Important Safety Instruction 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer‟s instructions.
Page 5
- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed no the apparatus. 14 Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation. “WARNING – To reduce the risk of fire or electric shock, do not expose the apparatus to rain or moisture.” “The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.”...
Page 6
CAUTION The power supply cord is used as the main disconnect device, ensure that the socket-outlet is located/installed near the equipment and is easily accessible. ATTENTIONN Le cordon d`alimentation est utillsé comme interrupteur général. La prise de courant doit être située ou installée à...
NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
BACK PANEL CONTROL 1. AC 24V IN 2. VGA IN 3. VIDEO(AV) IN 4. VIDEO (AV) OUT 5. CAM OUT 6. SD CARD READER (Optional) 7. USB 2.0 (Optional) 8. CAMERA OSD CONTROL (Refer to page 17~22 for details.) - 6 -...
REMOTE CONTROLLER (Optional) 1. POWER( Turns the power ON or OFF. There will be a few seconds delay before the display appears. 2. SOURCE Selects pc or video(Camera, AV, C/R) sources. 3. AUTO Auto geometry adjustment in PC Source. 4. HOLD Stops the Motion Detection &...
Page 10
FRONT & BACK KEY CONTROL 1. BUILT-IN CAMERA Image of camera. 2. IR Sensor Remote controller sensor. 3. POWER LED Turned on: Green color. Turned off: LED off. 4. RECORDING INDICATOR LED This LED indicates the recording status by blinking the LED light. User can choose the LED blink.
OSD Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the MENU button to enter the OSD menu. ▲/▼ 2. Press the buttons to select the desired option.
Page 12
B. SOUND/FUNCTION Option Function Value VOLUME Adjust the level of audio volume. 0 ~ 100 MUTE Mutes speaker sound. Off or On DATE TIME Sets the date time on the screen. See the table on Next page. RECORDING Sets the recording indication text. See the table on Next page.
Page 13
DATE TIME Option Function Value DATE TIME Activates the feature of Date Time. Off or On BLINK This function is for blinking Date & Time texts. Off or On POSITION Selects the location of Date Time text. Top, Bottom YEAR* Selects the wanted year.
Page 14
RECORDING Option Function Value INDICATOR LED Sets the light color of recoding LED Off or On TEXT DISPLAY Activates the feature of Recording Text. Off or On TEXT BLINK This function is for blinking Recording text. Off or On TEXT SIZE Selects the size of Recording text.
Page 15
C. PC (Only PC Mode) Option Function Value CONTRAST Adjusts intensity of the image. 0 ~ 100 BRIGHTNESS Adjusts brightness of the screen. 0 ~ 100 PC ADJUST Adjusts the PC Mode. See the table on Next page. COLOR MODE Adjusts the vertically picture position.
PC ADJUST Option Function Value AUTO ADJUST Auto geometry adjustment. H POSITION Adjusts the horizontally picture position. 0 ~ 100 V POSITION Adjusts the vertically picture position. 0 ~ 100 CLOCK Adjusts the vertical noise of screen image. 0 ~ 100 PHASE Adjusts the number of horizontal picture elements.
Page 17
D.SETUP Option Function Value English, German, French, Language Sets the language of the OSD menu. Italian, Spanish, Nederlands and Korea Sets the OSD. See the table on Next page. Locks all buttons of the monitor. Key Lock Note: Use remote controller to Off or On unlock.
Page 18
Option Function Value H POSITION Move OSD horizontally on screen right or left. 0 ~ 100 V POSITION Move OSD vertically on screen up or down. 0 ~ 100 OSD TIMER Adjust OSD displaying time. 5 ~ 60 TRANSPARENT Adjust OSD transparent. Off or On MOTION DELECTION Option...
Setting up the menu Settings can be made using the OSD Switch located on the back of the camera. 1. Press the button to access the SETUP mode. The SETUP menu is displayed on the monitor. 2. Please select any function you wish to activate by using the UP/DOWN selections.
Page 20
1-2. EXPOSURE (1) SHUTTER - Shutter speed control (AUTO & FLK level: 1/60~1/100000) (2) BRIGHTNESS - Adjust the brightness in 0~255 (Default 50) (3) AGC (Auto Gain Control) The higher the gain level is, the brighter the screen becomes. But the higher gain level causes more noise. - LOW : Allows automatic gain control from 0 to 20db.
Page 21
1-3. WHITE BAL (1) MANUAL - In the manual mode, the user can choose the color and balance. The user can adjust the color and temperature by controlling red and blue gain. (2) AWC→SET - This is used in order not to change the color and temperature values set for a certain environment.
1-4. BACK LIGHT (1) HSBLC : HLC is a function to mask bright areas in order to prevent the target object from looking dark due to the backlighting (2) BLC : Back Light Compensation controls the brightness Level of the screen in order to be able to distinguish objects against backlight.
