Refresh
Index
IP Address
TX rate (kbps)
RX rate (kbps)
Sessions
Action
3 . 7 . 9 T r a c e R
3 . 7 . 9 T r a c e R
Click Diagnostics and click Trace Route to open the web page. This page allows you to trace
the routes from router to the host. Simply type the IP address of the host in the box and click
Run. The result of route trace will be shown on the screen.
62
Click this link to refresh this page manually.
Display the number of the data flow.
Display the IP address of the monitored device.
Display the transmission speed of the monitored device.
Display the receiving speed of the monitored device.
Display the session number that you specified in Limit Session web
page.
Block - can prevent specified PC accessing into Internet within 5
minutes.
Unblock – the device with the IP address will be blocked in five
minutes. The remaining time will be shown on the session column.
o u t e
o u t e
