2.2

Layout contents

CPU, Memory and Expansion Slots
1) Socket 462
2) DIMM 1/2
3) PCI 1/2/3
4) AGP 4x
Motherboard Settings (Switches and Jumpers)
1) BSEL0, BSEL1
2) KBPWR
3) USBPWR_01,_23,_45
4) CLRTC
Connectors
1) PS2KBMS
2) PS2KBMS
3) USB
4) COM1 / COM2
5) VGA
6) PRINTER
7) GAME_AUDIO
8) AUDIO
9) IDELED
10) FLOPPY
11) PRIMARY / SEC. IDE p. 27 IDE Connectors (Two 40-1 pin)
12) CPU_FAN
13) AAPANEL
14) ATXPWR
15) SMB
16) CD_IN1, AUX
17) SPDIF1
18) USB_23, _45
18) IR
20) PWR_LED (Panel)
21) KEYLOCK (Panel)
22) SPEAKER (Panel)
23) LED (Panel)
24) SMI (Panel)
25) PWR (Panel)
26) RESET (Panel)
ASUS A7N266-VM motherboard user guide
p. 12 CPU Support
p. 14 System Memory Support
p. 18 32-bit PCI Bus Expansion Slots
p. 18 Accelerated Graphics Slot
p. 19 CPU:DRAM Frequency Setting (Various)
p. 20 Keyboard Wake Up (+5V / +5VSB)
p. 21 USB Device Wake-up (Disable/Enable)
p. 22 Clear RTC RAM (CLRTC)
p. 23 PS/2 Mouse Port (6 pin female)
p. 23 PS/2 Keyboard Port (6 pin female)
p. 24 Universal Serial Bus Ports 0, 1 (Two x 4 pin female)
p. 24 Serial Ports (One 9-pin, One 10-1 pin)
p. 25 Monitor Output Connector (Blue 15-pin)
p. 25 Parallel Port (25 pin female)
p. 25 Game/MIDI Ports (Gold 15-pin) (Optional)
p. 26 Audio Connectors (Three 1/8" AUDIO) (Optional)
p. 26 IDE Activity LED (Two 40-1 pin)
p. 27 Floppy Disk Drive Connector (34-1 pin)
p. 28 CPU Fan Connector (3 pin)
p. 28 ASUS Front Panel Audio Connector (10 pin)
p. 29 ATX Power Supply Connector (20 pin)
p. 29 SMBus Connector (6-1 pin)
p. 30 Internal Audio Connectors (Two 4 pin) (Optional)
p. 30 Digital Audio Interfaces (4-1 pin SPDIF1) (Optional)
p. 31 USB Headers (Two 10-1 pin)
p. 31 Infrared module connector (Two 5-1 pin)
p. 32 System Power LED Lead (3-1 pin)
p. 32 Keyboard Lock Switch Lead (2 pin)
p. 32 System Warning Speaker Lead (4 pin )
p. 32 System Message LED Lead (2 pin)
p. 32 System Management Interrupt Lead (2 pin)
p. 32 ATX Power Switch / Soft-Off Switch Lead (2 pin)
p. 32 Reset Switch Lead (2 pin)
9
