4 x 4 Utility Vehicle — Models M466, M467, & M46E
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Form No. 769-04153A
(September 9, 2008)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet M466
Summary of Contents for Cub Cadet M466
- Page 1 Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty ’ peratOr anual 4 x 4 Utility Vehicle — Models M466, M467, & M46E WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
-
Page 2: Table Of Contents
Locate your nearest Cub Cadet Dealer at (877) 282-8684 ◊ Write us at Cub Cadet LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019 If you have any problems or questions concerning the machine, phone your local Cub Cadet dealer or contact us directly. Cub Cadet’s Customer Support telephone numbers, website address... -
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 Avoid driving through water, since loss of control may occur. Drive belt may slip if exposed to water thus reducing vehicle pulling power and stopping vehicle entirely. Always use vehicle lights while operating in low light situations. Do not mount or leave vehicle while it is in motion or in actual operation.
- Page 5 Doing so may weaken the structure and endanger your safety. Never secure any parts other than Cub Cadet approved accessories on the main frame or attach the safety frame with anything other than the special fasteners specified.
-
Page 6: Spark Arrestor
Never over fill fuel tank. Fill tank to no more than ½ inch below bottom of filler neck to allow space for fuel expansion. Replace fuel cap and tighten securely. If fuel is spilled, wipe it off the engine and equipment. - Page 7 Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate WARNING—...
-
Page 8: Controls & Features
Controls and Features Check Engine Light Ignition Switch Brake Pedal Differential Lock Lever Parking Brake Lever Warning Light Cluster Engine Over-Temp Light Read this operator’s manual, safety labels, and operating instructions on the vehicle before operating. Compare the illustrations in this manual with your unit to familiarize yourself with the location of various controls and adjustments. -
Page 9: Accelerator Pedal
The check engine light (green) is located on the dash panel on the left side of the warning light cluster. See Fig. 4-1. When lit, take unit to your Cub Cadet dealer for a diagnostic test. Engine Over-Temp Light The engine over-temp light (red) is located on the dash panel on the right side of the warning light cluster. -
Page 10: Seat Belts
NOTE: Every 50 hours a “change oil” message will flash on the display for 2 minutes every time the tractor is started. This message will repeat for the first two minutes after each 50 hour interval. The oil pressure indicator light will also flash when this display is active. -
Page 11: Operation
Operation Filling Fuel Tank Stop vehicle on a level surface and apply parking brake. Turn the ignition key to the STOP position and remove the key. Allow engine to cool several minutes before you add fuel. Clean area around fuel cap and remove cap. Fill tank with fresh, unleaded, regular grade fuel only to bottom of filler neck. - Page 12 Engaging 4x4 The 4x4 switch is located on the right side of the dash panel. See the Controls & Features section. To engage, stop or slow vehicle speed and push up on the switch. All four wheels will now continue to have power. IMPORTANT: Engage the 4x4 feature as the first option when stuck in mud or similar situation where two wheel drive is ineffective at moving vehicle.
-
Page 13: Transporting Vehicle
Do not use the OPS to pull objects with the utility vehicle. Use ONLY the utility vehicle hitch for pulling. In the event of an accident, have the OPS carefully inspected and, if necessary, replaced by your Cub Cadet dealer. Do not attempt to repair the OPS. ectiOn 5 —... -
Page 14: Maintenance & Adjustment
Maintenance & Adjustments Engine Air Filter The engine air filter should be changed every 50 hours. Change more frequently if operated in extremely dusty conditions. Pull up on latch and turn counter-clockwise to release air cleaner cover. See Fig. 6-1. Cover Dust Valve... - Page 15 Changing the Engine Coolant The engine coolant should be drained and replaced with new coolant solution every 2 years or 500 hours. See your Cub Cadet service dealer to have the engine coolant changed. Cooling System Hoses Check the cooling system hoses and fan belt for any cracks or deterioration after every 100 hours of operation.
