Icom IC-F4160 Service Manual page 126

Aug. 2008
[VR UNIT]
REF ORDER
NO. NO.
Q701 1590001400 S.TR XP1214 (TX)
R701 7410001140 S.ARY EXB28V104JX
R702 7030007280 S.RES ERJ2GEJ 331 X (330 )
R703 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R704 7210003061 VAR TP76N00N-15F-A103-2251A
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k)
C701 4030017420 S.CER ECJ0EC1H470J
C702 4030017420 S.CER ECJ0EC1H470J
C703 4030017420 S.CER ECJ0EC1H470J
C704 4030017420 S.CER ECJ0EC1H470J
J701 6510024930 S.CNR 20RF-JMCSG1BTF (N) (LF)(SN)
DS701 5040002670 S.LED CL-165HR/YG
S701 2250000490 ECR TP70TF5163-15.9F-2775
S702 2230001060 S.SW EVQ-PUL 02K
[JACK UNIT]
REF ORDER
NO. NO.
D801 1790001810 S.VSR AVR-M1005C080MTABB
D802 1790001810 S.VSR AVR-M1005C080MTABB
D803 1790001810 S.VSR AVR-M1005C080MTABB
D804 1790001810 S.VSR AVR-M1005C080MTABB
D805 1790001810 S.VSR AVR-M1005C080MTABB
J801 6510025141 S.CNR 10FLT-SM2-TB (LF) (SN)
EP801 6910012350 S.BEA MMZ1608Y 102BT
EP802 6910012350 S.BEA MMZ1608Y 102BT
EP803 6910012350 S.BEA MMZ1608Y 102BT
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
T
T
B
T
T
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
S.=Surface mount
H/V
32.2/6.2
11.4/1.8
31.7/8.6
32.7/8.6
13.2/2.8
10.1/5.2
11.1/5.2
12.1/5.2
14.3/3.2
11.4/4.1
33.5/11.1
8/10.4
H/V
13.7/1.7
14.7/3.8
13.8/3.8
14.1/2.6
13.5/8
5/2.6
10/3.7
10/2.2
10/.9
14
