Service Manual
VACCUM CLEANER
MODEL : RC-4008S
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. : RC4008S001
MAY. 2004

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-4008S

Summary of Contents for Daewoo RC-4008S

  • Page 1 S/M No. : RC4008S001 Service Manual VACCUM CLEANER MODEL : RC-4008S  Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS --------------------------------------------------- 2. EXTERNAL VIEWS -------------------------------------------------- 3. DIAGRAM -------------------------------------------------------------- 3-1. WIRING DIAGRAM ------------------------------------------------------- 3-2. CIRCUIT DIAGRAM ------------------------------------------------------ 4. TROUBLE SHOOTING GUIDE ----------------------------------- 5. DISASSEMBLING AND TREATMENT ------------------------- 5-1. CLEANER ASSEMBLY ---------------------------------------------- 5-2. BODY ASSEMBLY ------------------------------------------------------- 5-3. MOTOR ASSEMBLY ----------------------------------------------------- 5-4.

  • Page 3: Specifications

    1. SPECIFICATIONS MODEL RC-4008S Rated Voltage/Frequency AC 230V, 50/60Hz Input Watt 1800W Suction Power 370W Noise Level 75dB(A) Weight (Body) 4.7Kg Electrical Components Thermostat (T80:80°C OFF ) Dimension (WXHXD) 437 X 229 X 294 mm Cord Length 5.0m Filter HEPA...

  • Page 4: External Views

    2. EXTERNAL VIEWS PART NAME RC-4008S FILTER HEPA HOSE HANDLE GRIP HOSE VARIABLE PIPE TELESCOPIC NOZZLE PEDAL CORD g FILTER : HEPA(3622204810) g PIPE : TELESCOPIC(3624411470) g NOZZLE : PEDAL(3629306610)

  • Page 5: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM 1) MODEL RC-4008S 3-2. CIRCUIT DIAGRAM 1) MODEL RC-4008S...

  • Page 6: Trouble Shooting Guide

    4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER)/DUST BOX IS CHANGE IT WITH NEW ONE (See 5-1,8) IS WEAK FULL WITH DUST REMOVE THE DUST IN DUST BOX FILTER PRE IS CLOGGY WITH DUST REMOVE THE DUST (See 5-2) CLOGGING OR TEAR IN HOSE REMOVE OBSTACLE OR REPLACE THE HOSE (See 5-6)
  • Page 7 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (See 5-4) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR (See 5-4) FROM THE BOBBIN BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE CAUTION REELSPRING MAY SPRING OUT OF THE SPRING COVER.

  • Page 8: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) LIFT THE DUST COVER(8), GRILLE(10), FILTER(9) AND UNSCREW THE 6 SCREWS(6) AND THEN LIFT THE COVER ASSEMBLY(5) UP FROM THE BODY ASSEMBLY(1). 2) CHECK THE DUST BOX. 3) CHECK THE FILTER (9).

  • Page 9: Body Assembly

    5-2. BODY ASSEMBLY 1) CHECK THE SAFETY VALVE ASSEMBLY (14). 2) CHECK THE GASKET (11). 3) CHECK THE HOLDER FILTER (9). 4) CHECK THE FILTER PRE (12). 5) CHECK THE TERMINAL AS (16).

  • Page 10: Motor Assembly

    5-3. MOTOR ASSEMBLY 1) TAKE THE MOTOR ASSEMBLY OUT OF THE CASE MOTOR ASSEMBLY. 2) CHECK THE MOTOR(2) (WHETHER THE MOTOR IS BURNT OUT OR NOT). 3) CHECK THE CONNECTION BETWEEN MOTOR TERMINAL AND THE LEADS. 4) CHECK THE ON/OFF SWITCH(5).

  • Page 11: Cordreel Assembly

    5-4. CORDREEL ASSEMBLY...
  • Page 12 1) TAKE THE CORD REEL ASSEMBLY OUT OF THE BODY ASSEMBLY. 2) UNSCREW THE SCREW(21). 3) SEPARATE THE BOBBIN(5) FROM THE CASE MOTOR BOTTOM(1) AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS(13,14) AND THE RING TYPE TERMINALS(7,8). 4) CHECK THE LEVER SPRING(4). 5) IF THE ROLLER BRAKE(3) IS WORN OUT AND SEPARATE THE LEVER(2) FROM THE CASE MOTOR BOTTOM(1), THEN REPLACE THE ROLLER BRAKE(3).

