Icom IC-F4160 Service Manual page 71

Mar. 2009
[MAIN-A UNIT] (For F4160 series)
REF ORDER
NO. NO.
R70 7030005110 S.RES ERJ2GEJ 224 X (220K)
R71 7030005050 S.RES ERJ2GEJ 103 X (10K)
R72 7030005530 S.RES ERJ2GEJ 100 X (10)
R73 7030004970 S.RES ERJ2GEJ 470 X (47)
R74 7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030005120 S.RES ERJ2GEJ 102 X (1K)
7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R75 7030005090 S.RES ERJ2GEJ 104 X (100K)
R76 7030005090 S.RES ERJ2GEJ 104 X (100K)
R77 7030005050 S.RES ERJ2GEJ 103 X (10K)
R84 7030007340 S.RES ERJ2GEJ 153 X (15K)
R85 7030007340 S.RES ERJ2GEJ 153 X (15K)
R86 7030005050 S.RES ERJ2GEJ 103 X (10K)
R87 7030004980 S.RES ERJ2GEJ 101 X (100)
R88 7030005580 S.RES ERJ2GEJ 560 X (56)
R89 7030007270 S.RES ERJ2GEJ 151 X (150)
R90 7030007270 S.RES ERJ2GEJ 151 X (150)
R91 7030005530 S.RES ERJ2GEJ 100 X (10)
R92 7030005050 S.RES ERJ2GEJ 103 X (10K)
R93 7030007280 S.RES ERJ2GEJ 331 X (330)
R94 7030005050 S.RES ERJ2GEJ 103 X (10K)
R95 7030005110 S.RES ERJ2GEJ 224 X (220K)
R96 7030007280 S.RES ERJ2GEJ 331 X (330)
R97 7030007280 S.RES ERJ2GEJ 331 X (330)
R99 7030005530 S.RES ERJ2GEJ 100 X (10)
R100 7030005090 S.RES ERJ2GEJ 104 X (100K)
R101 7030008400 S.RES ERJ2GEJ 182 X (1.8K)
R102 7030007270 S.RES ERJ2GEJ 151 X (150)
R103 7030004970 S.RES ERJ2GEJ 470 X (47)
R104 7030005600 S.RES ERJ2GEJ 273 X (27K)
R105 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R106 7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
R107 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R108 7030005210 S.RES ERJ2GEJ 822 X (8.2K)
R109 7030007060 S.RES ERJ2GEJ 684X (680K)
R110 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
R111 7030005600 S.RES ERJ2GEJ 273 X (27K)
R112 7030005000 S.RES ERJ2GEJ 471 X (470)
R113 7030005050 S.RES ERJ2GEJ 103 X (10K)
R114 7030005090 S.RES ERJ2GEJ 104 X (100K)
R115 7030005600 S.RES ERJ2GEJ 273 X (27K)
R116 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R117 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R118 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R119 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R120 7030005600 S.RES ERJ2GEJ 273 X (27K)
R121 7030005240 S.RES ERJ2GEJ 473 X (47K)
R122 7030008280 S.RES ERJ2GEJ 271 X (270)
R123 7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005080 S.RES ERJ2GEJ 823 X (82K)
7030005070 S.RES ERJ2GEJ 683 X (68K)
R124 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R125 7030005240 S.RES ERJ2GEJ 473 X (47K)
R126 7030005060 S.RES ERJ2GEJ 333 X (33K)
R128 7030005160 S.RES ERJ2GEJ 105 X (1M)
R130 7030007570 S.RES ERJ2GEJ 122 X (1.2K)
R131 7030005090 S.RES ERJ2GEJ 104 X (100K)
R132 7030005070 S.RES ERJ2GEJ 683 X (68K)
R133 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R134 7030007340 S.RES ERJ2GEJ 153 X (15K)
R135 7030005050 S.RES ERJ2GEJ 103 X (10K)
R136 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R137 7030005220 S.RES ERJ2GEJ 223 X (22K)
R138 7030005220 S.RES ERJ2GEJ 223 X (22K)
R139 7030005220 S.RES ERJ2GEJ 223 X (22K)
R140 7030011660 S.RES ERJ2RKF 1002 (10K)
R141 7030005060 S.RES ERJ2GEJ 333 X (33K)
R142 7030011660 S.RES ERJ2RKF 1002 (10K)
R143 7030005060 S.RES ERJ2GEJ 333 X (33K)
R144 7030005120 S.RES ERJ2GEJ 102 X (1K)
R145 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R146 7030010040 S.RES ERJ2GEJ-JPW
R147 7030005170 S.RES ERJ2GEJ 474 X (470K)
R148 7030008410 S.RES ERJ2GEJ 392 X (3.9K)
R149 7030010040 S.RES ERJ2GEJ-JPW
R150 7030005530 S.RES ERJ2GEJ 100 X (10)
DESCRIPTION M.
