DMA Mode [Auto]
Selects the DMA mode.
Configuration options: [Auto] [SWDMA0] [SWDMA1] [SWDMA2] [MWDMA0]
[MWDMA1] [MWDMA2] [UDMA0] [UDMA1] [UDMA2] [UDMA3] [UDMA4] [UDMA5]
SMART Monitoring [Auto]
Sets the Smart Monitoring, Analysis, and Reporting Technology.
Configuration options: [Auto] [Disabled] [Enabled]
32Bit Data Transfer [Enabled]
Enables or disables 32-bit data transfer.
Configuration options: [Disabled] [Enabled]
4.3.6

IDE Configuration

The items in this menu allow you to set or change the configurations for the IDE
devices installed in the system. Select an item then press <Enter> if you want to
configure the item.
IDE Configuration
SATA Configuraton
Configure SATA as
Hard Disk Write Protect
IDE Detect Time Out (Sec)
SATA Configuration [Enhanced]
Configuration options: [Disabled] [Compatible] [Enhanced]
Configure SATA As [IDE]
Sets the configuration for the Serial ATA connectors supported by the
Southbridge chip.
The AHCI allows the onboard storage driver to enable advanced Serial
ATA features that increases storage performance on random workloads by
allowing the drive to internally optimize the order of commands.
If you want to create a RAID 0, RAID 1, RAID 5, RAID 10, or the Intel
Storage Technology configuration from the Serial ATA hard disk drives, set
this item to [RAID].
If you want to use the Serial ATA hard disk drives as Parallel ATA physical
storage devices, keep the default setting [IDE].
4-14
[Enhanced]
[IDE]
[Disabled]
[35]
Options
Disabled
Compatiable
Enhanced
Matrix
®
Chapter 4: BIOS setup
