Service Manual
VACCUM CLEANER
MODEL : RC-4008BA
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. : RC4008B001
MAY. 2004

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-4008BA

Summary of Contents for Daewoo RC-4008BA

  • Page 1 S/M No. : RC4008B001 Service Manual VACCUM CLEANER MODEL : RC-4008BA  Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS --------------------------------------------------- 2. EXTERNAL VIEWS -------------------------------------------------- 3. DIAGRAM -------------------------------------------------------------- 3-1. WIRING DIAGRAM ------------------------------------------------------- 3-2. CIRCUIT DIAGRAM ------------------------------------------------------ 4. TROUBLE SHOOTING GUIDE ----------------------------------- 5. DISASSEMBLING AND TREATMENT ------------------------- 5-1. CLEANER ASSEMBLY ---------------------------------------------- 5-2. BODY ASSEMBLY ------------------------------------------------------- 5-3. MOTOR ASSEMBLY ----------------------------------------------------- 5-4.

  • Page 3: Specifications

    1. SPECIFICATIONS MODEL RC-4008BA Rated Voltage/Frequency AC 230V, 50/60Hz Input Watt 1800W 450W Suction Power Noise Level 75dB(A) Weight (Body) 4.7Kg Electrical Components Thermostat (T80:80 °C OFF ) Dimension (WXHXD) 437 X 229 X 294 mm Cord Length 5.0m Filter...

  • Page 4: External Views

    2. EXTERNAL VIEWS PART NAME RC-4008B FILTER General (or HEPA) BODY VARIABLE HOSE HANDLE FLAT Type PIPE TELESCOPIC NOZZLE PEDAL CORD g FILTER : GENERAL(3621909500, SPONGE 20T), HEPA(3621908510) g PIPE : TELESCOPIC(3624411470) g NOZZLE : PEDAL(3629306610)

  • Page 5: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM 1) MODEL RC-4008B 3-2. CIRCUIT DIAGRAM 1) MODEL RC-4008B...

  • Page 6: Trouble Shooting Guide

    4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER)/DUST BOX IS CHANGE IT WITH NEW ONE (See 5-1,8) IS WEAK FULL WITH DUST REMOVE THE DUST IN DUST BOX FILTER PRE IS CLOGGY WITH DUST REMOVE THE DUST (See 5-2) CLOGGING OR TEAR IN HOSE REMOVE OBSTACLE OR REPLACE THE HOSE (See 5-6)
  • Page 7 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (See 5-4) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR (See 5-4) FROM THE BOBBIN BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REELSPRING CAUTION MAY SPRING OUT OF THE SPRING COVER.

  • Page 8: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) LIFT THE DUST COVER(8), GRILLE(10), FILTER(9) AND UNSCREW THE 6 SCREWS(6) AND THEN LIFT THE COVER ASSEMBLY(5) UP FROM THE BODY ASSEMBLY(1). 2) CHECK THE DUST BOX. 3) CHECK THE FILTER (9).

  • Page 9: Body Assembly

    5-2. BODY ASSEMBLY 1) CHECK THE SAFETY VALVE ASSEMBLY (14). 2) CHECK THE GASKET (11). 3) CHECK THE HOLDER FILTER (9). 4) CHECK THE FILTER PRE (12).

  • Page 10: Motor Assembly

    5-3. MOTOR ASSEMBLY 1) TAKE THE MOTOR ASSEMBLY OUT OF THE CASE MOTOR ASSEMBLY. 2) CHECK THE MOTOR(2) (WHETHER THE MOTOR IS BURNT OUT OR NOT). 3) CHECK THE CONNECTION BETWEEN MOTOR TERMINAL AND THE LEADS. 4) CHECK THE SLIDE VOLUME(5) AND SWITCH(6).

  • Page 11: Cordreel Assembly

    5-4. CORDREEL ASSEMBLY...
  • Page 12 1) TAKE THE CORD REEL ASSEMBLY OUT OF THE BODY ASSEMBLY. 2) UNSCREW THE SCREW(21). 3) SEPARATE THE BOBBIN(5) FROM THE CASE MOTOR BOTTOM(1) AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS(13,14) AND THE RING TYPE TERMINALS(7,8). 4) CHECK THE LEVER SPRING(4). 5) IF THE ROLLER BRAKE(3) IS WORN OUT AND SEPARATE THE LEVER(2) FROM THE CASE MOTOR BOTTOM(1), THEN REPLACE THE ROLLER BRAKE(3).

  • Page 13: Pcb Assembly

    5-5. PCB ASSEMBLY 1) CHECK THE CONNECTIONS BETWEEN THE WIRES AND PCB BOARD. 2) CHECK THE THERMOSTAT...

  • Page 14: Hose Assembly

    5-6. HOSE ASSEMBLY 1) MODEL RC-4005B'S, RC-4006B'S(3623210600) 1) UNSCREW THE 1 SCREWS(5) AND CHECK WHETHER THE CLAMP(2) IS BROKEN OR NOT. 2) CHECK THE PACKING(10, 11) AND HOSE(6).

  • Page 15: Brush Assembly

    5-7. BRUSH ASSEMBLY 1) TO SEPARATE THE PIPE BRUSH(4) FROM THE COVER BRUSH(1), UNSCREW THE 4 SCREWS(15). 2) CHECK THE OPENING OF THE NECK BRUSH(8) AND THE PIPE BRUSH(5).

  • Page 16: Dust Box Assembly

    5-8. DUST BOX ASSEMBLY 1) CHECK THE MESH FILTER(4, 8). 2) CHECK THE WASHABLE FILTER(10). 3) CHECK THE PACKING(2,9).

  • Page 17: Exploded View And Parts List

    6.EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY 1) MODEL RC-4008B...
  • Page 18 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS. PART NAME PART CODE Q'YT...

  • Page 19: Body Assembly

    6-2. BODY ASSEMBLY 1) MODEL RC-4008B (3620412000)
  • Page 20 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS. PART NAME PART CODE Q'YT...

  • Page 21: Cover Body Assembly

    Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-3.

  • Page 22: Cover Dust Assembly

    Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-4.

  • Page 23: Dust Box Assembly

    Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-5.

  • Page 24: Motor Assembly

    Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-6.

  • Page 25: Cordreel Assembly

    6-7. CORDREEL ASSEMBLY 1) MODEL RC-4008B (3629508400)
  • Page 26 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). PART NAME PART CODE SPECS.

  • Page 27: Case Motor Upper Assembly

    6-8. CASE MOTOR UPPER 1) MODEL RC-4008B (3621107600)
  • Page 28 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS. PART NAME PART CODE Q'YT...

  • Page 29: Hose Assembly

    6-9. HOSE ASSEMBLY 1) MODEL RC-4008B (3623210600)
  • Page 30 Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). PART NAME PART CODE SPECS.

  • Page 31: Pipe Assembly

    Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-10.

  • Page 32: Brush Assembly

    6-11. BRUSH ASSEMBLY 1) MODEL RC-4008B (3629306610)
  • Page 33 Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS.
