4 Unit operation

Every time the unit starts, if there are cameras configured and network connection, it automatically
shows on screen the last view of cameras used.

4.1 Operation with the remote command

Use the numeric buttons [1 to 16] to select a single camera on screen.
[Zoom-in ] and [Zoom-out ] are used to change the quadrant layout: 1,4,9 or 16 cameras
on screen.
Press [Page ] or [Page ] to change to the next / previous camera or group of cameras in a quad
view.
Press the [.COM] button to show or hide the camera names on the video.

4.1.1 Main menu

Press the button [Menu ] to show on screen the main menu options, which are the following:
Cameras: Shows a list of cameras and allows the user to select one
Settings: Enters the configuration menus
Sequence: Displays the cameras configured in the sequence one by one with the defined time
interval. Exit the sequence pressing any button.
Help: Displays an operation guide
About: Shows the software version and the contact info
To exit the menu press [Exit ] at any time
User Manual - 13