LOCATION
T 102.1/9.2
T 104.9/13.6
T 103.2/12.2
B 103.4/7.3
[11] B 103.2/10.3
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
B 101.2/10.1
B 99.6/10.1
B 100.5/11.3
T 78.3/22.8
T 77.1/23.2
B 88.1/12.4
B 90.5/12.4
B
T 88.4/17.9
T
T 88.8/28.3
T 85.5/20.3
T 91.5/17.8
T
B 80.8/26.2
T
B 88.4/28.1
B 77.2/27.8
T 81.7/33.5
T 82.6/33.5
B 74.1/28.7
B 75.7/28.7
B 71.4/33.4
T 69.3/36.2
T
T 70.7/36.5
T 72.3/34.3
B 64.8/29.4
B 66.6/32.3
T 70.7/40.5
B 79.9/36.3
B 48.2/17.2
T 86.8/15.7
T 89.7/11.8
T
T
B
T 85.8/26.2
B 83.6/25.4
B
B 74.1/38.2
[11] B 73.2/36.6
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
B 73.2/38.2
B
B
B 46.2/34.5
B 61.3/36.7
B 63.6/38.1
B
B
B 64.1/34.5
B 62.5/34.5
B 60.9/34.5
B 66.1/36.9
B 66.8/38.1
B
B 57.4/40.2
B 57.4/41.8
B 56.5/38.3
T 54.4/37.7
B
T 46.9/31.2
T 44.2/29.1
T 55.6/39.3
T 55.6/38.4
T 56.2/37.2
B
[MAIN-A UNIT] (For F4160 series)
H/V REF ORDER
NO. NO.
R151 7030004980 S.RES ERJ2GEJ 101 X (100)
R152 7030005090 S.RES ERJ2GEJ 104 X (100K)
R153 7030005050 S.RES ERJ2GEJ 103 X (10K)
R154 7030005050 S.RES ERJ2GEJ 103 X (10K)
R155 7030007340 S.RES ERJ2GEJ 153 X (15K)
R156 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R157 7030005240 S.RES ERJ2GEJ 473 X (47K)
R158 7030005060 S.RES ERJ2GEJ 333 X (33K)
R159 7030005090 S.RES ERJ2GEJ 104 X (100K)
R161 7030010040 S.RES ERJ2GEJ-JPW
R162 7030005050 S.RES ERJ2GEJ 103 X (10K)
R164 7030005230 S.RES ERJ2GEJ 334 X (330K)
R165 7030005080 S.RES ERJ2GEJ 823 X (82K)
R167 7030005220 S.RES ERJ2GEJ 223 X (22K)
R168 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R169 7030011650 S.RES ERJ2GEJ 243X (24K)
R170 7030005530 S.RES ERJ2GEJ 100 X (10)
R171 7030005160 S.RES ERJ2GEJ 105 X (1M)
R173 7030005090 S.RES ERJ2GEJ 104 X (100K)
R174 7030005290 S.RES ERJ2GEJ 682 X (6.8K)
R175 7030007280 S.RES ERJ2GEJ 331 X (330)
R176 7030005090 S.RES ERJ2GEJ 104 X (100K)
R177 7030005240 S.RES ERJ2GEJ 473 X (47K)
R178 7030005070 S.RES ERJ2GEJ 683 X (68K)
R179 7030005070 S.RES ERJ2GEJ 683 X (68K)
R180 7030008300 S.RES ERJ2GEJ 184 X (180K)
R181 7030005310 S.RES ERJ2GEJ 124 X (120K)
R182 7030010040 S.RES ERJ2GEJ-JPW
63.7/16 R183 7030005110 S.RES ERJ2GEJ 224 X (220K)
R184 7030009140 S.RES ERJ2GEJ 272 X (2.7K)
89.3/17T R185 7030005230 S.RES ERJ2GEJ 334 X (330K)
