Electric built-in microwave/oven combination
Hide thumbs

Advertisement

BUILT-IN MICROWAVE/OVEN COMBINATION SAFETY

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.

Tools and Parts

Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools Needed
Phillips screwdriver
Measuring tape
Drill (for wall cabinet installations)
1" (2.5 cm) drill bit (for wall cabinet installations)
Level
Flat-blade screwdriver
Parts Needed
UL listed or CSA approved conduit connector
UL listed wire connectors
Warming Drawer Deflector Kit (for ovens installed above a
warming drawer)
Order Part Number W10489566B for white 27" (68.6 cm) kit
Order Part Number W10489564B for black 27" (68.6 cm) kit
Order Part Number W10489568A for stainless steel 27"
(68.6 cm) kit
Order Part Number W10489567B for white 30" (76.2 cm) kit
Order Part Number W10489565B for black 30" (76.2 cm) kit
Order Part Number W10489569A for stainless steel 30"
(76.2 cm) kit
Order Part Number W10727416A for stainless steel/black 30"
(76.2 cm) kit
To order, see the "Assistance or Service" section of the Use
and Care Guide.
2
Your safety and the safety of others are very important.

INSTALLATION REQUIREMENTS

You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
Flush Installation Kit (for Combo installed at flush installation)
Order Part Number W10752694A for white 27" (68.6 cm) kit
Order Part Number W10752695A for black 27" (68.6 cm) kit
Order Part Number W10752696A for stainless steel 27"
(68.6 cm) kit
Order Part Number W10752687A for white 30" (76.2 cm) kit
Order Part Number W10752688A for black 30" (76.2 cm) kit
Order Part Number W10752693A for stainless steel 30"
(76.2 cm) kit
Order Part Number W10752691A for black/stainless steel 30"
(76.2 cm) kit
To order, see the "Assistance or Service" section of the Use
and Care Guide.
Parts Supplied
#8-14 x 1" screws (4)
Bottom vent
#8-18 x ³⁄₈" screws - bottom vent (2)
Check local codes. Check existing electrical supply. See
"Electrical Requirements."
It is recommended that all electrical connections be made by a
licensed, qualified electrical installer.
Built-In Microwave/Oven Combination
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
Cabinet opening dimensions that are shown must be used.
Given dimensions provide minimum clearance with oven.
Recessed installation area must provide complete enclosure
around the recessed portion of the oven.
Grounded electrical supply is required. See "Electrical
Requirements" section.
