SERVICE MANUAL
DISHWASHER
EDW 1503
+
Dishwasher
599 515 184
+
EDW 1503

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EDW 1506

Summary of Contents for Electrolux EDW 1506

  • Page 1 SERVICE MANUAL DISHWASHER EDW 1503 Dishwasher 599 515 184 EDW 1503...
  • Page 2 Index - 2 -...
  • Page 3 Build-in dimensions for Integrated Dishwashers ÖKO-FAVORIT * Appliances with height-adjustable feet Plinth height for appliances 820 mm high 100 - 175 mm Plinth height for appliances 870 mm high 150 - 230 mm - 3 -...
  • Page 4 3. Components - 4 -...
  • Page 5 display „lack of rinse aid“ Dosing of detergent dosing of rinse-aid maximum filling level Dosing of rinse aid outlet of rinse-aid Capacity detergent tray detergent tray for pre wash Spule Zeit Zeit Zeit Zeit Zeit Zeit - 5 -...
  • Page 6 Temp. Resistor 10°C 9653 Ohm 25°C 4843 Ohm 60°C 1204 Ohm 90°C 445 Ohm - 6 -...

  • Page 7: Function Mode Of The Condensing Drying

    Function mode of the condensing drying - 7 -...
  • Page 8 - 8 -...

  • Page 9: Service Tips

    4. Service tips Torx - 9 -...
  • Page 10 - 10 -...
  • Page 11 - 11 -...
  • Page 12 - 12 -...

  • Page 13: Water Course Scheme

    5. Water Course Scheme Inlet valve Flow heater Non-return valve salt container Drain pump Air break Regeneration valve Regeneration water dosage Non-return valve Safety inlet hose Overflow safety level Spray arms Base tray Safety overflow Roof-mounted shower Float switch Tub vent Inlet to sump from regeneration dosage chamber Pressure switch Regeneration dosage chamber...

  • Page 14: Aqua-Control Inlet Hose

    Aqua-Control Inlet Hose Safety level Leakage Protection Inlet valve Flow heater Non-return valve salt container Air break Drain pump Regeneration valve Non-return valve Regeneration water dosage Safety inlet hose Overflow safety level Spray arms Base tray Safety overflow Roof-mounted shower Float switch Inlet to sump from regeneration dosage chamber Tub vent...

  • Page 15: Water Inlet

    5.2 Water Inlet Flow heater Inlet valve Non-return valve salt container Air break Drain pump Regeneration valve Regeneration water dosage Non-return valve Safety inlet hose Overflow safety level Spray arms Base tray Roof-mounted shower Safety overflow Float switch Inlet to sump from regeneration dosage chamber Tub vent Pressure switch Regeneration dosage chamber...
  • Page 16 5.2.1 Water load steps (Example) static water dynamic water max. 4 load load repetitions to level wit h level control Timeout 1 Timeout 2 speed target- speed ≥20 Sek. 5 Sek. 10 Sek. 5 Sek. 1600 time in Sek. water level c heck: level c heck: in L...

  • Page 17: Random-Function

    speed 2800 var iable s peed 1600 20 S ec. high,r high,r high,r s tar t-r outine time in s ec. -function = time (high s peed) + r andom time high,r water in L dynamic pulse was h level pr ess ur e s witch point water level...
  • Page 18 5.3 Draining Inlet valve Flow heater Non-return valve salt container Drain pump Air break Regeneration valve Regeneration water dosage Non-return valve Safety inlet hose Overflow safety level Spray arms Base tray Safety overflow Roof-mounted shower Float switch Tub vent Inlet to sump from regeneration dosage chamber Pressure switch Regeneration dosage chamber Sump assembly...
  • Page 19 Sequence draining with pressure switch level check drain pump 1 dr aining sequence with var iable timing level c heck! (variable) (variable) (variable) Drain Cycle First draining before every wash cycle 45 sec 15 sec 20 sec Draining after the wash cycles 30 sec 20 sec 10 sec...
  • Page 20 6. Electronic EDW 1503 6.1 In- and output elements (': Dis play L D14 - 2 9 L D1 L D2 L D3 L D4 L D5 L D6 L D10 (LQ$XV6FKDOWHU L D11 L D12 RKQH /DPSH - 20 -...

  • Page 21: General Information

    6.2. General information EDW 1503 / VGA Equipment in the panel area LD10 1 99 LD11 (see description page B 1) LD12 Possible equipment w Separate ON/OFF switch S0 without optical confirmation w 6 keys S1 to S6 to select programs or options with the corresponding LEDs All keys are free and can be programmed without any restriction by the programming of the appliance variant.
  • Page 22 EDW 1503 / VGA 6.3. Input philosophy: program selection LD10 1 99 LD11 LD12 1. Appliance in switched-off condition LD10 LD11 LD12 2. Switch on appliance with ON/OFF key S0 -- "prestart" mode Ä Appliance is in the prestart mode Ä...
  • Page 23 6.4. Input philosophy: select start time Variant A Variant B time preselection after program selection time preselection before program selection ç Variant A LD10 LD10 LD11 LD11 1. Appliance in switched-off condition LD12 LD12 2. Switch on appliance with ON/OFF key S0 Ä...

