250W GRASS TRIMMER
Article No. 310086
Model No. N1F-GT-220/250-C
ORIGINAL INSTRUCTION MANUAL
Please read these instructions fully before starting assembly.
HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576
Technical Support & Parts
01904 727509
Mon-Fri 9am-5pm Sat-Sun 11am-4pm
www.coreservice.co.uk
July 21
Advertisement
Table of Contents
Related Manuals for Sovereign N1F-GT-220/250-C
Summary of Contents for Sovereign N1F-GT-220/250-C
- Page 1 250W GRASS TRIMMER Article No. 310086 Model No. N1F-GT-220/250-C Technical Support & Parts 01904 727509 Mon-Fri 9am-5pm Sat-Sun 11am-4pm www.coreservice.co.uk ORIGINAL INSTRUCTION MANUAL Please read these instructions fully before starting assembly. HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576...
-
Page 2: Table Of Contents
CONTENTS General safety warnings Intended use Warning symbols In the box Assembling the grass trimmer Operate the grass trimmer Maintenance Troubleshooting Technical data Recycling and disposal Getting help Warranty... -
Page 3: General Safety Warnings
GENERAL SAFETY WARNINGS Safety Warnings WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING! Read all safety warnings and instructions designated by the symbol. Save all warnings and instructions for future reference. - Page 4 GENERAL SAFETY • Keep this operating and maintenance manual in a safe place for reference at a later date. Read the instructions carefully. Be familiar with the controls and the proper use of the equipment. • Never allow children or people unfamiliar with these instructions to use the grass trimmer.
- Page 5 • Consider the work environment. Do not expose your power tool to high humidity or rain. Do not use your tool in damp and wet conditions. Keep the work area well lit. Do not use your tool where there is a risk of causing fire or explosion, e.g. in the presence of flammable liquids and gases.
- Page 6 • Remove adjusting keys and wrenches. Always check that adjusting keys and wrenches are removed from the tool before operating. • Risk of harm. Do not touch or try to stop the cutting lines when they are moving. • Disconnect the plug. Disconnect the plug from the tool when not in use, or when servicing or cleaning.
- Page 7 • Store idle tools. When not in use, power tools should be stored in a dry, secure place, out of the reach of children. • Maintain tools with care. Keep tools clean and in good condition for better and safer performance. Follow the instructions for maintenance and changing accessories.
- Page 8 • Before using the machine and after any impact, check for signs of wear or damage and repair as necessary. • Never operate the machine with damaged guards or without the guards in place. • Keep hands and feet away from the cutting area at all times.
- Page 9 fuse cover becomes lost or damaged, the plug must not be used until a suitable replacement is obtained. • If the plug has to be changed because it is not suitable for your socket, or due to damage, it should be cut off and a replacement fitted. The old plug must be disposed of safely, as insertion into a 13 amp socket could cause an electrical hazard.
-
Page 10: Intended Use
MAINTENANCE AND STORAGE • Keep all nuts, bolts and screws tight, to be sure the equipment is in safe working condition. • Replace worn or damaged parts for safety. INTENDED USE This grass trimmer has been designed for cutting grass and similar soft vegetation, and for trimming grass edges in private and hobby garden areas that are not accessible with a grass trimmer. - Page 11 Do not expose and operate the tool in rain. Objects thrown by the product could hit the user or other bystanders. Always ensure that other people and pets remain at a safe distance from the product when it is in operation. In general, children must not come near the area where the product is.
-
Page 12: In The Box
IN THE BOX Parts 1. Hook 2. On/off switch 3. Upper handle 4. Motor housing 5. Safety guard 6. Auxiliary handle 7. Trimmer head... -
Page 13: Assembling The Grass Trimmer
ASSEMBLING THE GRASS TRIMMER Step 1- Assemble trimmer head Insert the motor housing into the upper handle, making sure the handle is locked in place. Step 2- Assemble the safety guard WARNING! Do not use the product without fitting the safety guard. - Page 14 Step 3 - Fitting the auxiliary handle Locate the auxiliary handle to the bracket. Take care of its orientation. Insert the bolt through the bracket and the handle, then screw into the captivated nut. Tighten the screw with the tool. Step 4 - Main supply cable strain relief To prevent excessive strain on the cable connections, the grass trimmer is fitted with a cable restraint.
-
Page 15: Operate The Grass Trimmer
OPERATE THE GRASS TRIMMER SWITCH ON/OFF Press the on/off switch to start the grass trimmer. To switch off, simply release the on/off switch. WARNING! The cutting head continues to rotate after the trimmer has been switched off; wait until it has stopped then lay down the tool. - Page 16 Without bending over, keep the line near and parallel to the ground (perpendicular when edging). Do not switch the machine on with the cutting head on or near material to be cut. Ensure the cutting line is at full speed before contacting material to be cut.
- Page 17 4. If the grass is very long, cut it in stages rather than trying to cut it in one ago. Do not overload your trimmer; small cuts will keep the machine operating at high speed and will greatly improve cutting efficiency. MANUALLY FEED THE LINE If required, line can be fed out manually.
-
Page 18: Maintenance
MAINTENANCE REMOVE THE CUTTING HEAD COVER Press the release latch on the spool head cover and remove the cover, pulling it straight off the cutting head assembly. Pull the cutting head cover away from the spool holder. REFITTING THE SPOOL CAP Keep all areas of the cutting head cover and spool holder clean. - Page 19 Replace the spool head cover, pressing firmly down towards the spool holder to ensure the cover is fully located. Check that the cap is correctly fitted by trying to remove it without depressing the two latches. FIT THE SPOOL AND LINE COMPLETE Remove the old spool.
- Page 20 Care should be taken to ensure that the line is neatly coiled on the spool. Failure to do so will impair the efficiency of the automatic line feed. MAINTENANCE AND STORAGE 1. Never use water or chemical cleaners to clean your power tool.
-
Page 21: Troubleshooting
WARNING! Never connect live or neutral wires to the earth terminal of the plug. Only fit an approved 13 Amp BS 1363 or BS 1363/A plug and the correctly rated fuse. If in doubt, consult a qualified electrician. TROUBLESHOOTING Although your new grass trimmer is really easy to operate, if you do experience problems, check the following: WARNING! Before proceeding, unplug the power tool. -
Page 22: Technical Data
TECHNICAL DATA Model no. N1F-GT-220/250-C Voltage 230-240V~, 50Hz Rated power 250W No load speed 12000min Cutting width 220mm Cutting line diameter 1.2mm Protection class / II Machine weight 1.7KG A weighted sound pressure level (L ) 88dB(A), K : 1.5dB(A) -
Page 23: Recycling And Disposal
RECYCLING AND DISPOSAL Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. GETTING HELP Our dedicated UK-based customer helpline is open 7 days a week to assist you with assembly, parts queries and technical support. -
Page 24: Warranty
WARRANTY This product is covered by a 1 year warranty. The warranty covers any manufacturing defect in materials, workmanship and finish. Any claim under this warranty must be made by going to your nearest Homebase store, taking your proof of purchase with you, and claims must be made within 1 year of the date of purchase.
