Operating the Hedge Trimmer

Step 1 - Removing the blade protector

Remove the blade protector.

Step 2 - Starting the Engine

1
2
3
4
5
6
2a To start a cold engine
1) Set the stop switch ( ) into the START position. If starting a cold engine the choke lever must
A
be moved to the " " position.
2) Press the primer bulb 7~10 times, the fuel can be pumped into the carburettor. This will reduce
the number of start attempts after a longer break.
3) Now stand the hedge trimmer on the ground, place left hand on the front handle. Use your
right hand to pull the starter grip (
B
4) Once the engine attempts to run. Move the choke lever to the
5) Pull the starter grip again until the engine runs, let it run for about 15 seconds then operate this
hedge trimmer.
Customer Helpline 01904 727503
10
www.gardenservicecentre.co.uk
B
A
) quickly.
position.
Operating the Hedge Trimmer
Step 2 - Starting the Engine (continued)
ATTENTION! Don't touch the blade.
2b Starting under warm conditions
1) Set the switch (
2) Set the choke lever to (
3) Pull the starter grip (
Step 4 - Trimming
2a&2b
Depress the throttle lever lock (
) to (START).
A
).
) quickly until engine runs.
B
D
E
) and throttle lever ( ) to active the blade.
D E
