Daewoo RC-1700P Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual

Vacuum Cleaner

Model: RC-1700P, S-36L
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. : RC9003S001
Jun. 2003

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-1700P

Summary of Contents for Daewoo RC-1700P

  • Page 1: Vacuum Cleaner

    S/M No. : RC9003S001 Service Manual Vacuum Cleaner Model: RC-1700P, S-36L  Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS ------------------------------------------------------------------------ 2. EXTERNAL VIEWS ----------------------------------------------------------------------- 3. DIAGRAM 3-1. WIRING DIAGRAM --------------------------------------------------------------- 4 3-2. CIRCUIT DIAGRAM ------------------------------------------------------------------- 4. TROUBLE SHOOTING GUIDE ------------------------------------------------------- 5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY ---------------------------------------------- 5-2. BODY ASSEMBLY ------------------------------------------------------------ 9 5-3. MOTOR ASSEMBLY ---------------------------------------------------------------- 5-4.

  • Page 3: Specifications

    1. SPECIFICATIONS RC-1700P, S-36L MODEL (North America) Rated Voltage AC 120V Rated Frequency 50/60Hz Input Watt 1100W Suction Power 300W Noise Level 75dB(A) Weight (Body) 4.7Kg Display Dimension (WXHXD) 546 X 250 X 290 mm Cord Length 8.2m HEPA Filter...

  • Page 4: External Views

    2. EXTERNAL VIEWS PART NAME RC-1700P S-36L FILTER HEPA HEPA HOSE ASSEMBLY (4-Current, Power Nozzle Control) HOSE ASSEMBLY × × (2-Current, Power Nozzle Control) HOSE ASSEMBLY × × (2-Current, Power Nozzle Control) HOSE ASSEMBLY × × (2-Current, Power Nozzle Control)

  • Page 5: Diagram

    3. DIAGRAM 3-1. WIRING DIAGRAM 3-2. CIRCUIT DIAGRAM Main PCB...
  • Page 6 PCB IN THE HOSE ASSEMBLY...

  • Page 7: Trouble Shooting Guide

    4. TROUBLE SHOOTING GUIDE TROUBLE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER) IS FULL WITH CHANGE IT WITH NEW ONE (See 5-1) IS WEAK DUST FILTER PRE IS CLOGGY WITH DUST REMOVE THE DUST (See 5-2) CLOGGING OR TEAR IN HOSE REMOVE OBSTACLE OR REPLACE THE HOSE (See 5-6) DEFECTIVE MOTOR REPLACE THE MOTOR (See 5-3)
  • Page 8 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (See 5-4) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR (See 5-4) FROM THE BOBBIN BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REELSPRING CAUTION MAY SPRING OUT OF THE SPRING COVER.

  • Page 9: Disassembling And Treatment

    5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) CHECK THE DUST BAG(14). 2) LIFT THE BUTTON(11), FILTER(12), GRILLE(13) AND UNSCREW THE 6 SCREWS(10). AND THEN LIFT THE COVER ASSEMBLY(9) UP FROM THE BODY ASSEMBLY(1). 3) CHECK CONNECTION BETWEEN THE PCB(8) AND THE WIRES OF EACH ASSEMBLY(2,7,9) . 4) LIFT THE MOTOR ASSEMBLY(2), CORDREEL ASSEMBLY(7) FROM THE BODY ASSEMBLY(1).

  • Page 10: Body Assembly

    5-2. BODY ASSEMBLY 1) CHECK THE FILTER PRE (15). 2) CHECK CONNECTION BETWEEN PCB(8) AND THE TUBE(20) . 3) CHECK CONNECTION BETWEEN THE WIRE(21) AND THE MAIN PCB/ CORDREEL ASSEMBLY. 4) CHECK CONNECTION BETWEEN THE TUBE(20) AND SMALL PROTRUSION IN THE BODY(1).

  • Page 11: Motor Assembly

    5-3. MOTOR ASSEMBLY 1) TAKE THE MOTOR OUT OF THE CASE (3, 4). 2) CHECK THE MOTOR(1) (WHETHER THE MOTOR IS BURNT OUT OR NOT). 3) CHECK CONNECTION BETWEEN MOTOR TERMINAL AND THE WIRES. 4) CHECK THE THERMOSTAT(7).