R186 7030007340 S.RES ERJ2GEJ 153 X (15K)
R187 7030005050 S.RES ERJ2GEJ 103 X (10K)
R188 7030005090 S.RES ERJ2GEJ 104 X (100K)
88/15.6 R189 7030010040 S.RES ERJ2GEJ-JPW
R190 7030005700 S.RES ERJ2GEJ 274 X (270K)
90.2/17 R191 7030005090 S.RES ERJ2GEJ 104 X (100K)
R192 7030005050 S.RES ERJ2GEJ 103 X (10K)
R193 7030004980 S.RES ERJ2GEJ 101 X (100)
R194 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R195 7030005050 S.RES ERJ2GEJ 103 X (10K)
R196 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R197 7030005050 S.RES ERJ2GEJ 103 X (10K)
R198 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R199 7030005050 S.RES ERJ2GEJ 103 X (10K)
69.2/35 R200 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R201 7030005090 S.RES ERJ2GEJ 104 X (100K)
R202 7030005110 S.RES ERJ2GEJ 224 X (220K)
R203 7030005000 S.RES ERJ2GEJ 471 X (470)
R204 7030008310 S.RES ERJ2GEJ 564 X (560K)
R205 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R206 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R207 7030005240 S.RES ERJ2GEJ 473 X (47K)
R208 7030005240 S.RES ERJ2GEJ 473 X (47K)
R209 7030005240 S.RES ERJ2GEJ 473 X (47K)
88/14 R210 7030005240 S.RES ERJ2GEJ 473 X (47K)
88/13.1 R211 7030005700 S.RES ERJ2GEJ 274 X (270K)
86.3/26 R212 7030005070 S.RES ERJ2GEJ 683 X (68K)
R213 7030005070 S.RES ERJ2GEJ 683 X (68K)
R214 7030005070 S.RES ERJ2GEJ 683 X (68K)
72.3/35B R215 7030005070 S.RES ERJ2GEJ 683 X (68K)
R216 7030005070 S.RES ERJ2GEJ 683 X (68K)
R217 7030005080 S.RES ERJ2GEJ 823 X (82K)
R219 7030004980 S.RES ERJ2GEJ 101 X (100)
R220 7030005720 S.RES ERJ2GEJ 563 X (56K)
R221 7410001130 S.ARR EXB28V102JX
R222 7410001130 S.ARR EXB28V102JX
R223 7410001130 S.ARR EXB28V102JX
R224 7030005090 S.RES ERJ2GEJ 104 X (100K)
R225 7410001130 S.ARR EXB28V102JX
R226 7410001130 S.ARR EXB28V102JX
R227 7410001130 S.ARR EXB28V102JX
R228 7030005000 S.RES ERJ2GEJ 471 X (470)
R229 7030005050 S.RES ERJ2GEJ 103 X (10K)
R230 7030005090 S.RES ERJ2GEJ 104 X (100K)
R231 7030005050 S.RES ERJ2GEJ 103 X (10K)
R232 7030005090 S.RES ERJ2GEJ 104 X (100K)
R233 7030005090 S.RES ERJ2GEJ 104 X (100K)
R234 7030005050 S.RES ERJ2GEJ 103 X (10K)
R235 7410001130 S.ARR EXB28V102JX
53.4/9.1 R236 7030005090 S.RES ERJ2GEJ 104 X (100K)
37.7/9.1 R237 7030005090 S.RES ERJ2GEJ 104 X (100K)
