10 If your choice for networking your Speaker Point
is Ethernet with DHCP, skip to Step 11. Otherwise,
follow these instructions:
a Connect to Local Director.
b From the Tools menu, select System
Manager.
c From the Devices pane (left pane), select the
network address for the device you want to
set up the network configuration and click
Connect. If the device's network address is
not on this list, click Refresh. If it still does not
appear, click Add to enter it manually. If you
do not know the network address, find it at
the Connections view > Network tab.
d Select the Network tab and click Configure.
e Click Next when a Network Configuration
Wizard dialog appears. Continue through
the wizard screens and provide the following
information appropriate for system. Much of
this information has to match that of your
Wireless Access Point (WAP).
- Enter new device name. Do not include
spaces in the new name.
- Indicate kind of network: Wireless (WiFi)
network.
- Indicate Method for obtaining DNS
server address: DCHP or Static IP. Control4
recommends DHCP (automatically).
- Enter the SSID.
- Enter the WEP key (if any).
- Enter the encryption type (64 or 128).
- Click on a Key type, hex or ascii.
f Click Finish to complete the wizard and
reboot the Speaker Point to apply the
network configuration changes.
11 Configure the Speaker Point within the Composer
software. See the Composer topic, "Configure a
Speaker Point—Ethernet or Wireless" for detailed
information.
NOTE: Treble, Bass, and Balance, as well as
the initial Volume level, are set in the System
Design view of Composer by double-clicking
the Speaker Point object to access the
controls screen.
12 After you have set up this device in the
Composer software, you can control the audio
output from this Speaker Point using any of
the navigators, such as On-Screen Navigator or
4
©2012 Control4. All rights reserved. Control4, the Control4 logo, the Control4 iQ logo and the Control4 certified logo are registered trademarks or trademarks of Control4 Corporation in
the United States and/or other countries. All other names and brands may be claimed as the property of their respective owners.
any of the Touch Screens. When you use any
navigation device, ensure that the room you
are trying to control is the room selected in
the navigation device. If necessary, refer to the
"Change Location" procedure in the System User
Guide.
13 If you are using the WiFi to communicate to your
Control4 Controller, disconnect the Ethernet
Category 5 cable.
Regulatory/Safety Information
To review regulatory information for your particular
Control4 products, see the information located on
the Control4 website at: http://www.control4.com/
regulatory/.
Warranty
Limited 2-year Warranty. Go to http://www.control4.
com/warranty for details.

About This Document

Part number: 200-00040, Rev. E, 03/06/2012