  • Page 13: Pcb Assembly

    5-5. PCB ASSEMBLY 1) CHECK THE CONNECTIONS BETWEEN THE WIRES AND PCB BOARD. 2) CHECK THE THERMOSTAT...

  • Page 14: Hose Assembly

    5-6. HOSE ASSEMBLY 1) UNSCREW THE 1 SCREWS(6) AND CHECK WHETHER THE CLAMP(4) IS BROKEN OR NOT. 2) CHECK THE CONNECTIONS THE TERMINALS(2) AND THE HOSE WIRE. 3) UNSCREW THE 2 SCREWS(17) AND CHECK THE PCB SLIDE VOLUME AS(19). 4) CHECK THE CONNECTIONS THE PCB Y-TERMINAL AS(15) AND HARNESS(20). 5) CHECK THE CONTACTS THE PCB Y-TERMINAL AS(15) AND THE TERMINAL AS(12) 6) CHECK THE CONNECTIONS THER TERMINAL AS(13) AND THE HOSE WIRE.

  • Page 15: Brush Assembly

    5-7. BRUSH ASSEMBLY 1) TO SEPARATE THE PIPE BRUSH(4) FROM THE COVER BRUSH(1), UNSCREW THE 4 SCREWS(15). 2) CHECK THE OPENING OF THE NECK BRUSH(8) AND THE PIPE BRUSH(5).

  • Page 16: Dust Box Assembly

    5-8. DUST BOX ASSEMBLY 1) CHECK THE MESH FILTER(4, 8). 2) CHECK THE WASHABLE FILTER(10). 3) CHECK THE PACKING(2,9).

  • Page 17: Exploded View And Parts List

    6.EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY 1) MODEL RC-4008S...
  • Page 18 SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN DUST BOX AS 3621910500 ASSY(RC-4008B) COVER DUST AS 3621439500 ASSY(RC-4008B) FILTER EXHAUST 3622204810 FRAME+HEPA GRILL EXHAUST 3622401210 HOSE AS 3623211400 RC-4008S(EVA, SWING) PIPE AS 3624411470 SPC T=0.7 BRUSH AS 3629306610 PEDAL(NON-SILK) NOZZLE CREVICE 3628100600...

  • Page 19: Body Assembly

    6-2. BODY ASSEMBLY 1) MODEL RC-4008S (3620412050)
  • Page 20 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS. PART NAME PART CODE Q'YT...

  • Page 21: Cover Body Assembly

    : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-3. COVER ASSEMBLY 1) MODEL RC-4008S (3621438220) PART NAME PART CODE SPECS.

  • Page 22: Cover Dust Assembly

    : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-4. COVER DUST ASSEMBLY 1) MODEL RC-4008S (3621439500) SPECS. PART NAME...

  • Page 23: Dust Box Assembly

    : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-5. DUST BOX ASSEMBLY 1) MODEL RC-4008S (3621910500) SPECS. PART NAME...

  • Page 24: Motor Assembly

    : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-6. MOTOR ASSEMBLY 1) MODEL RC-4008S PART NAME PART CODE SPECS.

  • Page 25: Cordreel Assembly

    6-7. CORDREEL ASSEMBLY 1) MODEL RC-4008S(3629508400)
  • Page 26 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). PART NAME PART CODE SPECS.

  • Page 27: Case Motor Upper Assembly

    6-8. CASE MOTOR UPPER 1) MODEL RC-4008S (3621107660)
  • Page 28 SPECS. PART NAME PART CODE Q'YT CASE MOTOR UPPER 3621107100 SWITCH PUSH 3629002000 7A/250V,(SKT) PCB POWER CONTROL AS 3624315050 RC-4008S, 220~240V/50HZ COVER PCB 3621437100 SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN FILTER OUTLET 3621909400 PE(T=3) ABSORBER SOUND 362113300 PU FOAM...

  • Page 29: Hose Assembly

    6-9. HOSE ASSEMBLY 1) MODEL RC-4008S (3623211400)
  • Page 30 Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). PART NAME PART CODE SPECS.

  • Page 31: Pipe Assembly

    : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). 6-10. PIPE ASSEMBLY 1) MODEL RC-4008S SPECS. PART NAME PART CODE...

  • Page 32: Brush Assembly

    6-11. BRUSH ASSEMBLY 1) MODEL RC-4008B (3629306610)
  • Page 33 Caution In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). SPECS. PART NAME PART CODE Q'YT...