-
Page 16: Tire Pressure
If damage is noted, contact your Cub Cadet dealer. If an accident has occurred which may have damaged the OPS, have the OPS thoroughly inspected by your Cub Cadet dealer. WARNING: To ensure the structural integrity of the OPS to provide operator protection, do not attempt to straighten or weld the OPS. - Page 17 100 hours or once a year. See Fig. 6-5. If excessive wear appears, have ball joints or tie rod ends replaced by your local Cub Cadet dealer. Ball...
-
Page 18: Service
Service Headlight Bulbs Raise hood to get access to the headlight assembly. Turn the bulb/socket assembly approximately a quarter turn counterclockwise to align its tabs with the notches of the reflector, then remove from the reflector. See Fig. 7-1. Figure 7-1 Unplug the wire harness from the bulb/socket assembly. - Page 19 Torque the mounting bolts to 22 to 26 ft. lbs. Replace wheel as described in Wheel section. Belts IMPORTANT: Several components must be removed in order to change the vehicle’s belts. See your Cub Cadet Dealer to have your belts replaced. 7 — s ectiOn ervice...
-
Page 20: Maintenance Chart
Maintenance Chart Maintenance Schedule Check Transfer Case Oil Change Transfer Case Oil* Tighten Wheel Bolts Change Air Filter^ Check Engine Coolant Level Change Engine Coolant Inspect Cooling System Hoses Inspect OPS Inspect Front and Rear Shocks Inspect Ball Joints Inspect CV Boots Drain CVT Cover †... -
Page 21: Accessories
Accessories NOTE: For parts or accessories, contact your local Cub Cadet dealer. To locate the dealer nearest you call 877-282-8684 or log onto www.cubcadet.com. Description Horn (Requires Accessory Harness) Acrylic Windshield Glass Windshield (Steel Cab Component) Manual Wiper Kit*** Electric Wiper Kit***** Cab Lights, Dome, &... -
Page 22: Specifications
Specifications NOTE: Specifications subject to change without notice. Engine/Electrical Make 31HP* Kohler® Aegis EFI Type/ Cylinders 4 Cycle Gas/ 2 Cylinders Displacement 748cc Maximum Torque 45.4 ft. lb. @ 2400 RPM Ignition Mechanically Controlled Lubrication Full Pressure w/ Filter Speed (No Load) 1,000 RPM(idle)/ 4,200 RPM (fast) Cooling System Liquid... -
Page 23: Troubleshooting
Troubleshooting Problem Engine will not start Engine is difficult to start Engine misses under load Engine vapor locks Engine runs unevenly Cause(s) Battery has low voltage. Loose or corroded battery connections. Fuse is blown. Spark plug wire is loose or disconnected. Faulty spark plug or coil. - Page 24 Problem Engine overheats Engine knocks Engine loses power Starter does not work Starter cranks slowly Entire electrical system does not work Dead battery Battery light comes on when engine is running Indicator lights do not come on when key switch is in START position 11 —...
- Page 25 Problem Battery will not take a charge Difficult to shift Cause(s) Dead battery. Loose or corroded connections. Sulfated or worn-out battery. Fluid level low. Gears not lined up. Flip throttle and let it return to idle. If still hard to shift, contact your nearest Cub Cadet dealer.
- Page 26 FEDERAL and CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT The California Air Resources Board, the United States Environmental Protection Agency, and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2008 off-road engine and equipment. In California, new off-road engine and equipment must be designed, built and equipped to meet the State’s stringent anti-smog standards (in other states, 1997 and later model year equipment must be designed, built, and equipped to meet the U.S.
- Page 27 The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if MTD Consumer Group Inc demonstrates that the off-road engine and equipment has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
-
Page 28: Warranty
MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by Cub Cadet LLC with respect to new merchandise purchased and used in the United States, its possessions and territories, and by MTD Products Limited with respect to new merchandise purchased and used in Canada and/or its territories and possessions.
