Service Manual
Vacuum Cleaner
Model : RC-407
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
OVERSEAS SERVICE DEPT.
Advertisement
Table of Contents
Related Manuals for Daewoo RC-407
Summary of Contents for Daewoo RC-407
- Page 1 Service Manual Vacuum Cleaner Model : RC-407 Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
-
Page 2: Specifications
CONTENTS 1. SPECIFICATIONS 2. CIRCUIT DIAGRAM 3. CAUSE OF TROUBLE AND COUNTERMEASURE DESCRIPTION ¡ DISCRIPTION LIST ¡ 5. EXPLODED VIEW AND PARTS LIST BODY (DOWN) ASS’Y ¡ BODY (DOWN) PARTS LIST ¡ COVER ASS’Y ¡ COVER PARTS LIST ¡ HOSE LINE ASS’Y ¡... -
Page 3: Circuit Diagram
2. CIRCUIT DIAGRAM YELLOW BLUE BLUE BLACK BLACK FILTER COIL WHITE WHITE 120µH, 12A 104K LR-03 LP-03 HARNESS ASS'Y TRIAC MOTOR SM16JZ47 104K SWITCH 100 1W 250V 10A YELLOW DIAC THERMOSTAT POWER CORD 250V 7.5A, 85˚C AC 250V, 7A 104K POWER P.C.B VOLTAGE... -
Page 4: Cause Of Trouble And Countermeasure
3. CAUSE OF TROUBLE AND COUNTERMEASURE TROUBLE CAUSE COUNTERMEASURE MOTOR DOSE NOT BREAK POWER CORD (AT REPLACE THE POWER ROTATE BLADE TIP OR ROOT OF PLUG) CORD DEFECTIVE PCB REPLACE REPAIR (SOLDER OR USE BREAK THE LEAD WIRE CLOSED END TERMINAL) DEFECTIVE SWITCH REPLACE THE SWITCH ABRASION CARBON... -
Page 5: Description
4. DESCRIPTION... - Page 6 Description List PART NAME PART CODE SPECS. Q¡¡ fl fl BODY ASS’Y 3620401500 COVER ASS’Y 3621404800 220V 50HZ COVER ASS’Y 3621404810 230V 50HZ HOSE ASS’Y 3623200900 1.3m E.V.A HOSE ASS’Y 3623204500 1.8m E.V.A PIPE AS 3624404500 STEEL PIPE AS 3624404600 BLOWER BRUSH ASS’Y 3629301600...
-
Page 7: Exploded View And Parts List
5. EXPLODED VIEW AND PARTS LIST BODY (DOWN) ASS’Y 14 15 17 19... -
Page 8: Body (Down) Parts List
BODY (DOWN) PARTS LIST PART NAME PART CODE SPECS. Q¡¡ fl fl TERMINAL AS 3628701900 TERMINAL£« WIRE (WH) TERMINAL AS 3628703100 TERMINAL£« WIRE (BK) HARNESS 3622705600 4505A63030 ST CE-230 SCREW TAPPING 7121401011 T2S PAN 4¡¿ 10 MFZN BRACKET CR 3620600300 3620600310 SCREW TAPPING 7121401411... -
Page 9: Cover Parts List
COVER PARTS LIST PART NAME PART CODE SPECS. Q¡¡ fl fl LATCH PUSH 4519F35000 COVER NOZZLE 3621405100 COVER DM 4560F30040 SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN VALVE 3625400100 LDPE PACKING 3624000400 PVC-S HOUSING 4560F23010 DUST METER 4560F23030 ABS (RED) DUST METER 4560F23060 ABS (GREEN) -
Page 10: Hose Line Parts List
HOSE LINE PARTS LIST PART NAME PART CODE SPECS. Q¡¡ fl fl PIPE HOSE 3624402100 VALVE 3625400200 COVER PIPE 3621405600 SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN HOSE 3623201100 CUFF HOSE 3626800200 LDPE HOUSING 4560F23010 ADAPTER 3629100200 CLAMP ADAPTER 3621200700 BUTTON ADAPTER 3626601300 ELBOW DM... -
Page 11: Suction Brush Parts List
SUCTION BRUSH PARTS LIST PART NAME PART CODE SPECS. Q¡¡ fl fl PIPE BRUSH 3624402400 NECK 3628000700 HOOK 3623100100 COVER BRUSH 3621405400 COVER AIR 3621406200 SHAFT 3624900400 SWRM + MFZN ROLLER 3624701000 PA + TPE RING E 7402004011 ER-4 MFZN CAP ROLLER 3620901500 LEVER BRUSH... -
Page 12: Accessory Nozzles