Page 23
1-6. IMAGE ADJ (1) LENS SHADE - Mounted on the circumference of the lens to the lens mechanism that prevents the light directly incident (Level Adjustable 0~255) (2) 2DNR - Cuts off the noise in low light condition. (3) MIRROR - Through ON-OFF on the screen like a mirror.
Page 24
1-8. SPECIAL (1) CAM TITLE - We offers the CAM TITLE function and it can configure a title made up of up to 15 letters. (2) MOTION - MD (Motion Detection) consists of the pre-processor that extracts motion information and the mixer that displays the motion information on the screen.
Page 25
Menu of the M/P (Media Player) • Connect USB & SD card devices 1. Connect USB & SD card devices to USB slot which are on the slide of the monitor set. • Removing the USB & SD card devices from Monitor 1.
Page 26
A. PHOTO JPEG File Viewing Options - When you select Photo in entry menu, 1. Press the USB button and then use ◀/▶ button to select the Photo. 2. Press the SEL button. 3. Press the ▲/▼ button to select photo file. 4.
Page 27
B. MUSIC - Purchased MP3/music files may contain copyright restrictions. 1. Press ◀/▶ button to select the Music. 2. Press the SEL button. 3. Press the ▲/▼ button to select desired music file. 4. Press the SEL button. Then the music starts. 5.
Page 28
C. MOVIE Select the Movie 1. Press ◀/▶ button to select the Movie 2. Press the SEL button. 3. Press the ▲/▼ button to select desired movie file. 4. Press the SEL button. Then the movie starts. 5. Press exit or press the ESC button to return to the USB menu. Using the remote control Playing selected movie file PLAY/PAUSE...
Page 29
D. PHOTO MUSIC -Playing slideshow with music. 1. Press the USB button and then use ◀/▶ button to select the PHOTO MUSIC. 2. Press the SEL button. 3. Press the ▲/▼ button to select photo file. 4. Press the SEL button for picture display for slideshow. 5.
Page 30
E. PHOTO Thumbnail mode - Thumbnail mode in photo. - Press ▶ button in Photo File list or ACT button in main menu ▲/▼/◀/▶ button to select desired photo file. 1. Press 2. Press SEL button to start Slideshow 3. Press exit or press the ESC button to return to the USB menu. Using the remote control Select desired photo file for slideshow playing PLAY/PAUSE...
Page 31
F. SETUP 1. SETUP- PHOTO Select Slideshow Effect -The picture display effect for the slide show. 1. Press ◀/▶ button to select the Setup. 2. Press the SEL button enter the Setup menu. 3. Press the ▶ and then use ▲/▼ button to select Slideshow EFFECT. 4.
2. SETUP-SYSTEM Select SUBTITLE LANG. - The menus can be shown on the screen in the selected language. First select your language. 1. Press ◀/▶ button to select the Setup. 2. Press the SEL button to enter the Setup menu. 3.
Page 33
Wall mount(Optional) 1) Using the 75 mm VESA holes. 2) Using the VESA standard wall mount design and the 75mm hole pattern on the back side to install the LCD monitor to the wall. M4x10 screws ※ Attention! You must use four M4x10 screws to assemble this monitor and the wall mount bracket. ※...
POWER CONSUMPTION MODE POWER CONSUMPTION < 16W POWER OFF < 0.5W LED INDICATOR The power management feature of the monitor is comprised of two stages: ON(GREEN) and POWER OFF(LED Off). MODE LED COLOR MONITOR OPERATION GREEN Normal Operation LED Off Not Operation POWER OFF - 32 -...
2. Camera Specification ITEM NTSC Image Sensor 1/3" Sony Super HAD II CCD Total Pixels 811(H) x 508(V) 795(H) x 596(V) Effective Pixels 768(H) x 494(V) 752(H) x 582(V) Scanning System 2:1 Interlace Horizontal :15.734KHz Horizontal :15.625KHz Frequency Vertical : 59.94Hz Vertical : 50.00Hz Resolution Horizontal : 620 TV-Line (Color) / 680 TV-Line (B/W)
Page 37
3. Card Reader Specification (Optional) MEDIA SUPPOTING SPECIFICATION ITEM Format Support Remarks Category Video Audio TECRONY (Maximum bit rate, resolution) MPEG1 MPEG1 MP3, layer1,2 Over 10,240kbps,720x576 MPEG2 MPEG2 MPEG2 MPEG4 Divx3 Over 10,240kbps,720x576 Over 10,240kbps,720x576 Divx4 Over 10,240kbps,720x576 Over 10,240kbps,720x576 Divx5 Over 10,240kbps,720x576 Over 10,240kbps,720x576...
WEEE Symbols Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
