Summary of Contents for Vax VCST-01
-
Page 2: Table Of Contents
INSTRUCTIONS FOR USE DETAILS Steam cleaning suggestions page 3 page 13 9.1. LIST OF ACCESSORIES Vacuum suggestions page 4 page 14 9.2. BEFORE USE EMPTYING THE MACHINE TANK page 5 page 15 Specifications TOPPING UP THE BOILER WATER TANK WITH WATER page 5 page 15 USES... -
Page 3: Details
1 DETAILS *Colours of product may differ from final product received Cable winder Power cable Boiler water tank cap Main switch Boiler switch “Steam-ready” pilot light “No-Water” pilot light Main switch pilot light Boiler switch pilot light Steam adjustment knob Pressure gauge Boiler water tank Machine tank... -
Page 4: List Of Accessories
LIST OF ACCESSORIES AND COMPONENTS *Colours of accessories and components may differ from final product received Hose tube Suction power level Extension tubes LED indicator Big brush steam delivery Carpet fitting safety lock Floor fitting lower hooking lever Liquid fitting Extension + spray Steam nozzle extension Small nozzle brush... -
Page 5: Before Use
3 BEFORE USE Specifications CAUTION! This user’s manual is an integral part of the appliance. Read the user’s manual carefully before using the appliance. Keep the The manual uses specifications, shown below, to draw your attention to manual for future reference. specific functions of the machine. -
Page 6: General Warnings
Repairs must be carried out only by Vax technicians and by assessment prior to its first use return of the product to Vax Service Centre Connect machine to a suitable 240V power supply. -
Page 7: Starting Up
6 STARTING UP automatic valve bottle (19a) (picture 5) which stops the water Preparing the vacuum cleaner supply when the boiler water tank is completely filled. (picture 6) • Put on the boiler water tank cap (C) The appliance is supplied and equipped with a microfibre filter (P) which is already assembled. -
Page 8: Operation
WARNING: Make sure that the microfiber filter (P) or the sponge filter filter cover, and that the solid filter (R) is placed correctly. If not, (Q) are properly fitted between upper filter holder and lower the handgrip (T) cann ot be hooked safely. picture 7 picture 8 picture 9... -
Page 9: Using Steam And Suction Simultaneously
Using the appliance as a steam cleaner Using steam and suction simultaneously Please refer to the chapter “6.2 Starting up the boiler” before use. Please refer to the chapter “6.2 Starting up the boiler” before use. To Press the main switch (D) and the boiler switch (E), the respective steam and vacuum simultaneously: it is possible to use the above- pilot lights (H) and (I) will come on. -
Page 10: Using The Accessories
USING THE ACCESSORIES WINDOW WIPER (13) The attachments can be directly connected to the handgrip (23) or, depending on your needs, to the extension tubes (2) CAUTION! Excessive temperature differences between the glass • window and the steam can break the window. Fitting the attachments: fit completely until the lower hooking With extreme outside temperatures, preheat the window with steam lever (30) is hooked... -
Page 11: Small Brush
SMALL BRUSH (14) The small brush has a steam diffuser and a suction nozzle. Two different fittings can be installed on it: Small wiper attachment (15) • Bristled attachment (16) • The attachments can be fixed onto the small brush (14). To disconnect the attachment from the brush, press the front part of the brush (push were indicated), using your thumb to release the hooking teeth of the attachment (pictures 23-24). -
Page 12: Filters
FILTERS The appliance is supplied with the following filters: Sponge filter (Q): The Sponge filter (Q) is to be used for Solids filter (R): this filter performs an initial filtration of • • vacuuming dust, vapour and liquids with the water filter for more deposits and material of considerable size. -
Page 13: Suggestions
9 SUGGESTIONS Steam cleaning suggestions Adjust the amount of When initiating cleaning, or after having a long break, you steam with the knob (J): should direct the first steam jet to one side in order t o turn anticlockwise to eliminate possible water residues from the steam hose;... -
Page 14: Vacuum Suggestions
• When vacuuming liquids on the surfaces, do not exceed the double Vacuum suggestions Max level inside the machine tank (M) CAUTION! • When using the water filtration, replace water when it starts to look • Do not vacuum explosive, toxic or inflammable substances (e.g. cloudy chimney ashes and soot) or substances that may be dangerous to •... -
Page 15: Emptying The Machine Tank
10 EMPTYING THE MACHINE TANK • WARNING: Empty the machine tank (M) every time you finish using it. Turn the handle (N) over and pull the filter assembly (O) up/forward (picture 51) CAUTION! Before removing the tank, switch off the appliance and unplug it. •... -
Page 16: After Use
CAUTION! Repairs should only be carried out only by the Vax Breakdowns may occur when the appliance is not used properly. The Service Centre. following table describes a few problems and explains how to solve them. If our solutions do not help, call the Vax Service Centre. - Page 17 TROUBLE CAUSE SOLUTION - After switching on, the no-water pilot - Low water level in the boiler tank - Fill the boiler tank with water using the light flashes and the appliance is beeping recharging automatic valve bottle - The appliance is ready for use but there - The quick connector of the flex tube is not fitted - Make sure that the quick connector (24) is no suction or no steam...
-
Page 18: Disposal
16 DISPOSAL Disposal should take place without detriment to the environment. The WARNING: appliance and attachments are mostly made of plastic. As owner of an electrical or electronic product, you are not allowed by When the appliance or attachments no longer work, they must be law (according to EU-Directive 2002/96/EC of 27 January 2003 on disposed of. -
Page 19: Warranty
The manufacturer undertakes to repair free of charge those parts showing manufacturing defects within the warranty period, or to replace these free of charge. Defects not clearly attributable to materials or manufacture may be examined by Vax and shall be charged according to the outcome of the examination. - Page 20 Vax Commercial Kingswood Road Hampton Lovett Droitwich Worcestershire WR9 0QH, UK info@vaxcommercial.co.uk vaxcommercial.co.uk...
