This code ...
trace
trace + all
trace + protocol display
trace + all - icmp
trace ppp
trace # ipx-router
display
trace - time
You will find notes on the interpretation of trace outputs in the reference section of this
manual.

ELSA LANmonitor

The ELSA LANmonitor includes a small monitoring tool with which you can view the most
important information on the status of your router on your monitor at any time under
Windows operating systems. Many of the internal messages generated by the device
are converted to plain text, thereby helping you to troubleshoot.
Installing ELSA LANmonitor
Usually, ELSA LANmonitor is automatically installed together with the ELSA LANconfig
configuration software on the computer from which you wish to configure your router.
If ELSA LANmonitor is not yet installed on your computer, place the ELSA LANCOM in
your CD drive. If the setup program does not start up automatically after insertion of the
CD, start Windows Explorer, click on 'autorun.exe' on the CD ELSA LANCOM and follow
the instructions in the install program.
During the installation you should activate the 'ELSA LANmonitor' option.
With ELSA LANmonitor you can only monitor those devices that you can access inband
via the local network. This computer must also have the TCP/IP network protocol
installed on it. With this program you cannot access any router connected to the serial
interface.
Checking your Internet connection with ELSA LANmonitor
To demonstrate the functions of ELSA LANmonitor we will first show you the types of
information ELSA LANmonitor provides about connections being established to your
Internet provider.
... in combination with the trace causes the following:
Displays all protocols that can generate outputs during the configuration,
and the status of each output (ON or OFF)
Switches on all trace outputs
Switches on the output for all connection protocols together with the sta-
tus and error messages
Switches on all trace outputs with the exception of the ICMP protocol
Displays the status of the PPP
Toggles between the trace outputs for the IPX router and the display out-
puts
Switches off the system time output before the actual trace output.
