Daewoo RC-230 Service Manual

Hide thumbs Also See for RC-230:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Service Manual
VACCUM CLEANER
MODEL : RC-230
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No. : RC-230UEF0
AUG. 2002

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-230

Summary of Contents for Daewoo RC-230

  • Page 1 S/M No. : RC-230UEF0 Service Manual VACCUM CLEANER MODEL : RC-230  Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    CONTENTS 1. SPECIFICATIONS……………………………………………… 2 Pages 2. EXTERNAL VIEWS……………………………………………… 3 Pages …………………………………………………… 3 Pages 2-1. ASSEMBLY 2-2. MODEL RC-230……………………………………………………………… 4 Pages 3. DIAGRAM……………………………………………………………… 5 Pages …………………………………………………… 3-1. WIRING DIAGRAM 5 Pages …………………………………………………… 6 Pages 3-2. CIRCUIT DIAGRAM 4. TROUBLE SHOOTING GUIDE………………………………………...

  • Page 3: Specifications

    1. SPECIFICATIONS Model RC-230 Rated Voltage AC 230V Frequency 50Hz Input Watt MAX 1000W Weight(Body) 3.5Kg Dimension(LXHXD) 320X224X220mm Cord Length 5.4m Power Control Micom Type(Handle) Dust Meter Mechanical Hose Current 1.5m Extension Pipe Multi-Aluminium 2 Lyer Nozzle Dusting Brush Crevice Tool...

  • Page 4: External Views

    2. EXTERNAL VIEWS 2-1. ASSEMBLY PART NAME BODY POWER CORD DUST METER CORD REWIND BUTTON MULTI-HOSE(SLIDE SWING) HOSE HANDLE POWER CONTROLLER COVER BUTTON EXTENSION PIPE(ALMIIUM TELESCOPIC) COVER BUTTON PIPE CONTROL BUTTON(COVER UP/DOWN) H - NOZZLE(TILTING) E - CLEANING TOOLS(CREVICE TOOL) E' - CLEANING TOOLS(DUSTING BRUSH)
  • Page 5 2-2. MODEL RC-230...

  • Page 6: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM...

  • Page 7: Circuit Diagram

    3-2. CIRCUIT DIAGRAM...

  • Page 8: Trouble Shooting Guide

    4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER OR CLOTH) CHANGE IT WITH NEW ONE IS WEAK IS FULL WITH DUST OR REMOVE THE DUST CLOGGING OR TEAR IN HOSE REMOVE OBSCTACLE OR REPLACE THE HOSE DEFECTIVE MOTOR REPLACE THE MOTOR (SEE 5-2) CLEANER DOES...
  • Page 9 TROUBLE CAUSE COUNTERMEASURE POWER CORD IS BROKEN REEL SPRING REPLACE IT (SEE 5-3) NOT WOUND UP OF CORD REEL POWER CORD BROKE AWAY REPAIR (SEE 5-3) FROM THE BOBBIN ※ CAUTION : BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REEL SPRING MAY SPRING OUT OF THE SPRING COVER.

  • Page 10: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) TAKE THE COVER TOP OUT OF THE COVER BODY BY USING AN AWL. 2) SEPARATE THE COVER DUST ASSEMBLY FROM THE COVER BODY. 3) UNSCREW THE 2 SCREWS(2) THEN LIFT THE COVER BODY UP FROM THE BODY ASSEMBLY.
  • Page 11 5-2. BODY ASSEMBLY 1) TAKE THE MOTOR ASSEMBLY OUT OF THE BODY. 2) CHECK THE MOTOR(1) (WHETHER THE MOTOR IS BURNT OUT OR NOT).

  • Page 12: Cordreel Assembly

    5-3. CORD REEL ASSEMBLY...
  • Page 13 1) TAKE THE CORD REEL OUT OF THE BODY. 2) UNSCREW THE SCREW(14) AND SEPARATE THE BOBBIN(1) FROM THE BRACKET(9) AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS AND THE RING TYPE TERMINALS(3, 4). 4) CHECK THE LEVER SPRING(17). 5) IF THE ROLLER BRAKE(16) IS WORN OUT AND SEPARATE THE LEVER(15) FROM THE BRACKET(9), THEN REPLACE THE ROLLER BRAKE(16).

  • Page 14: Cover Dust Assembly

    5-4. COVER DUST ASSEMBLY 1) UNSCREW THE 2 SCREWS(6) AND SEPARATE THE SOCKET(4) FROM THE COVER DUST(1).

  • Page 15: Cover Body Assembly

    5-5. COVER BODY ASSEMBLY 1) CHECK THE CONNECTIONS BETWEEN THE PCB ASSY(2) AND THE WIRE. 2) CHECK THE PCB ASSY(2). 3) CHECK THE SWITCH(4).

  • Page 16: Exploded View And Parts List

    6. EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY...
  • Page 17  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 18: Body Assembly

    6-2. BODY ASSEMBLY...
  • Page 19  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 20: Cover Assembly

    6-3. COVER ASSEMBLY...
  • Page 21  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 22: Motor Assembly

    6-4. MOTOR ASSEMBLY...
  • Page 23  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 24: Cord Reel Assembly

    6-5. CORD REEL ASSEMBLY 10 11...
  • Page 25  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 26: Hose Assembly

    6-6. HOSE ASSEMBLY(3623206200)
  • Page 27  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 28: Brush Assembly

    6-7. BRUSH ASSEMBLY...
  • Page 29  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.

  • Page 30: Pipe Assembly

    6-8. PIPE ASSEMBLY...
  • Page 31  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.
