2 GETTING STARTED
2.1 Storage
1. Cygnus HPG is designed to be used and stored outside. However, to
prevent unnecessary weathering it is recommended that the unit is
stored inside when possible.
2. It is recommended that the battery bank is charged regularly while in
storage. Refer to
further information.
3. The emergency stop should be engaged (pushed in) and output
protection switches should be switched off when in storage and not
being charged to prevent unnecessary discharge of the battery bank.
2.2 Transporting, Lifting & Positioning
This unit is considerably heavier than regular fuel powered
generators of similar physical dimensions. Be sure to double
check the capacity of lifting equipment.

2.2.1 Transportation

1. Cygnus HPG can be transported using its optional trailer, light or heavy
goods vehicle with adequate available payload. Check the relevant
transportation documentation for suitability.
2. The gross weight of the unit can be found on the rating plate positioned
on the left hand side of the unit.
3. It is recommended that the unit is secured using suitable straps when
in transit to prevent it from moving.

2.2.2 Lifting (Loading/Unloading)

1. Cygnus HPG must be loaded or unloaded using the correct equipment
operated by suitably trained personnel.
2. Using the fork pockets, Cygnus HPG can be loaded or unloaded with a
suitable fork-lift truck or telehandler.
3. Cygnus HPG can be safely lifted using its integral lifting ring.
Page 8 CYGHPG12-24-User-Manual-v1.6.indd
"3.2 Charging From An AC Supply" on page 21 for
