- Page 1 Series SC/SCT Oil, Gas & Gas/Oil Boilers I n s t a l l a t i o n , O p e r a t i o n & M a i n t e n a n c e M a n u a l...
- Page 2 INSTALLATION INSTRUCTIONS – SERIES SC AND SCT 1— Read carefully, study these instructions before beginning work. 2— This boiler must be installed by a qualified contractor. 3— The boiler warranty can be voided if the boiler is not installed, maintained and serviced correctly. 4—...
- Page 3 FIGURE 1 FIGURE 2...
- Page 4 D - JACKET ASSEMBLY 1— Refer to Page 4 for exploded view. Attach the back jacket panel (19) to bosses on middle of back section with two 1/4" x 3/8" truss head machine screws (20) provided. The back panel has two 5/16" dia. holes close to the center of the panel. 2—...
- Page 5 FIGURE 4...
- Page 6 SERIES SC/SCT Model No. Item No. Description Part No. SC/SCT-05 SC/SCT-06 SC/SCT-07 SC/SCT-08 SC/SCT-09 SC/SCT-10 Block Assembly – SC-05 Model Only X-1096 Block Assembly – SC-06 Model Only X-1096-1 Block Assembly – SCT-05 Model Only X-1097 Block Assembly – SCT-06 Model Only X-1097-1 Front Split Block Assembly SC-1018...
- Page 7 SERIES SC/SCT Model No. Item No. Description Part No. SC/SCT-05 SC/SCT-06 SC/SCT-07 SC/SCT-08 SC/SCT-09 SC/SCT-10 1/4"-20 x 3/8" Truss Hd. Mach. Screws – Cad. Plate – 2 Req’d Left Side Jacket Panel SC-6001-5 Left Side Jacket Panel SC-6001 Left Side Jacket Panel SC-6001-1 Left Side Jacket Panel SC-6001-2...
-
Page 8: Hot Water
E – PIPING DO NOT PIPE BOILER UNTIL AFTER JACKET IS INSTALLED. 1— See Figures 5 and 6 for suggested piping to the boiler. 2— Make up cold water supply connection to the boiler. 3— Install pressure gauge or theraltimeter in tapping provided. See Figure 7. 4—... - Page 9 F - BURNER INSTALLATION 1— The burner is supplied with a mounting flange fixed in position. 2— Mount the burner to the combustion chamber cover plate (3) with four 5/16"-18 x 1" studs and nuts provided. BE SURE HI TEMP GASKET IS BETWEEN THE BURNER MOUNTING FLANGE AND THE COMBUSTION CHAMBER COVER PLATE.
- Page 10 G – CONTROLS 1— Apply controls as follows: a. Water Boilers: Install the limit or operating control, temperature & pressure gauge and the pressure relief valve. See Figure 7 for proper location. b. Steam Boilers: Install pressure gauge, gauge glass trim and safety valve. See Figures 7 and 8. For application of low water cut-off see Figure 11.
-
Page 11: Tapping Locations
FIGURE 7 DIMENSIONS Rear of **Distance **Dist. Betw. Boiler Burner Number Jacket Jacket Top to Length Jacket to c/l Flue Between Front Tap. Unit Number Width Length Floor Fire Box of Flue Size Tappings & Tap. Inter. WU or SU Sections “A”... - Page 12 STEAM GAUGE/PRESSURETROLS PIPING ARRANGEMENT STEAM GAUGE/PRESSURETROLS ALTERNATE PIPING ARRANGEMENT FIGURE 8...
- Page 13 FIGURE 9: McD&M 51 Low Water Cut-off and Feeder...
- Page 14 FIGURE 10: McD&M 157 Low Water Cut-off and Pump Control FIGURE 11: McD&M #67PE-2 Low Water Cut-off...
- Page 15 I – ACCESSIBILITY CLEARANCES 1— All electrical wiring shall be done in accordance with the National Electrical Code and Local Requirements. 2— For recommended wiring, See Figures 12 and 13. 3— For complete information on servicing and adjustment of controls, refer to the attached control specification sheets. NOTE: SINGLE POLE SWITCHES INCLUDING THOSE OF SAFETY CONTROLS OR PROTECTIVE DEVICES SHALL NOT BE WIRED IN A GROUNDED LINE.
- Page 16 FORCED HOT WATER With or Without Tankless Water Heater FIGURE 12 STEAM With or Without Tankless Water Heater and GRAVITY HOT WATER FIGURE 13...
- Page 17 K — SERIES SC AND SCT RATINGS Net I-B-R Ratings I-B-R Burner Capacity Vent Gross Unit Number I=B=R Boiler Burner Output Water Steam Steam Sq. Oil G.P.H. Gas M.B.H. Boiler Size Height Feet WU or SU M.B.H. M.B.H. M.B.H. Input Input Inches (Min.)
- Page 18 Series SC/SCT Oil, Gas & Gas/Oil Boilers I n s t a l l a t i o n , O p e r a t i o n & M a i n t e n a n c e M a n u a l TO T H E I N S TA L L E R : This manual is the property of the owner and must...
