MODEL DT500CH Series
Installation and User Instructions

Ratings

• Input: 102-132 VAC 60 Hz, 2.5W max.
Output: 10 Amp/1200W Resistive, 5 Amp Inductive, 500W Tungsten
•
•
Electrical shock hazard. Risk of injury or death. Always plug three-prong plug
into a properly grounded outlet. Never attempt to defeat this safety feature.
• Risk of fire. Do not use timer to control devices that could have dangerous
consequences due to inaccurate timing, such as sun lamps, sauna, heaters,
crock pots, etc.
•
Follow local electrical codes during use.
• Dispose of used batteries promptly per local regulations.
 – Activate the Battery
The timer comes with two LR44 batteries installed.
1. Remove the pull tab from the
battery holder to connect the
installed batteries.
2. The timer will turn on and show the
default display (MO, "12:00 PM")
with the "12" flashing (Fig. 1).
NOTE: If the default display doesn't
show, the batteries may be dead.
Replace the batteries before using the
digital timer.
2 – Get Familiar with the Timer's Features
0
10
9
9
8
7
6
PM
8
5
4
7
3
2
EVENT
1. Battery Holder — two LR44 batteries keep time and data up to
three months without power
2. Time Of Day (TOD) Display — acts like a clock during normal
operation, displays messages during programming and displays
alerts, such as the Low Battery Display
3. Selector Wheel
4. PM Indicator — comes on to indicate TOD is PM, goes out to
indicate TOD is AM
Digital Timer
WARNING
NOTICE
12 12
11 11 AM AM
10 10
9 9
8 8
MO MO TU WE TH FR SA SU TU WE TH FR SA SU
7 7
6 6
5 5
RANDOM RANDOM
4 4
3 3
2 2
1 1
12 12
PM PM

12
11 AM
1
2
3
4
MO TU WE TH FR SA SU
5
6
AM
PM
7
RANDOM
8
9
10
1 11 TIME
12
PM
ON OFF
5. One Timed, Grounded Outlet — has green LED that lights when
outlet is turned on
6. Pushbuttons — used for setup, programming and manual
operation of plugged-in device
7. Reset Button
8. Random Display — indicates when the Random feature is turned
on. Random uses the timer's settings varied by random 5-minute
increments of ±15 minutes.
9. Day Of Week (DOW) Display — events can be programmed
for just one day of the week (Daily Mode, 21 total events), all
the days of the week (Weekly Mode, 48 total events), or just
weekends or weekdays (Weekend/Weekday Mode, 24 + 24 total
events)
10. Event ON/OFF Indicators — a full day is broken into 96 segments
(15 minutes each) to show the ON and OFF times programmed
NOTE: The timer may be set up and programmed before you plug
it in. Be aware that while it is unplugged, the display will turn off to
conserve battery power if there is no pushbutton activity for a few
minutes. If this happens, simply push any button to turn the display
back on.
3 – Clear Any Existing Programming
It's unlikely that your new digital timer has any existing
1 1
2 2
programming, but to make sure, use this procedure before setting
3 3
the time.
4 4
5 5 1. Locate the Reset button. It is the small, round hole adjacent to the
keypad. You will need a pen or paper clip to press this button.
6 6
PM PM
2. Press and release the Reset button. The display will light up all
7 7
the segments and then go blank.
8 8
9 9
The timer has erased all programming, displays the default
3.
10 10
11 11
settings (MO, "12:00 PM") and is ready for setup.
Fig.
1
4 – Set the Time, Day and Operating Mode
NOTE: The time, day AND operating mode must be set before any
ON Events can be programmed. Settings for time and ON Events
will not be activated until setup and programming are complete.
Setting Time and Day
2
1. Ensure that the time is displayed. A
timer that is just reset will display
3
MO, "12:00 PM".
2. The first two digits (hours) of the
4
Time of Day (TOD) display will begin
to flash (Fig. 3).
3. Turn the selector wheel until the
5
correct hour shows in the TOD hours
display, along with the PM indicator,
6
if desired. Note that PM indicator will
alternate on and off as the time
passes through noon and midnight.
Fig.
4. Press the ON button to set the new
2
hour. Or, if no change to the hour
is needed, press the TIME button to
keep the original hour setting. The
last two digits of the TOD display
(minutes) will begin to flash (Fig. 4).
5. Turn the selector wheel until the
correct time in minutes shows.
12 12
AM AM
11 11 1 1
10 10 2 2
9 9 3 3
8 8 4 4
MO MO TU WE TH FR SA SU TU WE TH FR SA SU
7 7 5 5
6 6 6 6
PM PM
5 5 7 7
RANDOM RANDOM
4 4
8 8
3 3
9 9
2 2
10 10
Fig. Fig.
1 1 11 11
12 12
PM PM
3 3
12 12
AM AM
11 11 1 1
10 10 2 2
9 9 3 3
8 8 4 4
MO MO TU WE TH FR SA SU TU WE TH FR SA SU
7 7 5 5
6 6 6 6
PM PM
5 5 7 7
RANDOM RANDOM
4 4
8 8
3 3
9 9
2 2
10 10
Fig. Fig.
1 1 11 11
12 12
PM PM
4 4
