Collect Mode Data lists

No.
Abbreviation
1
rgPr Regular Price
2
rgCP Regular Cold Price
3
rgrP Regular Warm Price
4
rgHP Regular Hot Price
5 dELC Dryer Moisture Sense
6
ItrC Interval Regular Cycles
7
ItCC Interval Regular Cold Cycles (60°C NORMAL )
8
ItAC Interval Regular Warm Cycles (75°C HOT, PERM. PRESS ) Number of Regular Warm cycles ( 0~65535 )
9
ItHC Interval Regular Hot Cycles (90°C MEDICAL)
10 ItSC Interval Super Cycles
11
IttF Interval Topoff Cycles
12
ItUC Interval Service Cycles
13
ItFC Interval Token Cycles
14
ACrC Accumulated Regular Cycles
15 ACCC Accumulated Regular Cold Cycles (60°C NORMAL)
16 ACAC Accumulated Regular Warm Cycles (75°C HOT, PERM. PRESS ) Number of Regular Warm cycles ( 0~65535 )
17
ACHC Accumulated Regular Hot Cycles (90°C MEDICAL)
18
ACSC Accumulated Super Cycles
19
ACtF Accumulated Topoff Cycles
20
ACUC Accumulated Service Cycles
21 ACFC Accumulated Token Cycles
22
ACrt Accumulated Run Time
23
Itnr Interval No Runs
24
Ittb Interval Trouble Cycles
25
ItPd Interval Power Downs
26 Itdd Interval Unauthorized Service Door Openings
27
ItAd Interval Authorized Service Door Openings
28
ItUC Interval Unauthorized Coin Vault Openings
29
ItAC Interval Authorized Coin Vault Openings
30
Ittl Interval Total Income
31 ACtl Accumulated Total Income
32
IttC Interval Total Cycles
33
ACtC Accumulated Total Cycles
34
SCPr Super Cycle Price
35
toPr Top Off Price
36 Itd Interval Money
37 Acd Accumulated Money
38
ItSd Interval Superwash Money
39
ACSd Accumulated Superwash Money
❊ Interval Cycles('Interval' means 'Since last data collecting')
❊ Accumulated Cycles('Accumulated'means 'Total cycles in washer/dryer's life time not include service cycles or trouble cycles')
❊ Authorized: Service Door Openings with PDA Communication (Open Service door Within 20 seconds After communicating with PDA)
❊ Unauthorized: Service Door Openings without PDA Communication
❊ These items (No.30~33) are not applied this program
Meaning
PROGRAMMING MODE - COLLECT MODE
Description
0~199 nickels ($.0~$9.95)
0~199 nickels ($.0~$9.95)
0~199 nickels ($.0~$9.95)
0~199 nickels ($.0~$9.95)
0: disable 1: enable
Number of Regular cycles ( 0~65535 )
Number of Regular Cold cycles ( 0~65535 )
Number of Regular Hot cycles ( 0~65535 )
Number of Super cycles ( 0~65535 ) ( Washer Only)
Number of Topoff cycles ( 0~65535 ) (Dryer Only)
Number of Service cycles (0~65535)
Number of Token cycles (0~65535)
Number of Regular cycles ( 0~65535 )
Number of Regular Cold cycles ( 0~65535 )
Number of Regular Hot cycles ( 0~65535 )
Number of Super cycles ( 0~65535 ) (Washer Only)
Number of Topoff cycles ( 0~65535 ) (Dryer Only)
Number of Service cycles ( 0~65535 )
Number of Token cycles (0~65535)
Number of Running minutes ( 0~65535 )
Money inserted, but no run
No money, but ran
Number of power down
Number of Unauthorized Service Door Openings ( 0~ 255)
Number of Authorized Service Door Openings ( 0~255)
Number of Authorized Service Door Openings ( 0~255)
Number of Authorized Coin Vault Openings (0~255)
Amount of money cycle($ 0 ~ $ 65535)
Amount of money cycle($ 0 ~ $ 65535)
Number of Total cycle($ 0 ~ $ 65535)
Number of Total cycle($ 0 ~ $ 65535)
$ 0,00 ~ $ 9,90
$ 0,00 ~ $ 9,90
Amount of money for regular cycle($ 0 ~ $ 65535)
Amount of money for regular cycle($ 0 ~ $ 65535)
Amount of money for superwash cycle($ 0 ~ $ 65535)
Amount of money for superwash cycle($ 0 ~ $ 65535)
65