  • Page 24: Cycle Start

    6.5. Input philosophy: program run A special feature with fully integrated appliancesis the condition that there are no control and display elements visible when the door has been closed. That is why important information for the customer, such as the cycle end or information on faults are indicated acoustically in addition.
  • Page 25 6.6. Input philosophy: delete program EDW 1503 / VGA LD10 1 99 LD11 LD12 A selected or already started washing cycle can be deletedat any time during normal operation Delete program (using the reset function) Reset function always with keys S2 and S3 1.
  • Page 26 6.7.1. Input philosophy: alter program EDW 1503 / VGA LD10 1 99 LD11 LD12 Alter program during the prestart mode The door is still open at that moment! Display blinkt 1. Program has been selected but did not yet start Ä...
  • Page 27 6.7.2. Input philosophy: alter program EDW 1503 / VGA LD10 1 99 LD11 LD12 Alter program after program start 1. To alter a program you have to open the door! Tür öffnen 2. Program is stopped by opening the door. Ä...
  • Page 28 6.8. Input philosophy: interrupt program Interrupt program Using the ON/OFF key S0 it is possible to interrupt the program as long as one wants. The same is valid for an interruption by opening the door. There is no deleting function integrated in the ON/OFF key S0. If the cycle is interrupted by using the ON/OFF key, all displays go out.
  • Page 29 6.9. Input philosophy - displays All displays are designed as LED displays and are available depending on the appliance variant. Start-time preselection and run time are indicated via a display only with the EDW1503. A special feature with fully integrated appliances is the condition that there are no control and display elements visible when the door has been closed.
  • Page 30 6.10. Short survey of all customer, service and aftersales service functions EDW 1503 / VGA LD10 1 99 LD11 LD12 Confirmation Call Detailed Who? Which function? Selection of special mode customer or service of the special mode of special function description ...
  • Page 31 When calling the customer functions no washing cycle must be selected generally! 6.11. Service function / setting of water hardness General information Calling / changing / saving the "electronic" hardness area value w Setting and changing the water hardness area is executed in Calling the function "set water hardness"...
  • Page 32 When calling the service functions no washing cycle must be selected generally! 6.12. Customer function / deactivation of rinse-aid addition General information Calling / changing / saving the rinse-aid addition deactivation Calling the function "deactivate rinse-aid addition" The function rinse-aid deactivation does not exist generally LD10 LD11 and must be programmed in the software variant.
  • Page 33 When calling the customer functions no washing cycle must be selected generally! 6.13. Customer function / deactivation of signal sound General information Calling / changing / saving the signal sound deactivation Calling the function "signal sound deactivation" The function deactivation of the signal sound does not exist LD10 LD11 generally and must be programmed in the software...
  • Page 34 6.14. Service function / readout of fault memory and single actuator selection: General information Calling above-mentioned service function w Calling the service function is executed in all designs Calling the functions LD10 LD11 "readout of fault memory" and "single actuator selection" resp.
  • Page 35 6.15. Service function / LED test with integrated deletion of the fault memory: General information Calling above-mentioned service function w Calling the service functions is executed in all designs Calling the functions LD10 LD11 resp. key arrangements analogously. "LED test with integrated deletion of the fault memory" LD12 w For that you always have to use keys S0, S1, S2 and S3 independent of their variant-depending program load.
  • Page 36 6.16. Service function / manufacturing test routine: General information Calling above-mentioned service function w Calling the service functions is executed in all designs Calling the function "manufacturing test routine" LD10 LD11 resp. key arrangements analogously. LD12 w For that you always have to use keys S0, S1, S2 and S3 Appliance in switched-off condition independent of their variant-depending program load.
  • Page 37 Overview Errors Displayed Applicable for EDW1500 / 1503 (VGA) -- EDW1100 / 1003 (VGA) -- EDW2000 Display Display Error Display Call Acoustic Error Output via Short Explanation What happens? visible for Error Memory Indication Name Indicator Lamp Screen END LED Customer** (Service) No.of Beeps...

  • Page 38: List Of Possible Error Causes

    List of Possible Error Causes Code Possible error causes Water tap is closed or faulty No water pressure, pressure too low or changing Screen in front of inlet valve clogged Flow governor at inlet valve faulty No or not enough water let in Inlet valve faulty Inlet valve deenergized (faulty wiring or no activation by electronics) Inlet hose bent...
  • Page 39 8. Wirings - 22 -...
  • Page 40 - 23 -...
