2.5.4

PCI slots

The PCI slots support cards such as
a LAN card, SCSI card, USB card,
and other cards that comply with PCI
specifications. The figure shows a LAN
card installed on a PCI slot.
2.5.5

PCI Express x1 slot

This motherboard supports PCI Express
x1 network cards, SCSI cards and other
cards that comply with the PCI Express
specifications. The following figure
shows a network card installed on the
PCI Express x1 slot.
2.5.6

Two PCI Express x16 slots

This motherboard supports two ATI
CrossFire™ PCI Express x16 graphics
cards that comply with the PCI Express
specifications. The figure shows two
graphics cards installed on the PCI
Express x16 slots.
See Chapter 6 for details on the
CrossFire™ technology feature.
ASUS P5B Premium Series 2-21