  • Page 12: Cordreel Assembly

    5-4. CORDREEL ASSEMBLY...
  • Page 13 1) TAKE THE CORD REEL ASSEMBLY OUT OF THE BODY ASSEMBLY. 2) UNSCREW THE SCREW(20). 3) SEPARATE THE BOBBIN(6) FROM THE BRACKET(1) AND CHECK CONTACT BETWEEN THE Y TYPE TERMINALS(14,15) AND THE RING TYPE TERMINALS(8,9). 4) CHECK THE LEVER SPRING(4). 5) IF THE ROLLER BRAKE(3) IS WORN OUT AND SEPARATE THE LEVER(2) FROM THE BRACKET THEN REPLACE THE ROLLER BRAKE(3).

  • Page 14: Pcb Assembly

    5-5. PCB ASSEMBLY 1) CHECK THE CONNECTIONS BETWEEN THE WIRES AND PCB BOARD. 2) CHECK THE THERMOSTAT. 3) CHECK THE FUSE. 4) CHECK THE PRESSURE SENSOR.

  • Page 15: Hose Assembly

    5-6. HOSE ASSEMBLY 1) UNSCREW THE 2 SCREWS(15) AND DISASSEMBLE THE COVERS(8,9) FROM PIPE(1) DISASSEMBLE THE COVER ADAPTER(10) FROM THE PIPE ADAPTER(8). 2) CHECK THE CONTACT BETWEEN TERMINAL(12) AND THE RING TERMINALS(2,3). 3) CHECK THE CONNECTION BETWEEN THE TERMINALS(12) AND WIRES. 4) CHECK THE CONNECTION BETWEEN THE RING TERMINALS(2,3) AND WIRES.
  • Page 16 1) UNSCREW THE 4 SCREWS(32) AND DISASSEMBLE THE CAP COVER HANDLE(31) FROM THE COVER HANDLE RIGHT/LEFT(26,27). DISASSEMBLE THE COVER HANDLE LEFT(27). 2) CHECK CONTACT BETWEEN THE TERMINAL(21) AND THE RING TERMINALS(2,3). 3) CHECK CONNECTION BETWEEN THE TERMINAL OF PCB(21) AND THE PCB ASSEMBLY(23). 4) CHECK CONNECTION BETWEEN THE TERMINAL(29) AND THE PCB(21).

  • Page 17: Brush Assembly

    5-7. BRUSH ASSEMBLY 1) TO SEPARATE THE PIPE BRUSH(4) FROM THE COVER BRUSH(1), UNSCREW THE 4 SCREWS(15). 2) CHECK OPENING OF THE NECK BRUSH(8) AND THE PIPE BRUSH(5).

  • Page 18: Exploded View And Parts List

    6.EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY...
  • Page 19 3621909200 ASSY(TACONY-RICCAR) HOSE AS 3623210300 4CURRENT EVA,2M,LED, BUTTON (RC-1700P,S-36L) HOSE AS 3623210350 2CURRENT EVA,2M,LED, BUTTON (RC-1700S, S-30L) PIPE AS 3624411480 ASSY(ONE-TOUCH(2)+TERMINAL) (RC-1700P, S-36L) PIPE AS 3624411490 AL-NAT,T=0.85 (RC-1700S, S-30L) BRUSH AS 3629308900 ASSY(POWER-UL-RICCAR) (RC-1700P) BRUSH AS 3629306610 PEDAL(NON-SILK) BRUSH AS...

  • Page 20: Body Assembly

    6-2. BODY ASSEMBLY...
  • Page 21  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 22: Cover Body Assembly

    6-3. COVER BODY ASSEMBLY...
  • Page 23  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 24: Cover Dust Assembly

    6-4. COVER DUST ASSEMBLY...
  • Page 25  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 26: Motor Assembly

     Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) 6-5. MOTOR ASSEMBLY PART NAME PART CODE SPECS.
  • Page 27 6-6. CORDREEL ASSEMBLY...
  • Page 28  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 29: Pcb Assembly

    6-7. PCB ASSEMBLY...
  • Page 30  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...
  • Page 31  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...
  • Page 32  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE SPECS.
  • Page 33  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME Q'YT RD-AZ103J-...

  • Page 34: Hose Assembly

    6-8. HOSE ASSEMBLY...
  • Page 36  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 37: Pipe Assembly

    6-9. PIPE ASSEMBLY...
  • Page 38  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...

  • Page 39: Brush Assembly (Powe Nozzle)

     Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) 6-10. BRUSH ASSEMBLY (POWER NOZZLE) PART NAME PART CODE SPECS.

  • Page 40: Brush Assembly (Floor)

     Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) 6-11. BRUSH ASSEMBLY (FLOOR) PART NAME PART CODE SPECS.

  • Page 41: Brush Assembly (Pedal)

    6-12. BRUSH ASSEMBLY (PEDAL)
  • Page 42  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) SPECS. PART NAME PART CODE Q'YT...
