Automate 5204A Owner's Manual

Hide thumbs Also See for 5204A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Since its inception, Directed has had one
purpose, to provide consumers with the fin-
est vehicle security and car stereo prod-
ucts and accessories available. The recipient
of nearly 100 patents and Innovations Awards
in the field of advanced electronic technology.
Quality Directed products are sold and ser-
viced throughout North America and around
the world.
Call (800) 274-0200 for more information
about our products and ser vic es.
© 2012 Directed. All rights reserved.
www.automatecarsecurity.com
Vista, CA 92081
Directed is committed to delivering world-
class quality products and services that excite
and delight our customers.
QRG5204A ML 2012-12
O W N E R' S
Vehicle Security System
G U I D E
MOD EL
5204A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5204A and is the answer not in the manual?

Questions and answers

Related Manuals for Automate 5204A

Summary of Contents for Automate 5204A

  • Page 1 © 2012 Directed. All rights reserved. QRG5204A ML 2012-12 www.automatecarsecurity.com MOD EL Vista, CA 92081 Directed is committed to delivering world- O W N E R’ S G U I D E 5204A class quality products and services that excite and delight our customers.

  • Page 2: What You Get

    Congratulations Congratulations on the purchase of your state-of-the-art remote start and security system. Reading this Owner’s Guide prior to using your system will help maximize the use of your system and its many fea- tures. Please visit: www.automatecarsecurity.com – For general and additional guide information.
  • Page 3 Your system comes with a warranty. Please make sure you receive the warranty registration card and proof of purchase from your dealer indicating the product was installed by an authorized Directed dealer. Please validate it online at www.prodregister.com/automate or com- plete and return the warranty registration card.

  • Page 4: Table Of Contents

    Contents Remote Control ....................2 Using your System ....................4 Remote Control Command table ............4 Basic Commands (Direct Access) ................5 Arm ....................5 Disarm ....................5 Trunk Release ..................6 Remote Start ..................6 Key Takeover..................6 Advanced Commands ..................8 Silent Arm ...................

  • Page 5: Remote Control

    Remote Control Internal Antenna Transmit LED Confirmation LEDs Command Buttons Feature Description Internal Antenna Used for transmitting and receiving* information Transmit LED Active when transmitting information Command buttons (4) Used to perform arming, disarming, auxiliary channel and remote start commands Confirmation LEDs* Each button has an associated LED that is active during related operations.
  • Page 6 Control Center Control button Status LED The Control Center, typically located on the upper part of the front windshield. It consists of: The In-vehicle system antenna. The Status LED, as a visual indicator of the system’s status. The Control button, for placing the system into Valet Mode* and to perform the Emergency Override** operation.

  • Page 7: Using Your System

    Using your System Remote Control Command table Press and Release Shift (Press/release Press/Hold Action “AUX” first) for 2 secs. Button Silent Arm Arm, Panic and Car Finder Disarm Silent Disarm No Function Shift* Sensor Bypass Trunk release Remote Start Runtime Reset No Function * Advanced commands are performed by pressing and releasing the button prior to pressing one of the other command buttons to...

  • Page 8: Basic Commands (Direct Access)

    Basic Commands (Direct Access) Press and release The alarm arms, doors lock (if connected), and the siren chirps and parking lights flash once. The Arm LED and beeps play to confirm. If Valet mode* is On, the doors lock, the Arm LED and a fault tone plays.

  • Page 9: Trunk Release

    4 or 5 fault tones play to alert of the report. Trunk Release Press and hold The Trunk opens (if connected) when this button is pressed for 2 sec- onds. The Aux LED and tones play to confirm. Remote Start Press and release Activates (or if On, deactivates) the remote starter.
  • Page 10 function, instead the vehicle shuts down when the vehicle door is opened and the car needs to be started as normal. Remote and System Operations in online guide. Alarm Features ** See in online guide. Remote Start Faults *** See in online guide.

  • Page 11: Advanced Commands

    Advanced Commands Press and release the once, followed quickly (within 2 seconds) by pressing and releasing another command button. Silent Arm Press and release , then press and release The alarm arms, doors lock (if connected), and the parking lights flash once.

  • Page 12: Runtime Reset

    times. The Arm LED, 1 beep and 2 fault tones play to confirm. Sensors will not be activated for any level of impact. Sensor Bypass off: The Parking lights flash 1 time. The Arm LED and 1 beep play to confirm. Sensors are fully operational. Note System needs to be armed to perform Sensor Bypass.

  • Page 13: Battery Information

    Battery Information The 2-way remote control is powered by two coin cell batteries (CR- 2016). The 1-way remote control is powered by one coin cell battery (CR-2032), both can be purchased at most retailers. When the batter- ies begin to weaken, the operating range is reduced. Battery Replacement Unscrew the hardware on unit rear and remove from housing.

  • Page 14: Patent Information

    Patent Information This product is covered by one or more of the following United States patents: Remote Start Patents: 5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053; 7,483,783 Vehicle Security Patents: 5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591; 5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667; 5,952,933;...

  • Page 15: Government Regulations

    Government Regulations This device complies with Part 15 of FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 16: Warning! Safety First

    Warning! Safety First Please read the safety warnings below before proceeding. Improper use of the product may be dangerous or illegal. Installation Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. If you have any questions, ask your retailer or contact Directed directly at 1-800-753-0600.
  • Page 17 Before remote starting a manual transmission vehicle, be sure to: Leave the vehicle in neutral and be sure no one is standing in front or behind the vehicle. Only remote start on a flat surface Have the parking brake fully engaged WARNING! It is the responsibility of the owner to ensure the parking/emer- gency brake properly functions.

  • Page 18: Interference

    GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPER- ATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMME- DIATELY CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AUTHORIZED Directed DEALER TO REPAIR OR DISCONNECT THE IN- STALLED REMOTE START MODULE.

  • Page 19: Limited Lifetime Consumer Warranty

    Limited lifetime consumer warranty Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereaf- ter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was profession-...
  • Page 20 ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE OF THE UNIT.