R238 7030004980 S.RES ERJ2GEJ 101 X (100)
R239 7030005090 S.RES ERJ2GEJ 104 X (100K)
R240 7030005090 S.RES ERJ2GEJ 104 X (100K)
62/38.1 R241 7030005090 S.RES ERJ2GEJ 104 X (100K)
65.2/36 R242 7410001130 S.ARR EXB28V102JX
R243 7030005530 S.RES ERJ2GEJ 100 X (10)
R244 7030005160 S.RES ERJ2GEJ 105 X (1M)
R245 7030008010 S.RES ERJ2GEJ 123 X (12K)
R246 7030008010 S.RES ERJ2GEJ 123 X (12K)
R247 7030008010 S.RES ERJ2GEJ 123 X (12K)
67/36.9 R248 7030005120 S.RES ERJ2GEJ 102 X (1K)
R249 7030005090 S.RES ERJ2GEJ 104 X (100K)
R250 7030005090 S.RES ERJ2GEJ 104 X (100K)
R251 7030005050 S.RES ERJ2GEJ 103 X (10K)
R252 7030005050 S.RES ERJ2GEJ 103 X (10K)
45.8/38 R253 7410001140 S.ARR EXB28V104JX
R255 7410001130 S.ARR EXB28V102JX
R257 7410001130 S.ARR EXB28V102JX
R258 7410001140 S.ARR EXB28V104JX
R259 7410001130 S.ARR EXB28V102JX
R260 7030010040 S.RES ERJ2GEJ-JPW
34.2/7.7
R261 7030005220 S.RES ERJ2GEJ 223 X (22K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
14
DESCRIPTION M.
LOCATION
T 44.9/18.9
B 46.2/36.8
T 45.7/36.1
T 44.5/36.5
B
B
B
B
B
B
B 40.2/33.5
B 37.1/29.3
B
B
B 49.1/30.2
B 46.9/31.4
T 53.6/25.9
T 55.7/20.5
B
T 50.4/25.9
T
B 45.7/11.9
B 53.4/10.7
B 38.2/33.5
T 40.5/29.6
T 39.3/31.5
T 39.3/30.6
B 41.5/25.4
B 46.9/27.4
B 47.8/28.6
B 47.8/29.8
B 47.8/26.2
B 57.5/32.8
B
B 97.2/21.9
B 99.1/17.8
T 97.3/18.4
T 95.4/24.3
B 98.8/20.9
B 101.7/24.3
B 95.4/24.2
B 94.2/24.6
B 96.1/19.6
B 94.8/19.2
T 93.7/12.5
T 97.5/10.8
B 61.6/11.4
B 61.7/23.6
B 62.4/29.4
B 35.9/14.4
T 59.8/27.4
B 27.9/33.8
B 32.4/36.2
B
B 23.3/33.8
B
T 10.7/20.6
B 21.2/37.3
B 21.2/38.2
B 22.1/40.9
B 20.4/40.9
B 19.6/38.5
B 41.5/26.3
T 18.4/29.4
B 39.9/26.3
B
B 24.7/12.9
T 16.3/22.9
B 38.6/34.7
B 28.7/17.6
B
B 32.4/25.1
T
B
B
T 98.9/39.1
T 13.4/27.2
T 26.2/24.2
T
B 19.2/15.4
B
B 50.1/41.1
B 12.7/21.7
T 27.8/36.5
B 26.6/10.2
T 55.5/35.1
T 21.5/19.1
T
T
B 15.8/32.2
B 10.9/31.5
B 10.9/29.7
T 24.8/25.1
T
T 43.8/13.8
T 27.7/32.3
B 31.7/29.8
T 27.9/28.4
B
T 25.4/31.6
T 32.5/29.8
B 19.8/32.2
B 29.9/36.8
T 23.9/35.3
S.=Surface mount
H/V
45.3/5.6
52.4/6.5
54.3/9.7
45/39.8
45/38.9
38/29.3
38/30.9
36.2/5.9
61/31.8
52/25.9
62/30.6
26/32.5
22/34.2
30.5/27
21/13.6
104/35.2
31.1/8.6
31.1/6.8
15/27.2
6.9/35.7
7.7/28.7
6.5/29.1
24.8/26T
28.5/29
